BD35605HFN-TR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> BD35605HFN-TR

BD35605HFN-TR: DescriptionLDO Voltage Regulators Reg IC for Micro computer Output; CategoryPower/power management The power supply circuit; File Size794KB，12 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BD35605HFN-TR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BD35605HFN-TR	-	-	View	Buy Now

BD35605HFN-TR Overview

LDO Voltage Regulators Reg IC for Micro computer Output

BD35605HFN-TR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SON
package instruction	HVSON, FL8,.12,25
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Adjustability	FIXED
Nominal dropback voltage 1	1.2 V
Maximum absolute input voltage	30 V
Maximum input voltage	25 V
Minimum input voltage	6.2 V
JESD-30 code	R-PDSO-N8
length	2.9 mm
Number of functions	1
Output times	1
Number of terminals	8
Working temperatureTJ-Max	100 °C
Working temperature TJ-Min
Maximum output current 1	0.1 A
Maximum output voltage 1	5.075 V
Minimum output voltage 1	4.925 V
Nominal output voltage 1	5 V
Package body material	PLASTIC/EPOXY
encapsulated code	HVSON
Encapsulate equivalent code	FL8,.12,25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
method of packing	TAPE AND REEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	0.6 mm
surface mount	YES
technology	CMOS
Terminal form	NO LEAD
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	1.5%
width	2.8 mm

Preview

Download Datasheet

View All

TECHNICAL NOTE

High-performance Regulator IC Series for PCs

100mA Linear Regulators

for Note PC

BD35602F/HFN/HFV, BD35603F/HFN/HFV, BD35605F/HFN/HFV

●Description

BD3560□ series is a LDO regulator with output current 100mA. The output accuracy is±1% of output voltage. BD3560

□

series have some kinds of output voltage line-up and package line-up. Thus, it is used for the wide applications of

digital appliances. Over current protection (for protecting the IC destruction by output short circuit), shutdown ON/OFF

switch (for setting the circuit current 0μA at shutdown mode), and thermal shutdown circuit (for protecting ICs from heat

destruction by over load condition) are all built in.

●Features

1) Output current 100mA

2) Output voltage accuracy :

±1%

3) Built-in Over Current Protection circuit (OCP)

4) Built-in Thermal Shut Down circuit (TSD)

5) With shut down switch

6) Rich package line-up : HVSOF6, HSON8, SOP8

●Line-up

Product name

BD3560□HFV

BD3560□HFN

BD3560□F

1.8V

○

5.0V

○

3.3V

○

Package

HVSOF6

HSON8

SOP8

Product name : BD3560□

□□□

Symbol

0□

Output Voltage (V)

1.8V typ.

5.0V typ.

3.3V typ.

□□□

HFV

HFN

Package

HVSOF6

SOP8

HSON8

Oct. 2008
