MOSFET
MetalOxideSemiconductorFieldEffectTransistor
OptiMOS
TM
OptiMOS
TM
Power-Transistor,60V
BSZ042N06NS
DataSheet
Rev.2.3
Final
PowerManagement&Multimarket
OptiMOS
TM
Power-Transistor,60V
BSZ042N06NS
1Description
Features
•OptimizedforhighperformanceSMPS,e.g.sync.rec.
•100%avalanchetested
•Superiorthermalresistance
•N-channel
•QualifiedaccordingtoJEDEC
1)
fortargetapplications
•Pb-freeleadplating;RoHScompliant
•Halogen-freeaccordingtoIEC61249-2-21
•Highersolderjointreliabilityduetoenlargedsourceinterconnection
(enlarged source interconnection)
TSDSON-8FL
Table1KeyPerformanceParameters
Parameter
V
DS
R
DS(on),max
I
D
Q
OSS
Q
G
(0V..10V)
Value
60
4.2
40
32
27
Unit
V
mΩ
A
nC
nC
S1
S2
S3
G4
8D
7D
6D
5D
Type/OrderingCode
BSZ042N06NS
Package
PG-TSDSON-8 FL
Marking
042N06N
RelatedLinks
-
1)
J-STD20 and JESD22
Final Data Sheet
2
Rev.2.3,2014-11-10
OptiMOS
TM
Power-Transistor,60V
BSZ042N06NS
TableofContents
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Thermal characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical characteristics diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Package Outlines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Final Data Sheet
3
Rev.2.3,2014-11-10
OptiMOS
TM
Power-Transistor,60V
BSZ042N06NS
2Maximumratings
atT
j
=25°C,unlessotherwisespecified
Table2Maximumratings
Parameter
Symbol
Values
Min.
-
-
-
-
-
-20
-
-
-55
Typ.
-
-
-
-
-
-
-
-
-
Max.
40
40
17
160
130
20
69
2.1
150
Unit
Note/TestCondition
V
GS
=10V,T
C
=25°C
V
GS
=10V,T
C
=100°C
V
GS
=10V,T
C
=25°C,R
thJA
=60K/W
1)
T
C
=25°C
I
D
=20A,R
GS
=25Ω
-
T
C
=25°C
T
A
=25°C,R
thJA
=60K/W
1)
IEC climatic category;
DIN IEC 68-1: 55/150/56
Continuous drain current
Pulsed drain current
2)
Avalanche energy, single pulse
3)
Gate source voltage
Power dissipation
Operating and storage temperature
I
D
I
D,pulse
E
AS
V
GS
P
tot
T
j
,T
stg
A
A
mJ
V
W
°C
3Thermalcharacteristics
Table3Thermalcharacteristics
Parameter
Thermal resistance, junction - case,
bottom
Device on PCB,
6 cm
2
cooling area
1)
Symbol
R
thJC
R
thJA
Values
Min.
-
-
Typ.
1.1
-
Max.
1.8
60
Unit
K/W
K/W
Note/TestCondition
-
-
1)
Device on 40 mm x 40 mm x 1.5 mm epoxy PCB FR4 with 6 cm
2
(one layer, 70 µm thick) copper area for drain
connection. PCB is vertical in still air.
2)
See figure 3 for more detailed information
3)
See figure 13 for more detailed information
Final Data Sheet
4
Rev.2.3,2014-11-10
OptiMOS
TM
Power-Transistor,60V
BSZ042N06NS
4Electricalcharacteristics
Table4Staticcharacteristics
Parameter
Drain-source breakdown voltage
Gate threshold voltage
Zero gate voltage drain current
Gate-source leakage current
Drain-source on-state resistance
Gate resistance
1)
Transconductance
Symbol
V
(BR)DSS
V
GS(th)
I
DSS
I
GSS
R
DS(on)
R
G
g
fs
Values
Min.
60
2.1
-
-
-
-
-
-
27
Typ.
-
2.8
0.5
10
10
3.4
4.9
1.6
54
Max.
-
3.3
1
100
100
4.2
6.3
2.4
-
Unit
V
V
µA
nA
mΩ
Ω
S
Note/TestCondition
V
GS
=0V,I
D
=1mA
V
DS
=V
GS
,I
D
=36µA
V
DS
=60V,V
GS
=0V,T
j
=25°C
V
DS
=60V,V
GS
=0V,T
j
=125°C
V
GS
=20V,V
DS
=0V
V
GS
=10V,I
D
=20A
V
GS
=6V,I
D
=5A
-
|V
DS
|>2|I
D
|R
DS(on)max
,I
D
=20A
Table5Dynamiccharacteristics
1)
Parameter
Input capacitance
Output capacitance
Reverse transfer capacitance
Turn-on delay time
Rise time
Turn-off delay time
Fall time
Symbol
C
iss
C
oss
C
rss
t
d(on)
t
r
t
d(off)
t
f
Values
Min.
-
-
-
-
-
-
-
Typ.
2000
490
22
10
7
19
6
Max.
2500
612.5
44
-
-
-
-
Unit
pF
pF
pF
ns
ns
ns
ns
Note/TestCondition
V
GS
=0V,V
DS
=30V,f=1MHz
V
GS
=0V,V
DS
=30V,f=1MHz
V
GS
=0V,V
DS
=30V,f=1MHz
V
DD
=30V,V
GS
=10V,I
D
=20A,
R
G,ext
,ext=1.7Ω
V
DD
=30V,V
GS
=10V,I
D
=20A,
R
G,ext
,ext=1.7Ω
V
DD
=30V,V
GS
=10V,I
D
=20A,
R
G,ext
,ext=1.7Ω
V
DD
=30V,V
GS
=10V,I
D
=20A,
R
G,ext
,ext=1.7Ω
1)
Defined by design. Not subject to production test.
Final Data Sheet
5
Rev.2.3,2014-11-10
