SSL22 - SSL24
Taiwan Semiconductor
2A, 20V - 40V Surface Mount Schottky Barrier Rectifier
FEATURES
●
●
●
●
●
Low power loss, high efficiency
Ideal for automated placement
Guard ring for over-voltage protection
High surge current capability
Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
● Halogen-free according to IEC 61249-2-21
KEY PARAMETERS
PARAMETER
I
F(AV)
V
RRM
T
J MAX
Package
Configuration
VALUE
2
20 - 40
125
UNIT
A
V
°C
DO-214AA (SMB)
Signal Die
APPLICATIONS
●
●
●
●
Switching mode power supply (SMPS)
Adapters
Monitor
TV
MECHANICAL DATA
●
●
●
●
●
●
●
●
●
Case: DO-214AA (SMB)
Molding compound meets UL 94V-0 flammability rating
Part no. with suffix “H” means AEC-Q101 qualified
Packing code with suffix "G" means green compound
(halogen-free)
Moisture sensitivity level: level 1, per J-STD-020
Terminal: Matte tin plated leads, solderable per J-STD-002
Meet JESD 201 class 2 whisker test
Polarity: As marked
Weight: 0.093 g (approximately)
DO-214AA (SMB)
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25°C unless otherwise noted)
PARAMETER
Marking code on the device
Repetitive peak reverse voltage
Reverse voltage, total rms value
Maximum DC blocking voltage
Forward current
Surge peak forward current, 8.3 ms single half sine-
wave superimposed on rated load per diode
Junction temperature
Storage temperature
V
RRM
V
R(RMS)
V
DC
I
F(AV)
I
FSM
T
J
T
STG
SYMBOL
SSL22
SL22
20
14
20
SSL23 SSL24
SL23
30
21
30
2
80
- 55 to +125
- 55 to +150
SL24
40
28
40
V
V
V
A
A
°C
°C
UNIT
1
Version:K1706
SSL22 - SSL24
Taiwan Semiconductor
THERMAL PERFORMANCE
PARAMETER
Junction-to-ambient thermal resistance
Junction-to-lead thermal resistance
SYMBOL
R
ӨJA
R
ӨJL
LIMIT
70
25
UNIT
°C/W
°C/W
ELECTRICAL SPECIFICATIONS
(T
A
= 25°C unless otherwise noted)
PARAMETER
Forward voltage per diode
(1)
(2)
CONDITIONS
I
F
= 2A,T
J
= 25°C
T
J
=25°C
SSL22
SSL23
SSL24
T
J
=100°C
SYMBOL
V
F
I
R
I
R
TYP
-
-
-
-
MAX
0.41
0.4
50
60
UNIT
V
mA
mA
mA
Reverse current @ rated V
R
per diode
Reverse current @ rated V
R
per diode
(2)
Notes:
1. Pulse test with PW=0.3 ms
2. Pulse test with PW=30 ms
ORDERING INFORMATION
PART NO.
PART NO.
SUFFIX(*)
H
PACKING
CODE
R5
SSL2x
(Note 1)
R4
M4
Note:
1. "x" defines voltage from 20V (SSL22) to 40V (SSL24)
*: Optional available
G
PACKING CODE
SUFFIX(*)
PACKAGE
SMB
SMB
SMB
PACKING
850 / 7" Plastic reel
3,000 / 13" Paper reel
3,000 / 13" Plastic reel
EXAMPLE P/N
EXAMPLE P/N
SSL24HR5G
PART NO.
SSL24
PART NO.
SUFFIX
H
PACKING
CODE
R5
PACKING CODE
SUFFIX
G
DESCRIPTION
AEC-Q101 qualified
Green compound
2
Version:K1706
SSL22 - SSL24
Taiwan Semiconductor
CHARACTERISTICS CURVES
(T
A
= 25°C unless otherwise noted)
Fig.1 Forward Current Derating Curve
3
AVERAGE FORWARD CURRENT (A)
1000
Fig.2 Typical Junction Capacitance
CAPACITANCE (pF)
2
100
1
RESISTIVE OR
INDUCTIVE LOAD
f=1.0MHz
Vslg=50mVp-p
10
0
25
50
75
100
125
0.1
1
10
100
LEAD TEMPERATURE (
°
C)
REVERSE VOLTAGE (V)
Fig.3 Typical Reverse Characteristics
INSTANTANEOUS REVERSE CURRENT (mA)
INSTANTANEOUS FORWARD CURRENT (A)
1000
10 10
Fig.4 Typical Forward Characteristics
100
T
J
=100
o
C
1
UF1DLW
T
J
=125°C
0.01
Pulse width
Pulse width=300μs
1% duty cycle
0.8
0.9
1
1.1
1
1.2
1.4
1.6
1
T
J
=25
o
C
0.001
0.1
0
0.3
0.4
0.2
0.5
0.4
0.6
0.6
0.7
0.8
0.1
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
1.2
FORWARD VOLTAGE (V)
3
Version:K1706
(A)
10
T
J
=75
o
C
0.1
1
T
J
=25°C
SSL22 - SSL24
Taiwan Semiconductor
CHARACTERISTICS CURVES
(T
A
= 25°C unless otherwise noted)
Fig.5 Maximum Non-repetitive Forward Surge Current
PEAK FORWARD SURGE CURRENT (A)
100
8.3ms Single Half Sine-Wave
80
60
40
20
0
1
10
100
NUMBER OF CYCLES AT 60 Hz
4
Version:K1706
