Line width be designed to match 50Ω characteristic impedance
depending on PCB material and thickness.
RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/
• All specifications are subject to change without notice.
• Before using these products, be sure to request the delivery specifications.
20150601 / rf_lpf_dea161910lt-5003c1_en.fm
0.80
RF Components
DEA161910LT-5003C1
ELECTRICAL CHARACTERISTICS
Item
Insertion Loss (dB)
Return Loss (dB)
Attenuation (dB)
Characteristic Impedance (:)
・Ta:
+25±5°C
Frequency Range
(MHz)
1710 to 1910
1710 to 1910
1710 to 1910
2400 to 2480
3700 to 3820
2400 to 2480
3700 to 3820
Min.
—
—
10.16
15
10
15 (–30 to +80°C)
9 (–30 to +80°C)
Typ.
0.52
—
18.3
21
12
—
—
50 (Nominal)
Max.
0.8
1.0 (–30 to +80°C)
—
—
—
—
—
TEMPERATURE RANGE
Operating temperature
(°C)
–30 to +80
Storage temperature
(°C)
–40 to +85
• All specifications are subject to change without notice.
• Before using these products, be sure to request the delivery specifications.
20150601 / rf_lpf_dea161910lt-5003c1_en.fm
RF Components
DEA161910LT-5003C1
FREQUENCY CHARACTERISTICS
INSERTION LOSS
0.0
0.5
1.0
1.5
Insertion Loss (dB)
2.0
2.5
3.0
3.5
4.0
4.5
5.0
1000
1500
2000
Frequency (MHz)
2500
3000
50
1000
1500
2000
2500
3000
Frequency (MHz)
3500
4000
40
10
ATTENUATION
0
Attenuation(dB)
1500
2000
Frequency (MHz)
2500
3000
20
30
RETURN LOSS
0
5
10
15
Return Loss(dB)
20
25
30
35
40
45
50
1000
• All specifications are subject to change without notice.
• Before using these products, be sure to request the delivery specifications.
20150601 / rf_lpf_dea161910lt-5003c1_en.fm
RF Components
RECOMMENDED REFLOW PROFILE
Preheating
Soldering
Peak
T4
T:
Temperature
3°C/sec
or lower
6°C/sec
or lower
T3
T3
T2
T1
t1
t3
t2
t:
Time
Preheating
Temp.
T1
150°C
t3
T2
200°C
Time
t1
60 to 120sec
Soldering
Critical zone (T3 to T4)
Temp.
Time
T3
t2
217°C
60 to 120sec
Peak
Temp.
T4
240 to 260°C
Time
t3
30sec max.
: Time within 5°C of actual peak temperature
The maximum number of reflow is 3.
• All specifications are subject to change without notice.
• Before using these products, be sure to request the delivery specifications.
