SI1022R-T1

Description
MOSFET 60V 0.33A
CategoryDiscrete semiconductor    The transistor
File Size152KB,7 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

SI1022R-T1 Online Shopping

Suppliers Part Number Price MOQ In stock
SI1022R-T1 - - View Buy Now

SI1022R-T1 Overview

MOSFET 60V 0.33A

SI1022R-T1 Parametric

Parameter NameAttribute value
MakerVishay
Parts packaging codeSC-75A
package instructionSMALL OUTLINE, R-PDSO-G3
Contacts3
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresLOW THRESHOLD
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage60 V
Maximum drain current (ID)0.33 A
Maximum drain-source on-resistance1.25 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JESD-30 codeR-PDSO-G3
Number of components1
Number of terminals3
Operating modeENHANCEMENT MODE
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Polarity/channel typeN-CHANNEL
Certification statusNot Qualified
surface mountYES
Terminal formGULL WING
Terminal locationDUAL
transistor applicationsSWITCHING
Transistor component materialsSILICON
Si1022R
Vishay Siliconix
N-Channel 60 V (D-S) MOSFET
PRODUCT SUMMARY
V
DS(min.)
(V)
60
R
DS(on)
()
1.25 at V
GS
= 10 V
V
GS(th)
(V)
1 to 2.5
I
D
(mA)
330
FEATURES
Halogen-free According to IEC 61249-2-21
Definition
• TrenchFET
®
Power MOSFETs
• Low On-Resistance: 1.25
• Low Threshold: 2.5 V
• Low Input Capacitance: 30 pF
• Fast Switching Speed: 25 ns
• Low Input and Output Leakage
• Miniature Package
• ESD Protected: 2000 V
• Compliant to RoHS Directive 2002/95/EC
SC-75A
(SOT-416)
G
1
3
APPLICATIONS
D
S
2
Marking Code: E
• Drivers: Relays, Solenoids, Lamps, Hammers, Displays,
Memories, Transistors, etc.
• Battery Operated Systems
• Solid State Relays
Ordering Information:
Si1022R-T1-GE3 (Lead (Pb)-free and Halogen-free)
BENEFITS
Low Offset Voltage
Low-Voltage Operation
High-Speed Circuits
Low Error Voltage
Small Board Area
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25 °C, unless otherwise noted)
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current
a
Pulsed Drain Current
a
Power Dissipation
a
Thermal Resistance, Maximum Junction-to-Ambient
a
Operating Junction and Storage Temperature Range
Notes:
a. Surface mounted on FR4 board, power applied for t
10 s.
T
A
= 25 °C
T
A
= 85 °C
T
A
= 25 °C
T
A
= 85 °C
Symbol
V
DS
V
GS
I
D
I
DM
P
D
R
thJA
T
J
, T
stg
Limit
60
± 20
330
240
650
250
130
500
- 55 to 150
mW
°C/W
°C
mA
Unit
V
Document Number: 71331
S10-2687-Rev. F, 22-Nov-10
www.vishay.com
1
