BAV100/101/102/103
Taiwan Semiconductor
Small Signal Product
CREAT BY ART
Hermetically Sealed Glass High Voltage Switching Diodes
FEATURES
- High voltage switching device
- Ideal for automated placement
- Hermetically sealed glass
- Compression bonded construction
- All external surfaces are corrosion
resistant and leads are readily solderable
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21
MINI MELF
MECHANICAL DATA
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
SYMBOL
P
D
V
RRM
I
F(AV)
I
FSM
VALUE
500
250
200
1.0
4.0
UNIT
mW
V
mA
A
°C
Power dissipation
Repetitive peak reverse voltage
Average rectified forward current
Non-repetitive peak forward
surge current
Operating and storage temperature range
Electrical Characteristics
PARAMETER
No V10
tR 0&
eco B
mm AV
10
en
de 2
d
Pulse width = 1.0 s
Pulse width = 1.0
μs
T
J
, T
STG
SYMBOL
MIN
60
120
200
250
-
BAV100
BAV101
BAV102
I
R
= 100
μA
I
R
= 100
μA
I
R
= 100
μA
B
V
BAV103
I
R
= 100
μA
V
R
= 50 V
I
F
= 100 mA
V
F
BAV100
BAV101
V
R
= 100 V
V
R
= 150 V
V
R
= 200 V
R
θJA
V
R
= 0 , f = 1.0 MHz
(Note)
C
J
t
rr
-
-
350
BAV102
I
R
-
BAV103
- Polarity: Indicated by black cathode band
-65 to +200
MAX
UNIT
BA
Breakdown voltage
-
V
Forward voltage
1.0
100
100
100
100
V
Peak reverse current
nA
Thermal resistance, junction to ambient
Junction capacitance
Reverse recovery time
°C/W
5.0
50
pF
ns
Notes : Reverse recovery test conditions : I
F
= I
R
= 30 mA , I
rr
= 3 mA , R
L
= 100
Ω
Document Number: DS_S1501002
Version: C15
BAV100/101/102/103
Taiwan Semiconductor
Small Signal Product
CREAT BY ART
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
Fig. 1 Reverse Current VS. Junction Temperature
1000
100
10
1
0.1
0.01
0
40
80
120
160
200
T
j
- Junction Temperature
(
o
C)
V
R
= V
RRM
1000
Fig. 2 Forward Current VS. Forward Voltage
I
R
- Reverse Current (uA)
I
F
- Forward Current (mA)
Scattering Limit
100
T
j
=25
o
C
Scattering Limit
10
1
0.1
0
0.4
0.8
1.2
1.6
2
V
F
- Forward Voltage (V)
Fig. 3 Differential Forward Resistance VS. Forward Current
1000
r
f
- Differential Forward Resistance (Ohm)
100
10
1
0.1
1
I
F
- Forward Current (mA)
Document Number: DS_S1501002
No V10
tR 0&
eco B
mm AV
10
en
de 2
d
10
100
BA
Version: C15
BAV100/101/102/103
Taiwan Semiconductor
Small Signal Product
ORDERING INFORMATION
PART NO.
BAV10x
(Note 1)
PACKING
CODE
L0
L1
PACKING CODE
SUFFIX
G
(*)
PACKAGE
MINI MELF
PACKING
10K / 13" Reel
2.5K / 7" Reel
Note 1: "x" is device code from "0" - "3", detail could follow the previous page
*: Whole series with "G", packing code with suffix "G" means halogen free
EXAMPLE
EXAMPLE P/N
BAV100 L0G
PART NO.
BAV100
PACKING CODE
L0
PACKING CODE
SUFFIX
G
DESCRIPTION
Green compound
DIMENSIONS
MINI MELF
No V10
tR 0&
eco B
mm AV
10
en
de 2
d
C
DIM.
A
Unit (mm)
Unit (inch)
Max
0.146
0.063
0.020
Min
Max
Min
3.30
3.70
0.130
B
1.40
0.20
1.60
0.50
0.055
0.008
B
C
A
BA
SUGGESTED PAD LAYOUT
DIM.
A
Unit (mm)
Typ.
1.25
2.00
2.50
5.00
Unit (inch)
Typ.
0.049
0.079
0.098
0.197
B
C
D
Document Number: DS_S1501002
Version: C15
BAV100/101/102/103
Taiwan Semiconductor
Small Signal Product
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors or inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, to
any intellectual property rights is granted by this document. Except as provided in TSC's terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
Document Number: DS_S1501002
Version: C15
