March, 12th 2012
Automotive grade
AUIPS6041(G)(R)(S)
INTELLIGENT POWER HIGH SIDE SWITCH
Features
Over temperature shutdown (with auto-restart)
Short circuit protection (current limit)
Reverse battery protection (turns On the MOSFET)
Full diagnostic capability (short circuit to battery)
Active clamp
Open load detection in On and Off state
Ground loss protection
Logic ground isolated from power ground
ESD protection
Lead Free and RoHS compliant
Product Summary
Rds(on)
Vclamp
I Limit
Open load
Packages
130m max.
39V
7A
3V / 0.22A
Description
The AUIPS6041(G)(R)(S) is a five terminal Intelligent Power
Switch (IPS) for use in a high side configuration. It features
short circuit, over-temperature, ESD protection, inductive load
capability and diagnostic feedback. The output current is
limited to the Ilim value. The current limitation is activated until
the thermal protection acts. The over-temperature protection
turns off the device if the junction temperature exceeds the
Tshutdown value. It will automatically restart after the junction
has cooled 7°C below the Tshutdown value. The reverse
battery protection turns On the MOSFET. A diagnostic pin
provides different voltage levels for each fault condition. The
double level shifter circuitry will allow large offsets between
the logic and load ground.
SO8
AUIPS6041G
D-Pak
AUIPS6041R
TO220
AUIPS6041
D2Pak
AUIPS6041S
Typical Connection
+5V
+Bat
Vcc(5-6-7-8)
Dg(3)
Control
Rdgs
In(2)
V Diag
Rin
Input Signal
Load
Gnd(1)
Out(4)
Pull-up resistors required for
open load off and short
circuit to Vbat detection
Rdgp
www.irf.com
1
AUIPS6041(G)(R)(S)
Qualification Information
†
Qualification Level
Automotive
††
(per AEC-Q100 )
Comments: This family of ICs has passed an Automotive qualification. IR’s
Industrial and Consumer qualification level is granted by extension of the higher
Automotive level.
MSL1, 260°C
D2PAK-5L
(per IPC/JEDEC J-STD-020)
TO-220
Moisture Sensitivity Level
DPAK-5L
SOIC-8L
Machine Model
Human Body Model
ESD
Charged Device Model
(SOIC, DPAK,D2PAK)
Charged Device Model
(TO220)
Not applicable
(non-surface mount package style)
MSL1, 260°C
(per IPC/JEDEC J-STD-020)
MSL2, 260°C
(per IPC/JEDEC J-STD-020)
Class
M2 (+/-150V)
(per AEC-Q100-003)
†††
Class
H1C (+/-1500V)
(per AEC-Q100-002)
†††
Class
C4 (+/-900V)
(per AEC-Q100-011)
†††
Class
C3B (+/-750V)
(per AEC-Q100-011)
Class
II,
Level
A
(per AEC-Q100-004)
Yes
†††
IC Latch-Up Test
RoHS Compliant
†
††
†††
Qualification standards can be found at International Rectifier’s web site
http://www.irf.com/
Exceptions to AEC-Q100 requirements are noted in the qualification report.
Passing voltage level
www.irf.com
2
AUIPS6041(G)(R)(S)
Absolute Maximum Ratings
Absolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage parameters
are referenced to Ground lead. Tj= -40°C..150°C, Vcc=6..35V (unless otherwise specified).
Symbol
Vout
Voffset
Vin
Vcc max.
Vcc cont.
Iin max.
Idg max.
Vdg
Pulse 2a max
Pd
Tj max.
Parameter
Maximum output voltage
Maximum logic ground to load ground offset
Maximum input voltage
Maximum Vcc voltage
Maximum continuous Vcc voltage
Maximum IN current
Maximum diagnostic output current
Maximum diagnostic output voltage
Maximum voltage ISO pulse 2a x 500cy (ISO7637)
Maximum power dissipation (internally limited by thermal protection)
Rth=100°C/W AUIPS6041G
Rth=50°C/W AUIPS6041R 1”sqrt. footprint
Max. storage & operating temperature junction temperature
Min.
Max.
Units
V
Vcc-35 Vcc+0.3
Vcc-35 Vcc+0.3
-0.3
5.5
36
28
-3
10
-3
10
-0.3
5.5
55
mA
V
V
W
°C
1.25
2.5
150
-40
Thermal Characteristics
Symbol
Rth1
Rth1
Rth2
Rth3
Rth1
Rth2
Parameter
Thermal resistance junction to ambient AUIPS6041G
Thermal resistance junction to ambient AUIPS6041R D-Pak std. footprint
Thermal resistance junction to ambient AUIPS6041R D-Pak 1” sqrt.
footprint
Thermal resistance junction to case AUIPS6041(R)(S)
D-Pak/D2pak/TO220
Thermal resistance junction to ambient AUIPS6041(S) D2Pak/TO220 std.
footprint
Thermal resistance junction to ambient AUIPS6041S D2Pak 1” sqrt.
footprint
Typ.
100
70
50
6
60
40
Max.
Units
°C/W
Recommended Operating Conditions
These values are given for a quick design. For operation outside these conditions, please consult the application notes.
Symbol
VIH
VIL
Iout
Rin
Rdgs
Rdgp
Rol
F max.
Parameter
High level input voltage
Low level input voltage
Continuous drain current, Tambient=85°C, Tj=125°C, Vin=5V
Rth=100°C/W AUIPS6041G
Rth=50°C/W AUIPS6041R 1” sqrt. footprint
Recommended resistor in series with IN pin
Recommended resistor in series with DG pin for reverse battery protection
Recommended pull-up resistor for DG
Recommended pull-up resistor for open load detection
Max. switching frequency
Min.
4
0
Max.
5.5
0.9
1.6
2.3
10
20
20
100
3.5
Units
A
4
4
4
5
k
kHz
www.irf.com
3
AUIPS6041(G)(R)(S)
Static Electrical Characteristics
Tj=-40°C..150°C, Vcc=6..28V (unless otherwise specified), typical values are given for Vcc=14V and Tj=25°C
Symbol
Rds(on)
Parameter
ON state resistance Tj=25°C
ON state resistance Tj=150°C
ON state resistance Tj=25°C, Vcc=6V
ON state resistance during reverse battery
Tj=25°C
Operating voltage range
Vcc to Out clamp voltage 1
Vcc to Out clamp voltage 2
Supply current when Off and with Vout
connected to ground Rconnection <4Ω
Supply current when On
Input high threshold voltage
Input low threshold voltage
Input hysteresis
Input current when device is On
Dg leakage current
Low level DG voltage
Min.
Typ.
110
190
125
140
Max.
130
230
155
180
28
43
Units
m
Test Conditions
Vin=5V, Iout=2.5A
Vin=5V, Iout=2.5A
Vin=5V, Iout=1.5A
Vcc-Gnd=-14V
Vcc op.
V clamp 1
V clamp 2
Icc Off
Icc On
Vih
Vil
In hyst.
Iin On
Idg
Vdg
6
37
39
40
4
2.2
2.5
2
0.5
40
0.1
0.25
V
µA
mA
V
µA
V
9
5
3
Iout=20mA
Iout=2.5A (see Fig. 1)
Vin=0V, Vout=0V,
Tj=25°C, Vcc=14V
Vin=5V, Vcc=14V
1.5
0.2
1
100
10
0.4
Vin=5V
Vdg=5V
Idg=1.6mA
Switching Electrical Characteristics
Vcc=14V, Resistive load=6, Vin=5V, Tj=-40°C..150°C, typical values are given for Tj=25°C
Symbol
Tdon
Tr1
Tr2
dV/dt (On)
EOn
Tdoff
Tf
dV/dt (Off)
EOff
Parameter
Turn-on delay time
Rise time to Vout=Vcc-5V
Rise time to Vout=0.9 x Vcc
Turn On dV/dt
Turn On energy
Turn-off delay time
Fall time to Vout=0.1 x Vcc
Turn Off dV/dt
Turn Off energy
Min.
Typ.
5
3
4
2.5
100
10
3
6.5
50
Max.
15
10
30
Units
µs
V/µs
µJ
µs
V/µs
µJ
Test Conditions
see Fig. 3
20
10
www.irf.com
4
AUIPS6041(G)(R)(S)
Protection Characteristics
Tj=-40°C..150°C, Vcc=6..28V (unless otherwise specified), typical values are given for Vcc=14V and Tj=25°C
Symbol
Ilim
Tsd+
Tsd-
Vsc
UV+
UV -
VOL Off
I OL On
Parameter
Internal current limit
Over temperature high threshold
Over temperature low threshold
Short-circuit detection voltage(2)
Min.
4
150(1)
Typ.
7
165
158
3
5
4.5
3
0.17
0.15
Max.
10
Units
A
°C
Test Conditions
Vout=0V, Tj=25°C
See fig. 2
2
Open load detection threshold
Open load detection threshold
2
0.05
0.05
4
6.2
5.8
4
0.27
0.22
V
Tj=-40..25°C
Tj=25..150°C
A
(1) Guaranteed by design
(2) Reference to Vcc
True Table
Operating Conditions
IN
OUT
DG
Normal
H
H
H
Normal
L
L
H
Open Load
H
H
L
Open Load (3)
L
H
L
Short circuit to Gnd
H
L
L
Short circuit to Gnd
L
L
H
Short circuit to Vcc
H
H
L (4)
Short circuit to Vcc (5)
L
H
L
Over-temperature
H
L
L
Over-temperature
L
L
H
(3) With a pull-up resistor connected between the output and Vcc.
(4) Vds lower than 10mV.
(5) Without a pull-up resistor connected between the output and Vcc.
Lead Assignments
www.irf.com
5
