HA17555 Series
Precision Timer
ADE-204-064 (Z)
Rev. 0
Dec. 2000
Description
HA17555 Series are ICs designed for accurate time delays or oscillations. It provides both of trigger
terminal and reset terminal in order to enable a wide scope of application including Mono Multi Vibrator
and Astable Multi Vibrator, and the number of external components is fewer. Further, it’s compatible with
NE555 of singnetics.
Features
•
•
•
•
•
•
•
•
Mono multi vibrator can be constructed with one resistor and one capacitor.
Astable multi vibrator can be constructed with two resistors and one capacitor.
Delay time can be established widely from several µ seconds to several hours.
Pulse Duty can be controlled.
The maximum value of both sink current and source current is 200mA.
Direct connection of output to TTL is possible.
Temperature/delay time ratio is 50 ppm/°C (typ).
Output is normally in the on and off states.
Ordering Information
Application
Industrial use
Type No.
HA17555PS
HA17555FP
Commercial use
HA17555
HA17555F
Package
DP-8
FP-8D
DP-8
FP-8D
HA17555 Series
Absolute Maximum Ratings
(Ta = 25°C)
Item
Supply voltage
Discharge current
Output source current
Output sink current
Power dissipation*
1
Operating temperature
Storage temperature
Note:
Symbol
V
CC
I
T
Isource
Isink
P
T
Topr
Tstg
HA17555PS/FP
18
200
200
200
600/385
–20 to +75
–55 to +125
HA17555/F
18
200
200
200
600/385
–20 to +70
–55 to +125
Unit
V
mA
mA
mA
mW
°C
°C
1. For the HA17555/PS,
This value applies up to Ta = 50°C; at temperatures above this, 8.3mW/°C derating should be
applied.
For the HA17555F/FP,
This value applies up to Ta = 25°C; at temperatures above this, 3.85mW/°C derating should be
applied.
See notes on SOP Package Usage in Reliability section.
4
HA17555 Series
Maximum Power Dissipation P
T
max (W)
0.7
0.6
0.5
3.85 mW/°C
0.4
0.3
0.2
0.1
b. 0.385 W
a. 0.6 W
8.3 mW/°C
a. HA17555PS
b. HA17555FP
–40 –20 0
20 40 60 70 80 100 120
Ambient Temperature Ta (°C)
Maximum Power Dissipation P
T
max (W)
a. HA17555
b. HA17555F
a. 0.6 W
8.3 mW/°C
3.85 mW/°C
0.4
0.3
0.2
0.1
b. 0.385 W
0.7
0.6
0.5
–40 –20 0
20 40 60 70 80 100 120
Ambient Temperature Ta (°C)
5
