Technical Data
2101
Effective
June
2017
Supersedes
December
2007
S-8000
1/4"
x
1 1/4"
Fuse
blocks
Agency information
•
UL Recognized: E14853
•
CSA Certified: 47235
•
•
Relative Temperature Index (RTI)
o
Bolt-in 130°C
o
Snap-in 110°C
Environmental data
Product features
•
•
•
•
•
•
•
For 1/4" x 11/4" (6.3 x 32mm) fuses
Bolt-in and snap-in mounting available
Tight cluster mounting
All types of terminal configurations
Clips made of bright tin-plated spring-bronze
Anti-rotational pin provided
Flame retardant thermoplastic meets UL 94V0
Ordering information
• Specify packaging, product, and
option code
Bolt-in Mounting Example:
BK/S-8102-6-R
BK/
1
S-8
2
1
3
02
4
6 - R
5
7
Snap-in Mounting Example:
BK/S-8001-1-SNP-R
BK/
1
S-8
2
0
3
01 - 1 - SNP -
4
5
6
R
7
1. Packaging Code:
2. Series Number:
3. Type Terminal:
4. Terminal Angle:
5. Number of Poles:
6. Mounting Style:
7. RoHS Compliant Version
*Available only in single pole
BK/
S-8
0 = Solder
1 =
3
/
16
" quick connect
2 =
1
/
4
" quick connect
3 = Screw
01 = Straight (0°)
02 = 40° Angle
03 = Side*
(1 – 12)
1X = One pole, No Mounting Stud
SNP = Snap-in Mounting*
-R
Catalog Number Pre x
Blank
BK/
Description
Varies with number of poles. Contact customer service.
Varies with number of poles. Contact customer service.
Packaging Code
Effective
June
2017
Technical Data
2101
S-8000
1/4" x 1 1/4" Fuse blocks
Multiple Pole
CSA Max. Amps
21
13
16
25
No. of
Poles
1
2
3
4
5
6
7
8
9
10
11
12
Specifications
Series
S-8000
S-8100
S-8200
S-8300
Volts
300Vac/dc
300Vac/dc
300Vac/dc
300Vac/dc
UL Max Amps
30
20
30
30
Mounting Dimensions
Inches
A
–
1
1
/
8
"
1
3
/
4
"
2
3
/
8
"
3"
3
5
/
8
"
4
1
/
4
"
4
7
/
8
"
5
1
/
2
"
6
1
/
8
"
6
3
/
4
"
7
3
/
8
"
B
–
5
/
8
"
1
1
/
4
"
1
7
/
8
"
2
1
/
2
"
3
1
/
8
"
3
3
/
4
"
4
3
/
8
"
5"
5
5
/
8
"
6
1
/
4
"
6
7
/
8
"
Millimeters
A
B
–
–
28.6
15.9
44.4
31.8
60.3
47.6
76.2
63.5
92.1
79.4
108.0
95.2
123.8
111.1
139.7
127.0
155.6
142.9
171.4
158.8
187.3
174.6
Dimensions - mm/in.
S-8000 Single-Pole Snap-In Mounting Series
40° Terminal
0°
Terminal
Side
Terminal
Mounting
Dimensions - mm/in.
S-8000 Single-Pole Bolt-In Mounting Series
40° Terminal
Component
Clip
Body
Material
Spring-Bronze, Bright Tin-Plate
Thermoplastic
0°
Terminal
Screw
Terminal
Side
Terminal
Mounting
