SFBD
Filter Type
Feedthrough EMI Filter Datasheet
(12-32 UNEF Tread : 4.75mm Hexagonal Head)
Circuit Configurations Available
Electrical Details
Electrical Configuration
Capacitance Measurement
Current Rating
Insulation Resistance (IR)
Temperature Rating
Ferrite Inductance (Typical)
Body Flange Diameter
Head A/F
Nut A/F
Washer Diameter
Mounting Torque
Mounting Hole Diameter
Max. Panel Thickness
Weight (Typical)
Finish
C Filter
@ 1000hr Point
10A
10G or 1000F
-55
o
C to +125
o
C
See relevant tables
6.35mm
(0.250")
4.75mm
(0.187")
7.92mm
(0.312")
11.35mm
(0.447")
0.6Nm
(5.31lbf in)
max. if using nut
0.3Nm
(2.65lbf in)
max. into tapped
hole
5.7mm
0.1
(0.224"
0.004")
4.9mm
(0.193")
1.5g
(0.05oz)
Silver plate on copper undercoat
Mechanical Details
12-32 UNEF Class 2A Thread
C Configuration
Typical Insertion Loss (db)
Hardware
(Nuts &
Washers
etc.)
0.01MHz
Product Code
Capacitance
20% UOS
Dielectric
Rated
Voltage
(dc)
100MHz
0.1MHz
10MHz
1MHz
DWV
(dc)
* SFBDC5000100ZC
SFBDC5000150ZC
SFBDC5000220ZC
SFBDC5000330ZC
* SFBDC5000470ZC
* SFBDC5000680MC
* SFBDC5000101MC
1 = supplied with standard nut and wavy washer
Other options available – please contact factory
SFBDC5000151MC
* SFBDC5000221MC
* SFBDC5000331MC
* SFBDC5000471MX
SFBDC5000681MX
* SFBDC5000102MX
SFBDC5000152MX
* SFBDC5000222MX
SFBDC5000332MX
* SFBDC5000472MX
SFBDC5000682MX
* SFBDC5000103MX
* SFBDC5000153MX
* SFBDC5000223MX
SFBDC5000333MX
* SFBDC2000473MX
SFBDC2000683MX
*SFBDC1000104MX
* SFBDC0500154MX
0 = No hardware supplied
10pF -20% / +80%
15pF -20% / +80%
22pF -20% / +80%
33pF -20% / +80%
47pF -20% / +80%
68pF
100pF
150pF
220pF
330pF
470pF
680pF
1.0nF
1.5nF
2.2nF
3.3nF
4.7nF
6.8nF
10nF
15nF
22nF
33nF
47nF
68nF
100nF
150nF
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
† X7R
† X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
200
200
100
50
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
500
500
250
125
1
2
4
7
1
2
4
7
10
13
16
19
22
25
1
2
4
7
10
13
16
19
22
25
29
33
35
39
41
45
1
2
4
7
10
13
16
19
23
26
30
33
36
39
41
44
46
48
50
54
57
60
10
12
15
18
22
25
29
33
35
36
41
45
50
52
55
57
60
62
65
68
70
70
70
70
# - Also rated for operation at 115Vac 400Hz. Self-heating will occur – evaluation in situ recommended
* Recommended values
†
Also available in C0G
Syfer Technology Ltd.
Old Stoke Road, Arminghall
Norwich, Norfolk, NR14 8SQ
United Kingdom
Tel: +44 1603 723300 | Email sales@syfer.co.uk | www.syfer.com
SFBD Issue 2 (P108893) Release Date 04/03/14
Page 1 of 6
1GHz
4
7
T Configuration
Ferrite Inductance (Typical) – 450nH
0.01MHz
Typical Insertion Loss (db)
Product Code
Hardware
Capacitance
20% UOS
Dielectric
Rated
Voltage
(dc)
100MHz
0.1MHz
10MHz
1MHz
DWV
(dc)
* SFBDT5000100ZC
SFBDT5000150ZC
SFBDT5000220ZC
SFBDT5000330ZC
* SFBDT5000470ZC
* SFBDT5000680MC
* SFBDT5000101MC
Other options available – please contact factory
SFBDT5000151MC
* SFBDT5000221MC
* SFBDT5000331MC
* SFBDT5000471MX
SFBDT5000681MX
* SFBDT5000102MX
SFBDT5000152MX
* SFBDT5000222MX
SFBDT5000332MX
* SFBDT5000472MX
SFBDT5000682MX
* SFBDT5000103MX
* SFBDT5000153MX
* SFBDT5000223MX
SFBDT5000333MX
* SFBDT2000473MX
SFBDT2000683MX
* SFBDT1000104MX
* SFBDT0500154MX
0 = No hardware supplied
1 = supplied with standard nut and wavy washer
10pF -20% / +80%
15pF -20% / +80%
22pF -20% / +80%
33pF -20% / +80%
47pF -20% / +80%
68pF
100pF
150pF
220pF
330pF
470pF
680pF
1.0nF
1.5nF
2.2nF
3.3nF
4.7nF
6.8nF
10nF
15nF
22nF
33nF
47nF
68nF
100nF
150nF
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
C0G
† X7R
† X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
500#
200
200
100
50
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
750
500
500
250
125
1
2
4
7
1
4
7
10
14
17
20
22
25
1
2
4
7
10
13
17
19
23
26
29
33
36
39
42
46
49
1
2
4
6
9
12
15
19
21
24
28
30
34
38
40
43
45
47
49
50
52
57
62
68
11
14
18
20
23
27
30
33
36
40
43
47
50
53
57
59
63
66
68
70
>70
>70
>70
>70
>70
# - Also rated for operation at 115Vac 400Hz. Self-heating will occur – evaluation in situ recommended
* Recommended values
†
Also available in C0G
Ordering Information
Type
SF
Syfer Filter
Case Style
B
4.75mm
Hex Head
Thread
D
12-32
UNEF
Electrical
configuration
C
C = C Filter
L = L-C Filter
P = Pi Filter
T = T Filter
Voltage
(dc)
500
050 = 50V
100 = 100V
200 = 200V
500 = 500V
Capacitance in
picofarads (pF)
0102
First digit is 0. Second and
third digits are significant
figures of capacitance code.
The fourth digit is the number
of zeros following.
Examples: 0101 = 100pF
0332 = 3300pF
Note: The addition of a 4-digit numerical suffix code can be used to denote changes to the standard part.
Options include for example: change of pin length / custom body dimensions or threads / alternative voltage rating / non-standard intermediate capacitance values / test
requirements.
Please refer specific requests to the factory.
Capacitance Tolerance
M
M =
20%
Z = -20+80%
Dielectric
X
C = C0G/NP0
X = X7R
Hardware
0
0 = Without
1 = With
Syfer Technology Ltd.
SFBD Issue 2 (P108893) Release Date 04/03/14
Page 4 of 6
1GHz
9
Surface Mount and Panel Mount Solder-in filters
Solder pad layouts are included with the detailed information
for each part.
Recommended soldering profile
E01, E03, E07 SBSP ranges are compatible with all standard
solder types including lead-free, maximum temperature
260°C. For SBSG, SBSM and SFSS ranges, solder time should
be minimised, and the temperature controlled to a maximum
of 220°C. For SFSR, SFST and SFSU ranges the maximum
temperature is 250°C.
Cooling to ambient temperature should be allowed to occur
naturally. Natural cooling allows a gradual relaxation of
thermal mismatch stresses in the solder joints. Draughts
should be avoided. Forced air cooling can induce thermal
breakage, and cleaning with cold fluids immediately after a
soldering process may result in cracked filters.
Note: The use of FlexiCap™ terminations is strongly
recommended to reduce the risk of mechanical cracking.
Soldering to axial wire leads
Soldering temperature
The tip temperature of the iron should not exceed 300°C.
Dwell time
Soldering of filters
The soldering process should be controlled such that the filter
does not experience any thermal shocks which may induce
thermal cracks in the ceramic dielectric.
The pre-heat temperature rise of the filter should be kept to
around 2°C per second. In practice successful temperature
rises tend to be in the region of 1.5°C to 4°C per second
dependent upon substrate and components.
The introduction of a soak after pre-heat can be useful as it
allows temperature uniformity to be established across the
substrate thus preventing substrate warping. The magnitude
or direction of any warping may change on cooling imposing
damaging stresses upon the filter.
Dwell time should be 3-5 seconds maximum to minimise the
risk of cracking the capacitor due to thermal shock.
Heat sink
Where possible, a heat sink should be used between the solder
joint and the body, especially if longer dwell times are
required.
Bending or cropping of wire leads
Bending or cropping of the filter terminations should not be
carried out within 4mm (0.157”) of the epoxy encapsulation,
the wire should be supported when cropping.
Soldering irons should not be used for mounting surface
mount filters as they can result in thermal shock
damage to the chip capacitor.
A more comprehensive application note covering
installation of all Syfer products is available on the Syfer
website.
