Printed-circuit board connector - ZEC 1,0/ 8-ST-3,5
C2R1,8BDF4F1 - 1936225
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Direct connector, Nominal current: 8 A, Rated voltage (III/2): 200 V, Number of positions: 8, Pitch: 3.5 mm,
Connection method: Spring-cage connection, Color: green, Contact surface: Tin, Mounting: Direct plug-in
method
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Note
4017918618919
85366990
Made to Order (non-returnable)
50 STK
Technical data
Dimensions
Pitch
Dimension a
3.50 mm
28 mm
General
Range of articles
Type of contact
Number of positions
Connection method
Insulating material group
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
Maximum load current
ZEC 1,0/..-ST
Female connector
8
Spring-cage connection
I
2.5 kV
2.5 kV
2.5 kV
125 V
200 V
320 V
EN-VDE
8A
1 mm²
8 A (with 1 mm² conductor cross section)
11/14/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/1936225
Printed-circuit board connector - ZEC 1,0/ 8-ST-3,5
C2R1,8BDF4F1 - 1936225
Technical data
General
Insulating material
Flammability rating according to UL 94
Stripping length
PA
V0
7 mm
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Conductor cross section AWG min.
Conductor cross section AWG max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
Minimum AWG according to UL/CUL
Maximum AWG according to UL/CUL
0.2 mm²
1 mm²
0.2 mm²
1 mm²
0.25 mm²
0.25 mm²
0.75 mm²
24
16
0.5 mm²
0.5 mm²
26
16
Conductor cross section flexible, with ferrule without plastic sleeve max. 1 mm²
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
EN-VDE
CUL
V0
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Approvals
Approvals
Approvals
UL Recognized / VDE Gutachten mit Fertigungsüberwachung / cUL Recognized / IECEE CB Scheme / CCA / EAC / cULus Recognized
Ex Approvals
11/14/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/1936225
Printed-circuit board connector - ZEC 1,0/ 8-ST-3,5
C2R1,8BDF4F1 - 1936225
Approvals
Approval details
UL Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
VDE Gutachten mit Fertigungsüberwachung
Search.aspx 40020343
http://www.vde.com/en/Institute/OnlineService/VDE-approved-products/Pages/Online-
cUL Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
IECEE CB Scheme
http://www.iecee.org/ DE1-51128
CCA DE1 34215
EAC B.01742
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
