160 CLA
www.vishay.com
Vishay BCcomponents
Aluminum Capacitors
SMD (Chip), High Temperature, Low Impedance
FEATURES
• Polarized aluminum electrolytic capacitors,
non-solid electrolyte, self healing
• SMD-version with base plate, lead (Pb)-free
reflow solderable
• Charge and discharge proof, no peak current
limitation
160 CLA
150 °C
• High temperature reflow soldering according to JEDEC
J-STD-020
• High temperature proof
• Vibration proof, 4-pin version and 6-pin version
Higher temperature
140 CRH
125 °C
Lower Z
Lower Z
Higher I
R
146 CTI
125 °C
• AEC-Q200 qualified
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
150 CRZ
105 °C
APPLICATIONS
Fig. 1
• SMD technology, for high temperature reflow soldering
• High temperature environment, high peak load
QUICK REFERENCE DATA
DESCRIPTION
Nominal case sizes
(L x W x H in mm)
Rated capacitance range, C
R
Tolerance on C
R
Rated voltage range, U
R
Category temperature range
Endurance test at 150 °C
Useful life at 150 °C
Useful life at 40 °C
1.8 x l
R
applied
Shelf life at 0 V, 150 °C
Based on sectional
specification
Climatic category IEC 60068
VALUE
12.5 x 12.5 x 13
to 18 x 18 x 21
100 μF to 3300 μF
± 20 %
16 V to 50 V
- 55 °C to + 150 °C
1000 h to 1500 h
1250 h to 2000 h
300 000 h to 400 000 h
1000 h
IEC 60384-18/CECC 32300
55/150/56
• Automotive, industrial
• Smoothing, filtering, buffering
MARKING
• Rated capacitance (in μF)
• Rated voltage (in V)
• Date code, in accordance with IEC 60062
• Black mark or “-” sign indicating the cathode (the anode is
identified by bevelled edges)
• Code indicating group number (A)
PACKAGING
Supplied in blister tape on reel
Revision: 04-Dec-12
Document Number: 28405
1
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
160 CLA
www.vishay.com
Vishay BCcomponents
SELECTION CHART FOR C
R
, U
R
, AND RELEVANT NOMINAL CASE SIZES
(L x W x H in mm)
C
R
(μF)
100
150
220
330
470
680
1000
1500
2200
2700
3300
U
R
(V)
16
12.5 x 12.5 x 13
12.5 x 12.5 x 13
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
18 x 18 x 21
25
12.5 x 12.5 x 13
12.5 x 12.5 x 13
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
-
-
35
12.5 x 12.5 x 13
12.5 x 12.5 x 13
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
-
-
-
50
12.5 x 12.5 x 13
12.5 x 12.5 x 13
12.5 x 12.5 x 16
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
-
-
-
-
min. 0.4/max. 1.0 (2 x)
4-pin:
Ø 12.5 mm
6-pin:
≥
Ø
16 mm
min. 0.4/max. 1.0 (2 x)
H
MAX.
MAX. 0.3
H
MAX.
MAX. 0.3
25V
2200u
L4-H
W
MAX.
B
35V
1000u
3R-H
D
D
W
MAX.
B
L1
MAX.
S
L
MAX.
L1
MAX.
S
L
MAX.
Fig. 2 - Dimensional outline
Table 1
DIMENSIONS
in millimeters
AND MASS
NOMINAL
CASE SIZE
LxWxH
12.5 x 12.5 x 13
12.5 x 12.5 x 16
16 x 16 x 16
16 x 16 x 21
18 x 18 x 16
18 x 18 x 21
CASE
CODE
1213
1216
1616
1621
1816
1821
L
MAX.
12.9
12.9
16.6
16.6
19.0
19.0
W
MAX.
12.9
12.9
16.6
16.6
19.0
19.0
H
MAX.
14.0
16.5
17.5
22.0
17.5
22.0
ØD
12.5
12.5
16.0
16.0
18.0
18.0
B
MAX.
1.3
1.3
1.3
1.3
1.3
1.3
S
3.6
3.6
6.5
6.5
6.5
6.5
L1
MAX.
14.9
14.9
18.6
18.6
21.0
21.0
MASS
(g)
2.9
3.2
5.8
7.1
8.0
9.3
Revision: 04-Dec-12
Document Number: 28405
2
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
160 CLA
www.vishay.com
Table 2
Vishay BCcomponents
TAPE AND REEL DIMENSIONS
in millimeters,
PACKAGING QUANTITIES
NOMINAL
CASE SIZE
LxWxH
12.5 x 12.5 x 13
12.5 x 12.5 x 16
16 x 16 x 16
16 x 16 x 21
18 x 18 x 16
18 x 18 x 21
CASE
CODE
1213
1216
1616
1621
1816
1821
PITCH
P
1
20
24
28
28
32
32
TAPE WIDTH
W
24
32
44
44
44
44
TAPE
THICKNESS
T
2
16.2
18.5
18.9
23.4
18.9
23.4
REEL DIAMETER
PACKAGING
QUANTITY
PER REEL
250
200
150
100
125
100
380
380
380
380
380
380
Note
• Detailed tape dimensions see section “PACKAGING”
MOUNTING
The capacitors are designed for automatic placement on to
printed-circuit boards.
Optimum dimensions of soldering pads depend amongst
others on soldering method, mounting accuracy, print
layout and/or adjacent components.
For recommended soldering pad dimensions, refer to Fig. 3
and Table 3.
SOLDERING
Soldering conditions are defined by the curve, temperature
versus time, where the temperature is that measured on the
component during processing.
For maximum conditions refer to Fig. 4.
Any temperature versus time curve which does not exceed
the specified maximum curves may be applied.
As a general principle, temperature and duration shall be the
minimum
necessary required to ensure good soldering
connections. However, the specified maximum curves
should never be exceeded.
a
d
b
f
b
d
a
c
a
c
a
e
Case size Ø D = 12.5 mm
Case size Ø D
≥
16 mm
Fig. 3 - Recommended soldering pad dimensions
Table 3
RECOMMENDED SOLDERING PAD DIMENSIONS
in millimeters
CASE CODE
1213
1216
1616
1621
1816
1821
a
6.3
6.3
7.8
7.8
8.8
8.8
b
2.5
2.5
9.6
9.6
9.6
9.6
c
4.0
4.0
4.7
4.7
4.7
4.7
d
4.2
4.2
-
-
-
-
e
5.0
5.0
-
-
-
-
f
5.6
5.6
-
-
-
-
Revision: 04-Dec-12
Document Number: 28405
3
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
160 CLA
www.vishay.com
Vishay BCcomponents
ADVANCED SOLDERING PROFILE FOR LEAD (Pb)-FREE REFLOW PROCESS
ACCORDING TO JEDEC J-STD-020
T (°C)
T
Peak
230
217
200
190
t
2
150
t
1
t
4
t
3
25
time (s)
Fig. 4 - Maximum temperature load during reflow soldering
Table 4
REFLOW SOLDERING CONDITIONS
for MAL216099xxxE3
PROFILE FEATURES
Max. time from 25 °C to T
Peak
Min. ramp-up rate to 150 °C
Max. time from 150 °C to 200 °C (t
1
)
Max. time from 190 °C to 200 °C (t
2
)
Ramp up rate from 200 °C to T
Peak
Max. time above T
Liquidus
(217 °C) (t
3
)
Max. time above 230 °C (t
4
)
Peak temperature T
Peak
Max. time above T
Peak
minus 5 °C
Ramp-down rate from T
Liquidus
Notes
• Temperature measuring point on top of the case and on terminals.
• Max. 2 runs with pause of min. 30 min in between.
CASE CODE
1213 TO 1216
300 s
3 K/s
150 s
110 s
0.5 K/s to 3 K/s
90 s
65 s
250 °C
30 s
3 K/s to 6 K/s
CASE CODE
1616 TO 1821
300 s
3 K/s
150 s
110 s
0.5 K/s to 3 K/s
90 s
60 s
245 °C
30 s
3 K/s to 6 K/s
Revision: 04-Dec-12
Document Number: 28405
4
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
160 CLA
www.vishay.com
Vishay BCcomponents
ORDERING EXAMPLE
Electrolytic capacitor 160 CLA series
220 μF/50 V; ± 20 %
Nominal case size: 12.5 mm x 12.5 mm x 16 mm;
taped on reel
Ordering code: MAL216099103E3
ELECTRICAL DATA
SYMBOL
C
R
I
R
I
L2
tan
Z
DESCRIPTION
Rated capacitance at 100 Hz, tolerance ± 20 %
Rated RMS ripple current at 100 kHz, 150 °C
Max. leakage current after 2 min at U
R
Max. dissipation factor at 100 Hz
Max. impedance at 100 kHz
Note
• Unless otherwise specified, all electrical values in Table 5 apply
at T
amb
= 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
Table 5
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
(μF)
470
680
1000
16
1500
2200
2700
3300
330
470
25
680
1000
1500
2200
220
330
35
470
680
1000
1500
100
150
220
50
330
470
680
1000
NOMINAL
CASE SIZE
LxWxH
(mm)
12.5 x 12.5 x 13
12.5 x 12.5 x 13
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
18 x 18 x 21
12.5 x 12.5 x 13
12.5 x 12.5 x 13
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
12.5 x 12.5 x 13
12.5 x 12.5 x 13
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
12.5 x 12.5 x 13
12.5 x 12.5 x 13
12.5 x 12.5 x 16
16 x 16 x 16
18 x 18 x 16
16 x 16 x 21
18 x 18 x 21
I
R
150 °C
100 kHz
(mA)
750
800
850
900
1100
1350
1400
650
700
800
830
1050
1350
550
650
800
830
1000
1350
420
450
550
700
720
800
1100
I
L2
2 min
(μA)
75
109
160
240
352
432
528
83
118
170
250
375
550
77
116
165
238
350
525
50
75
110
165
235
340
500
tan
100 Hz
0.16
0.16
0.16
0.16
0.18
0.18
0.20
0.14
0.14
0.14
0.14
0.14
0.16
0.12
0.12
0.12
0.12
0.12
0.12
0.10
0.10
0.10
0.10
0.10
0.10
0.10
Z
100 kHz
20 °C
()
0.080
0.080
0.050
0.050
0.035
0.035
0.035
0.080
0.080
0.050
0.050
0.035
0.035
0.080
0.080
0.050
0.050
0.035
0.035
0.130
0.120
0.085
0.072
0.070
0.052
0.049
Z
100 kHz
- 40 °C
()
0.70
0.70
0.45
0.45
0.32
0.32
0.32
0.70
0.70
0.45
0.45
0.32
0.32
0.70
0.70
0.45
0.45
0.32
0.32
1.20
1.10
0.76
0.65
0.63
0.47
0.44
ORDERING
CODE
MAL2160...
99501E3
99502E3
99503E3
99504E3
99505E3
99506E3
99507E3
99601E3
99602E3
99603E3
99604E3
99605E3
99606E3
99001E3
99002E3
99003E3
99004E3
99005E3
99006E3
99101E3
99102E3
99103E3
99104E3
99105E3
99106E3
99107E3
Revision: 04-Dec-12
Document Number: 28405
5
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
