hVc Series
Precision High-Value High-voltage Wraparound Chip
f e at u r e S
• High value chip resistors in thick film technology
• Low temperature and voltage dependency (low TCR and VCR)
• High working voltage up to 3000V
• Suitable for high vacuum applications—no organics
• Contact areas: Nickel-barrier/matte tin
• Wraparound terminals
S e r i e S S p e c i f i c at i o n S
Series
HVC0402---
Type
0402
0603
0805
Wattage
1
P
70
(mW)
50
100
125
HVC0603---
HVC0805---
HVC1206---
1206
250
HVC2512---
2512
1000
HVC4020---
4020
1500
1. At continuous power dissipation the dimensions of the solder pads have to be capable of sufficient heat conduction.
2. Not all TCR/VCR combinations available in all resistance values
3. HVC2512 and HVC4020 10M-10G TCR’s available: 10ppm and 15ppm
Oper. Voltage (V)
Resistance
std. untrimmed (≥5%)
Range
30
60
100k-100M
>100M-1G
>1G-10G
75
150
100k-100M
>100M-1G
>1G-10G
200
400
100K-100M
>100M-1G
>1G-10G
>10G-100G
600
1000
100K-100M
>100M-1G
>1G-10G
>10G-100G
2000
3000
100K-100M
>100M-1G
>1G-10G
>10G-100G
4000
6000
100k-100M
>100M-1G
>1G-10G
>10G-100G
>100G-1T
Tolerance
5-10%
5-20%
10-30%
1-10%
5-20%
5-20%
0.5-10%
2-20%
5-20%
10-30%
0.5-10%
2-20%
5-20%
10-30%
0.5-10%
1-20%
2-20%
5-30%
0.25-10%
0.5-20%
1-20%
2-30%
5-30%
TCR
2,3
(ppm)
50, 100
250, 500
1000, 2000
50, 100
250, 500
500, 1000
25, 50, 100
50, 100, 250
250, 500
1000, 2000
25, 50, 100
50, 100, 250
50, 100, 250
250, 500, 1000
25, 50, 100
25, 50, 100
25, 50, 100
100, 250, 500
25, 50, 100
25, 50, 100
25, 50, 100
50, 100, 250
250/500
VCR
2
(ppm)
500
1000
2000
500
1000
2000
100
250
500
2000
50
100
250
1000
10
25
50
100
5
10
10
50
250
characteriSticS
Operating temperature
-55°C ~ +155°C
range
Climatic category
55/155/56, acc. to EN 60068-1
Solderability
250°C, 3s, acc. to EN 60068-2-58
<1G
<0.25%
<0.5%
<0.5%
<10G
<0.5%
<1%
<1%
≥10G
<1%
<2%
<2%
Derating
100
Percent Rated Power
80
60
40
20
0
-55
Max. soldering temperature
260°C, 10s, acc. to IEC 68-2-58
Long Term Stability
Load Life 70°C/1000h
Storage 125°C/1000h
Max. Voltage/1000h
0
50 70 100
Ambient Temperature,
°C
155
Data not specified according to EN 140401-802 (CECC 40401-802)
20
1-866-9-OHMITE • Int’l 1-847-258-0300 • Fax 1-847-574-7522 • www.ohmite.com • info@ohmite.com
hVc Series
Precision High-Value High-voltage Wraparound Chip
t e r m i n a l d e ta i l S
Barrier Material between Base Metal and Finish
Porosity-free Ni (5-8 microns thickness)
Peak Process Body Temperature (Classification
260°C for 10 seconds
Temperature) and Maximum Time
dimenSionS
(mm)
Thickness of Finish
5 microns
Termination Finish
100% electroplated matte Sn100
Base Metal
PdAg
Baking/Annealing Process after Sn Plating
150°C; > 4 hours
W
L
a
T
Size
0402
0603
0805
1206
2512
4020
Power
Rating (mW)
L
50
1.04 ±.05
100
1.50 +.15/-.05
125
2.00 +.15/-.05
250
3.20 +.15/-.05
1000
6.30 +.15/-.05
1500
10.20 +.20/-.05
W
0.50 ±.05
0.80 +.15/-.05
1.25 +.15/-.05
1.50 +.2/-.05
3.50 +.2/-.05
5.10 +.2/-.05
T
0.30 ±.05
0.40 +.15/-.05
0.40 +.15/-.05
0.40 +.15/-.05
0.60 +.15/-.05
0.60 +.20/-.1
a
0.1 +.1/-.05
0.2 +.2/-.1
0.3 +.2/-.1
0.3 +.2/-.1
0.9 ±.2
0.9 ±.2
hoW to order
RoHS Compliant
HVC1206T1004JET
Series
Package
High Voltage
Size
Wrap Around Chip
(ppm)
TCR
W = 25
V = 50
T = 100
Z = 250
E = 500
N = 1000
U = 2000
Tolerance Tape & Reel
Ohms
D =0.50% 500 pc/reel
1004 = 1MΩ
5006 = 500MΩ F = 1%
G = 2%
J = 5%
K = 10%
M = 20%
P = 30%
Standard Part Numbers
HVC0402E5006KET
HVC0402N5007KET
HVC0402T1004JET
HVC0402T1005JET
HVC0402T1006JET
HVC0402T2504JET
HVC0402T2505JET
HVC0402Z2506JET
HVC0402T5004JET
HVC0402T5005JET
HVC0603N1007KET
HVC0603N5007KET
HVC0603T1004FET
HVC0603T1005FET
HVC0603T1006FET
HVC0603T2504FET
HVC0603T2505FET
HVC0603T5004FET
HVC0603T5005FET
HVC0603Z5006JET
HVC0805E1008KET
HVC0805T1004JET
HVC0805T1005JET
HVC0805T1006JET
HVC0805T2504JET
HVC0805T2505JET
HVC0805Z2506JET
HVC0805T5004JET
HVC0805T5005JET
HVC0805E5007JET
HVC0805Z1007JET
HVC0805Z5006JET
HVC1206T1004JET
HVC1206T1005JET
HVC1206T1006JET
HVC1206Z2504JET
HVC1206T2505JET
HVC1206Z2506JET
HVC1206T5004JET
HVC1206T5005JET
HVC1206Z5007KET
HVC1206Z1007JET
HVC1206Z1008KET
HVC1206Z5006JET
HVC2512T1004JET
HVC2512T1005JET
HVC2512T1006JET
HVC2512T1007JET
HVC2512T1008KET
HVC2512T2504JET
HVC2512T2505JET
HVC2512T2506JET
HVC2512T5004JET
HVC2512T5005JET
HVC2512T5006JET
HVC2512T5007JET
HVC4020V1004JET
HVC4020V1005JET
HVC4020V1006JET
HVC4020V1007JET
HVC4020V1008KET
HVC4020V2504JET
HVC4020V2505JET
HVC4020V2506JET
HVC4020Z2508KET
HVC4020V5004JET
HVC4020V5005JET
HVC4020V5006JET
HVC4020V5007JET
