BAT14-034

Description
Mixer Diode, Medium Barrier, S Band, 6.5dB Noise Figure, Silicon,
CategoryDiscrete semiconductor    diode
File Size47KB,3 Pages
ManufacturerInfineon
Websitehttp://www.infineon.com/
Download Datasheet Parametric View All

BAT14-034 Overview

Mixer Diode, Medium Barrier, S Band, 6.5dB Noise Figure, Silicon,

BAT14-034 Parametric

Parameter NameAttribute value
MakerInfineon
Reach Compliance Codecompliant
ECCN codeEAR99
ConfigurationSINGLE
Maximum diode capacitance0.35 pF
Diode component materialsSILICON
Diode typeMIXER DIODE
frequency bandS BAND
JESD-30 codeO-LXMW-G2
maximum noise index6.5 dB
Number of components1
Number of terminals2
Maximum operating frequency4 GHz
Minimum operating frequency2 GHz
Package body materialGLASS
Package shapeROUND
Package formMICROWAVE
Certification statusNot Qualified
surface mountYES
technologySCHOTTKY
Terminal formGULL WING
Terminal locationUNSPECIFIED
Schottky barrier typeMEDIUM BARRIER
Base Number Matches1
Silicon Schottky Diodes
q
q
q
BAT 14- … 4
Medium barrier diodes for detector and mixer
applications
Hermetical ceramic package
For frequencies up to 40 GHz
ESD: Electrostatic discharge
sensitive device, observe handling precautions!
Type
BAT 14-014
BAT 14-034
BAT 14-044
BAT 14-064
BAT 14-074
BAT 14-094
BAT 14-104
BAT 14-114
BAT 14-124
Frequency
band (GHz)
… 4 (S)
… 8 (C)
… 12 (X)
… 18 (Ku)
… 40 (Ka)
Ordering Code
Q62702-D1005
Q62702-D1019
Q62702-D1026
Q62702-D1036
Q62702-D1041
Q62702-D1051
Q62702-D1056
Q62702-D1061
Q62702-D1066
Pin Configuration
Cathode: black dot,
heat sink
Package
1)
T1
Maximum Ratings
Parameter
Reverse voltage
Forward current BAT 14-014 … BAT 14-064
BAT 14-074 … BAT 74-124
Junction temperature
Storage temperature range
Operating temperature range
Symbol
V
R
I
F
T
j
T
stg
T
op
Values
3
100
50
175
– 65 … + 150
– 65 … + 150
Unit
V
mA
˚C
1)
For detailed information see chapter Package Outlines.
