(1/2)
Common Mode Filters(SMD)
For xDSL
ZCYS Series
FEATURES
• ZCYS series provide highly effective noise rejection characteris-
tics without distorting the transmission signal.
Therefore this product is most suitable for an application of a
xDSL interface circuit.
• The products contain no lead and also support lead-free solder-
ing.
APPLICATIONS
xDSL, modem, Pots-splitters for DSLAM
TEMPERATURE RANGE
Operating
–25 to +85°C
Conformity to RoHS Directive
PRODUCT IDENTIFICATION
ZCYS 8684 -902 -2P -TL
(1)
(2)
(3) (4) (5)
(1)Series name
(2)Case size
(3)Inductance code
(4)Number of lines
(5)Packaging style
TL: Taping(ø330mm reel)
PACKAGING STYLE AND QUANTITIES
Type
ZCYS8684
ZCYS9058
ZCYS1512
Quantity
1000pieces/reel
1500pieces/reel
500pieces/reel
SHAPES AND DIMENSIONS/RECOMMENDED PC BOARD PATTERNS
ZCYS8684 TYPE
ZCYS9058 TYPE
9.0±0.3
1.2
1
8.4±0.2
6.2±0.15
4
0.6±0.15
1.85
1
5.8±0.2
2.5±0.15
9.0±0.5
1.2
4
0.6±0.15
2.9
6.2
7.3
2
3
0.3±0.15
2
5.0±0.2
3
0.3±0.15
4.4±0.2
7.65
Weight: 0.32g
Dimensions in mm
Weight: 0.57g
Dimensions in mm
ZCYS1512 TYPE
15.0±0.5
3.0
1
12.0±0.25
7.62±0.25
4
0.6±0.15
1.2
CIRCUIT DIAGRAM
1
2
4
3
2
3
13.3
6.9±0.25
0.3±0.15
Weight: 1.53g
Dimensions in mm
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific
bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.
• All specifications are subject to change without notice.
001-04 / 20061022 / e971_zcys_xdsl.fm
7.62
2.5
(2/2)
ELECTRICAL CHARACTERISTICS
Part No.
ZCYS8684-472-2P
ZCYS8684-902-2P
ZCYS9058-471-2P
ZCYS9058-222-2P
ZCYS9058-472-2P
ZCYS1512-203-2P
Common mode inductance
(mH)[100kHz]
4.7±30%
9.0±30%
0.47±30%
2.2±30%
4.7±30%
20±30%
DC resistance
(Ω)max.
1.0
1.2
0.5
0.7
1.0
2.0
Rated current
(A)max.
0.4
0.3
0.3
0.3
0.3
0.2
Rated voltage
(V)max.
80
80
80
80
80
80
Insulation resistance
(MΩ)min.
100
100
100
100
100
100
TYPICAL ELECTRICAL CHARACTERISTICS
INSERTION LOSS (COMMON MODE) vs. FREQUENCY CHARACTERISTICS
ZCYS8684-472-2P
ZCYS8684-902-2P
10
15
20
Attenuation(dB)
30
35
40
45
50
55
60
0.01
Attenuation(dB)
0.1
1
Frequency (MHz)
10
100
25
10
15
20
25
30
35
40
45
50
55
60
0.01
0.1
1
Frequency (MHz)
10
100
ZCYS9058-471-2P
10
15
20
Attenuation(dB)
30
35
40
45
50
55
60
0.01
25
ZCYS9058-222-2P
10
15
20
Attenuation(dB)
25
30
35
40
45
50
55
60
0.01
0.1
1
Frequency (MHz)
10
100
0.1
1
Frequency (MHz)
10
100
ZCYS9058-472-2P
10
15
20
Attenuation(dB)
30
35
40
45
50
55
60
0.01
25
ZCYS1512-203-2P
10
15
20
Attenuation(dB)
25
30
35
40
45
50
55
60
0.01
0.1
1
Frequency (MHz)
10
100
0.1
1
Frequency (MHz)
10
100
• All specifications are subject to change without notice.
001-04 / 20061022 / e971_zcys_xdsl.fm
