BK-EFF-5: DescriptionFuses with Leads (Through Hole) Replaced by SR-5F-5A-BK; CategoryCircuit protection; File Size138KB，2 Pages; ManufacturerEaton

Download Datasheet Parametric Compare View All

BK-EFF-5 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BK-EFF-5	-	-	View	Buy Now

BK-EFF-5 Overview

Fuses with Leads (Through Hole) Replaced by SR-5F-5A-BK

BK-EFF-5 Parametric

Parameter Name	Attribute value
Product Category	Fuses with Leads (Through Hole)
Manufacturer	Eaton
RoHS	Details
Product	PCB Mount Fuse
Current Rating	5 A
Voltage Rating AC	250 VAC
Fuse Type	Fast Blow
Body Style	Leaded Fuses
Termination Style	Radial
Fuse Size / Group	MICRO
Diameter	8.35 mm
Indicator Style	Without Indicator
Length	7.7 mm
Factory Pack Quantity	1
Type	Specialty Fuses
Unit Weight	0.016000 oz

Preview

Download Datasheet

View All

Radial Lead Micro Fuse

EFF Series, Fast Acting

Description

• Fast acting micro fuse

• Base and cap material is a thermoplastic, UL 94-V0

• Leads are tin-lead plated copper alloy

Electrical Characteristics

150%

Rated Current

250mA to 5A

All are 250V AC

Min.

1 hr.

210%

Max.

30 min.

275%

Min.

10 ms.

Max.

3 sec.

400%

Min.

3 ms.

Max.

300 ms.

1000%

Max.

20 ms.

Dimensional Data

A

V

DE

Agency Information

• Semco Certificate VDE License: 250mA to 5A / 35A or

10

In

whichever is greater @ 250VAC

• UL Recognized File No. E19180, CSA Acceptance File

No. LR701159; 250mA to 5A / 50A @ 250VAC

• RoHS Compliant

Environmental Data

• Soldering Heat Resistance: 260°, 10 sec. per IEC 68-2-20

• Vibration Resistance: MIL-STD-202, Method 201,

10-55Hz x 3 axis/ no load

• Shock Resistance: MIL-STD-202, Method 213,

Condition I (Sawtooth)

• Moisture Resistance: MIL-STD-202F, Method 106

• Salt Spray: MIL-STD-202, Method 101,

Condition B (48 hrs)

• Operating Temperature: -55°C to +125°C

Ordering

• Specify product code and packaging code

S

F500MA 250V

BU

SS

FUSE

B

E

LEAD

C

Ø

D

F

Short Lead

Dimensions

mm (inches)

Short Lead

A

B

C

D

E

F

∅

8.35 ± 0.1 (0.329)

7.7 ± 0.1 (0.303)

4.3 ± 0.3 (0.169)

—

0.5 min. (0.020)

0.6 ± 0.1 (0.024)

Long Lead

8.35 ± 0.1 (0.329)

7.7 ± 0.1 (0.303)

—

18.8 ± 0.3 (0.740)

0.5 min. (0.020)

0.6 ± 0.1 (0.024)

Long Lead

5.08 ± 0.1 (0.200) 5.08 ± 0.1 (0.200)

SPECIFICATIONS

Product

Code

EFF-250mA

EFF-315mA

EFF-400mA

EFF-500mA

EFF-630mA

EFF-800mA

EFF-1

EFF-1.25

EFF-1.6

EFF-2

EFF-2.5

EFF-3.15

EFF-4

EFF-5

EFF-6.3

Ampere

Rating

250mA

315mA

400mA

500mA

630mA

800mA

1A

1.25A

1.6A

2A

2.5A

3.15A

4A

5A

6.3A

Typical Cold

Resistance

(ohm)

0.45

0.34

0.25

0.19

0.091

0.071

0.055

0.043

0.034

0.026

0.02

0.016

0.012

0.01

0.008

Volt-drop

@ 100%

In

(Volt) max.

0.254

0.246

0.239

0.232

0.106

0.103

0.1

0.097

0.094

0.091

0.088

0.086

0.083

0.081

0.078

Melting I

2

T

< 10 mSec

(A

2

Sec)

0.029

0.05

0.08

0.15

0.12

0.21

0.36

0.61

1.1

1.8

3.1

5.3

9

16

27

Melting I

2

T

@ 10

In

(A

2

Sec)

0.027

0.05

0.08

0.13

0.22

0.36

0.59

1

1.7

2.7

4.5

8

13

21

Maximum

Power

Dissipation (W)

0.15

0.18

0.22

0.27

0.15

0.19

0.23

0.28

0.35

0.42

0.51

0.62

0.77

0.93

1.14

Voltage Drop measured at 100% of rated current.

Melting I

2

t measured at 10X current rating
