DATA SHEET
SURFACE-MOUNT CERAMIC
MULTILAYER CAPACITORS
Mid-voltage
NP0/X7R
100 V TO 630 V
0.47 pF to 2.2 µF
RoHS compliant & Halogen Free
Product Specification – September 14, 2017 V.20
Product specification
2
18
Surface-Mount Ceramic Multilayer Capacitors
SCOPE
This specification describes Mid-
voltage NP0/X7R series chip
capacitors with lead-free
terminations.
APPLICATIONS
PCs, Hard disk, Game PCs
Power supplies
LCD panel
ADSL, Modem
FEATURES
Supplied in tape on reel
Nickel-barrier end termination
RoHS compliant
Halogen Free compliant
Mid-voltage
NP0
/
X7R
100 V to 630 V
ORDERING INFORMATION - GLOBAL PART NUMBER, PHYCOMP
CTC & 12NC
All part numbers are identified by the series, size, tolerance, TC material,
packing style, voltage, process code, termination and capacitance value.
YAGEO BRAND ordering code
GLOBAL PART NUMBER (
PREFERRED
)
CC
XXXX X X XXX X
B
X XXX
(1)
(2) (3) (4)
(5)
(6) (7)
(1) SIZE – INCH BASED (METRIC)
0201 (0603) / 0402 (1005) / 0603 (1608) / 0805 (2012) / 1206 (3216) / 1210 (3225)
1808 (4520) / 1812 (4532)
(2) TOLERANCE
C = ± 0.25 pF
D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
(3) PACKING STYLE
R = Paper/PE taping reel; Reel 7 inch
K = Blister taping reel; Reel 7 inch
P = Paper/PE taping reel; Reel 13 inch
F = Blister taping reel; Reel 13 inch
C = Bulk case
(4) TC MATERIAL
NPO
X7R
(5) RATED VOLTAGE
0 = 100 V
A = 200 V
Y = 250 V
B = 500 V
Z = 630 V
(6) PROCESS
N = NP0
B = Class 2 MLCC
(7) CAPACITANCE VALUE
2 significant digits+number of zeros
The 3rd digit signifies the multiplying factor, and letter R is decimal point
Example: 121 = 12 x 10
1
= 120 pF
www.yageo.com
Sep. 14, 2017 V.20
Product specification
3
18
Surface-Mount Ceramic Multilayer Capacitors
CONSTRUCTION
The capacitor consists of a
rectangular block of ceramic
dielectric in which a number of
interleaved metal electrodes are
contained. This structure gives
rise to a high capacitance per
unit volume.
The inner electrodes are
connected to the two end
terminations and finally covered
with a layer of plated tin (NiSn).
The terminations are lead-free. A
cross section of the structure is
shown in Fig.1.
Mid-voltage
NP0
/
X7R
100 V to 630 V
Fig. 1
Surface mounted multilayer ceramic capacitor construction
DIMENSION
Table 1
For outlines see fig. 2
L
2
/ L
3
(mm)
L
4
(mm)
min.
max.
min.
0.10
0.15
0.20
0.20
0.30
0.60
0.20
0.40
0.40
OUTLINES
T (MM)
0.3± 0.03
0.5 ± 0.05
0.8 ± 0.10
0.6 ± 0.10
For dimension see Table 1
TYPE
0201
0402
0603
0805
L
1
(mm)
0.6 ± 0.03
1.0 ± 0.05
1.6 ± 0.10
W (mm)
0.3± 0.03
0.5 ± 0.05
0.8 ± 0.10
2.0 ± 0.20
1.25 ± 0.20
0.85 ± 0.10
1.25 ± 0.20
0.6 ± 0.10
0.25
0.75
0.70
Fig. 2
Surface mounted multilayer
ceramic capacitor dimension
1206
3.2 ± 0.30
1.6 ± 0.20
0.85 ± 0.10
1.25 ± 0.20
1.6 ± 0.20
0.25
0.75
1.40
3.2 ± 0.30
1.6 ± 0.30
1.6 ± 0.30
0.85 ± 0.10
1210
3.2 ± 0.30
2.5 ± 0.20
1.25 ± 0.20
2.0 ± 0.20
0.25
0.75
1.40
1808
4.5 ± 0.40
2.0 ± 0.30
1.25 ± 0.20
0.85 ± 0.10
0.25
0.75
2.20
1812
4.5 ± 0.40
3.2 ± 0.30
1.25 ± 0.20
1.6 ± 0.20
0.25
0.75
2.20
www.yageo.com
Sep. 14, 2017 V.20
Product specification
4
18
Surface-Mount Ceramic Multilayer Capacitors
CAPACITANCE RANGE & THICKNESS FOR NP0
Table 2
Sizes from 0201 to 0805
0201
0402
0603
CAP.
100V
0.22 pF
0.47 pF
0.56 pF
0.68 pF
0.82 pF
1.0 pF
1.2 pF
1.5 pF
1.8 pF
2.2 pF
2.7 pF
3.3 pF
3.9 pF
4.7 pF
5.6 pF
6.8 pF
8.2 pF
10 pF
12 pF
15 pF
18 pF
22 pF
27 pF
33 pF
39 pF
47 pF
56 pF
68 pF
82 pF
100 pF
NOTE
Mid-voltage
NP0
/
X7R
100 V to 630 V
0805
250 V
100 V
200 V
250 V
500 V
630V
100V
100 V
200 V
0.3± 0.03
0.5± 0.05
0.8± 0.1
0.8± 0.1
0.8± 0.1
0.6± 0.1
0.6± 0.1
0.6± 0.1
0.6± 0.1
0.6± 0.1
1. Values in shaded cells indicate thickness class in mm
2. Capacitance value of non E-12 series is on request
www.yageo.com
Sep. 14, 2017 V.20
Product specification
5
18
Surface-Mount Ceramic Multilayer Capacitors
CAPACITANCE RANGE & THICKNESS FOR NP0
Table 4
Sizes from 0603 to 0805 (continued)
0603
CAP.
100 V
120 pF
150 pF
180 pF
220 pF
270 pF
330 pF
390 pF
470 pF
560 pF
680 pF
820 pF
1.0 nF
1.2 nF
1.5 nF
1.8 nF
2.2 nF
2.7 nF
3.3 nF
3.9 nF
4.7 nF
5.6 nF
6.8 nF
8.2 nF
10 nF
12 nF
15 nF
18 nF
22 nF
NOTE
Mid-voltage
NP0
/
X7R
100 V to 630 V
0805
100 V
200 V
250 V
500 V
630 V
200 V
250 V
0.6± 0.1
0.6± 0.1
0.6± 0.1
0.6± 0.1
0.8± 0.1
0.8± 0.1
0.8± 0.1
0.6± 0.1
0.85± 0.1
0.85± 0.1
0.85± 0.1
0.85± 0.1
1.25± 0.2
1.25± 0.2
0.85± 0.1
1.25± 0.2
1.25± 0.2
1.25± 0.2
1. Values in shaded cells indicate thickness class in mm
2. Capacitance value of non E-12 series is on request
www.yageo.com
Sep. 14, 2017 V.20
