Type LPX
85 ºC Radial Snap-In Aluminum Electrolytic Capacitors
High Voltage, High Value Radial Leaded Snap-In
Type LPX radial leaded snap-in aluminum electrolytic
capacitors are a compact design for high density pack-
aging and are ideal for high voltage, switch mode power
supply input filtering applications.
•
•
•
•
•
Capacitance Range:
Voltage Range:
Tolerance:
Operating Temperature Range:
Dissipation Factor:
Complies with the EU Directive
2002/95/EC requirement restricting
the use of Lead (Pb), Mercury (Hg),
Cadmium (Cd), Hexavalent chromium
(Cr(VI)), PolyBrominated Biphenyls
(PBB) and PolyBrominated Diphenyl
Ethers (PBDE).
Highlights
Specifications
High voltage
High Capacitance
85 ºC
Good for input filtering in consumer applications
22 to 35 mm diameter with 10 mm lead spacing
56 to 2,700 µF
160 to 450 Vdc
±20%
–40 ºC to +85 ºC
DF at 120 Hz, +25 ºC
Vdc
DF (%)
160 -250
30
400 - 450
25
For values that are >1000 µF, the DF (%) increases
2% for every additional 1000 µF
DC Leakage Test:
I = 3√CV
C = capacitance in µF
V = rated voltage
I = leakage current in µA
Rated
Vdc
120 Hz
1.00
1.00
Ripple Multipliers
1 kHz
1.05
1.15
Ripple Multiplier
1.60
2.20
2.60
3.00
Frequency Ripple Multipliers:
10 to 50 kHz
1.10
1.20
160 to 250
315 to 450
Temperature Ripple Multipliers:
Temperature
+75 ºC
+65 ºC
+55 ºC
+55 ºC
Part Numbering System
LPX
471
M
160
C1
Case
P
Polarity
3
Insulating
Sleeve
Type
Cap
Tolerance
Voltage
Diameter
Code
Length
25
A1
C1
E1
H1
30
A3
C3
E3
H3
35
A5
C5
E5
H5
40
A7
C7
E7
H7
45
A4
C4
E4
H4
50
A9
C9
E9
H9
LPX
471 = 470 µF
272 = 2,700 µF
±20%
160 = 160
mm
22 (.87)
25 (1.00)
30 (1.18)
35 (1.38)
(in.)
(1.00) (1.18) (1.38) (1.57) (1.77) (2.00)
P
3 = PVC
CDE Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8561
•
Fax: (508)996-3830
•
www.cde.com
Type LPX
85 ºC Radial Snap-In Aluminum Electrolytic Capacitors
Notice and Disclaimer:
All product drawings, descriptions, specifications, statements, information and
data (collectively, the “Information”) in this datasheet or other publication are subject to change. The
customer is responsible for checking, confirming and verifying the extent to which the Information con-
tained in this datasheet or other publication is applicable to an order at the time the order is placed. All
Information given herein is believed to be accurate and reliable, but it is presented without any guaran-
tee, warranty, representation or responsibility of any kind, expressed or implied. Statements of suitability
for certain applications are based on the knowledge that the Cornell Dubilier company providing such
statements (“Cornell Dubilier”) has of operating conditions that such Cornell Dubilier company regards
as typical for such applications, but are not intended to constitute any guarantee, warranty or representa-
tion regarding any such matter – and Cornell Dubilier specifically and expressly disclaims any guarantee,
warranty or representation concerning the suitability for a specific customer application, use, storage,
transportation, or operating environment. The Information is intended for use only by customers who
have the requisite experience and capability to determine the correct products for their application. Any
technical advice inferred from this Information or otherwise provided by Cornell Dubilier with reference
to the use of any Cornell Dubilier products is given gratis (unless otherwise specified by Cornell Dubilier),
and Cornell Dubilier assumes no obligation or liability for the advice given or results obtained. Although
Cornell Dubilier strives to apply the most stringent quality and safety standards regarding the design
and manufacturing of its products, in light of the current state of the art, isolated component failures may
still occur. Accordingly, customer applications which require a high degree of reliability or safety should
employ suitable designs or other safeguards (such as installation of protective circuitry or redundancies
or other appropriate protective measures) in order to ensure that the failure of an electrical component
does not result in a risk of personal injury or property damage. Although all product-related warnings,
cautions and notes must be observed, the customer should not assume that all safety measures are indi-
cated in such warnings, cautions and notes, or that other safety measures may not be required.
