1N6103A – 1N6137A
Voidless Hermetically Sealed Bidirectional
Transient Voltage Suppressors
Qualified to MIL-PRF-19500/516
Qualified Levels:
JAN, JANTX, JANTXV
and JANS*
Available on
commercial
versions
DESCRIPTION
This series of industry recognized voidless, hermetically sealed bidirectional Transient Voltage
Suppressors (TVS) is military qualified to MIL-PRF-19500/516 and is ideal for high-reliability
applications where a failure cannot be tolerated. They provide a Working Peak “Standoff” Voltage
selection from 5.7 to 152 volts with a 500 watt rating for a 10/1000
µs
pulse. They are very robust
in hard-glass construction and use internal “Category
1”
metallurgical bonds. These devices are
available as both a non-suffix part and an “A” version providing different voltage tolerances as
described in the nomenclature section. These devices are also available in a surface mount MELF
package configuration.
Important:
For the latest information, visit our website
http://www.microsemi.com.
FEATURES
•
•
•
•
•
•
High surge current and peak pulse power provides transient voltage protection for sensitive circuits.
Triple-layer passivation.
Internal “Category
1”
metallurgical bonds.
Voidless hermetically sealed glass package.
JAN, JANTX, and JANTXV qualified versions are available per MIL-PRF-19500/516.
*JANS available for 1N6103(A) thru 1N6118(A) per MIL-PRF-19500/516 as well as further options
for screening in reference to MIL-PRF-19500 for all others in this series.
(See
part nomenclature
for all available options.)
RoHS compliant versions available (commercial grade only).
“B” Package
Also available in:
“B” SQ-MELF
Package
(surface mount)
1N6103US – 1N6137US
•
APPLICATIONS / BENEFITS
•
•
•
•
•
•
•
•
•
Military and other high-reliability applications.
Extremely robust construction.
Extensive range in working peak “standoff” voltage (V
WM
) from 5.7 to 152 volts.
500 watt peak pulse power (P
PP
) for a 10/1000
µs
pulse.
ESD and EFT protection per IEC6100-4-2 and IEC61000-4-4 respectively.
Protection from the secondary effects of lightning per select levels in IEC61000-4-5.
Flexible axial-leaded mounting terminals.
Non-sensitive to ESD per MIL-STD-750 method 1020.
Inherently radiation hard as described in Microsemi “MicroNote
050”.
MAXIMUM RATINGS
@
T
A
= 25 C unless otherwise noted
Parameters/Test Conditions
Junction and Storage Temperature
(1)
Thermal Resistance Junction-to-Lead
Peak Pulse Power @ 25 ºC (10/1000
µs)
o (1)
Steady-State Power @ T
L
= 75 C
o (2)
Steady-State Power @ T
A
= 25 C
Impulse Repetition Rate
Solder Temperature @ 10 s
Notes:
1.
2.
o
Symbol
T
J
and T
STG
R
ӨJL
P
PP
P
D
P
D
df
T
SP
Value
-55 to +175
33.5
500
3.0
2.0
0.01
260
Unit
o
C
C/W
W
W
W
%
o
C
o
MSC – Lawrence
6 Lake Street,
Lawrence, MA 01841
Tel: 1-800-446-1158 or
(978) 620-2600
Fax: (978) 689-0803
MSC – Ireland
Gort Road Business Park,
Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044
Fax: +353 (0) 65 6822298
Website:
www.microsemi.com
At 3/8 inch lead length from body.
Steady-state power ratings with reference to ambient are for PC boards where thermal resistance from
mounting point to ambient is sufficiently controlled where maximum rated T
J
is not exceeded (also see
figure 4).
T4-LDS-0277, Rev. 1 (121354)
©2013 Microsemi Corporation
Page 1 of 6
1N6103A – 1N6137A
MECHANICAL and PACKAGING
•
•
•
•
•
•
•
CASE: Hermetically sealed voidless hard glass with tungsten slugs.
TERMINALS: Axial-leads are tin/lead over copper. RoHS compliant matte-tin is available on commercial grade only.
MARKING: Body paint and part number.
POLARITY: No polarity marking for these bidirectional TVSs.
TAPE & REEL option: Standard per EIA-296. Consult factory for quantities.
WEIGHT: Approximately 750 milligrams.
See
Package Dimensions
on last page.
PART NOMENCLATURE
Applicable to entire series:
JAN
Reliability Level
JAN = JAN Level
JANTX = JANTX Level
JANTXV = JANTXV Level
Blank = commercial
JEDEC type number
See
Electrical Characteristics
table
1N6103
A
(e3)
RoHS Compliance
e3 = RoHS compliant (available
on commercial grade only)
Blank = non-RoHS compliant
Voltage Tolerance
A = Standard
Blank =5% higher V
C
, 5% lower
min. V
(BR)
and 5% lower I
PP
Applicable to 1N6103(A) thru 1N6118(A) only:
JANS
Reliability Level
JANS = JANS Level
JEDEC type number
See
Electrical Characteristics
table
1N6103
A
Voltage Tolerance
A = Standard
Blank =5% higher V
C
, 5% lower
min. V
(BR)
and 5% lower I
PP
Applicable to 1N6119(A) thru 1N6137(A) only:
MSP
Reliability Level
MSP (reference JANS)
JEDEC type number
See
Electrical Characteristics
table
1N6119
A
(e3)
RoHS Compliance
e3 = RoHS compliant
Blank = non-RoHS compliant
Voltage Tolerance
A = Standard
Blank =5% higher V
C
, 5% lower
min. V
(BR)
and 5% lower I
PP
T4-LDS-0277, Rev. 1 (121354)
©2013 Microsemi Corporation
Page 2 of 6
1N6103A – 1N6137A
SYMBOLS & DEFINITIONS
Definition
Minimum Breakdown Voltage: The minimum voltage the device will exhibit at a specified current.
Working Peak Voltage: The maximum peak voltage that can be applied over the operating temperature range. This is
also referred to as standoff voltage.
Maximum Standoff Current: The maximum current that will flow at the specified voltage and temperature.
Maximum clamping voltage at specified I
PP
(Peak Pulse Current) at the specified pulse conditions.
Peak Pulse Power: The peak power dissipation resulting from the peak impulse current I
PP
.
Symbol
V
(
BR)
V
WM
I
D
V
C
P
PP
ELECTRICAL CHARACTERISTICS
MINIMUM
BREAKDOWN
VOLTAGE
(Note 1)
V
(BR)
@ I
(BR)
Volts
7.13
7.79
8.65
9.50
10.45
11.40
12.35
14.25
15.20
17.10
19.0
20.9
22.8
25.7
28.5
31.4
34.2
37.1
40.9
44.7
48.5
53.2
58.9
64.6
71.3
77.9
86.5
95.0
104.5
114.0
123.5
142.5
152.0
171.0
190.0
mA
175
150
150
125
125
100
100
75
75
65
65
50
50
50
40
40
30
30
30
25
25
20
20
20
20
15
15
12
12
10
10
8
8
5
5
RATED
STANDOFF
VOLTAGE
V
WM
V
5.7
6.2
6.9
7.6
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.7
56.0
62.2
69.2
76.0
86.6
91.2
98.8
114.0
121.6
136.8
152.0
MAXIMUM
STANDBY
CURRENT
I
D
@ V
WM
µA
50
20
20
20
20
20
20
20
20
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
MAXIMUM
CLAMPING
VOLTAGE
(Note 1)
V
C
@ I
PP
Volts
11.2
12.1
13.4
14.5
15.6
16.9
18.2
21.0
22.3
25.1
27.7
30.5
33.3
37.4
41.6
45.7
49.9
53.6
59.1
64.6
70.1
77.0
85.3
97.1
103.1
112.8
125.1
137.6
151.3
165.1
178.8
206.3
218.4
245.7
273.0
MAXIMUM
PEAK PULSE
CURRENT
(Note 1)
I
PP
Amps
44.6
41.3
37.3
34.5
32.0
29.6
27.5
23.8
22.4
19.9
18.0
16.4
15.0
13.4
12.0
10.9
10.0
9.3
8.5
7.7
7.1
6.5
5.9
5.1
4.8
4.4
4.0
3.6
3.3
3.0
2.8
2.4
2.3
2.0
1.8
MAXIMUM
TEMP.
COEF. OF
V
(
BR)
α
V(BR)
o
%/ C
.06
.06
.06
.07
.07
.07
.08
.08
.08
.085
.085
.085
.09
.09
.09
.095
.095
.095
.095
.095
.095
.095
.100
.100
.100
.100
.100
.100
.100
.100
.105
.105
.105
.110
.110
INDUSTRY
TYPE
NUMBER
(Note 1)
†1N6103A
†1N6104A
†1N6105A
†1N6106A
†1N6107A
†1N6108A
†1N6109A
†1N6110A
†1N6111A
†1N6112A
†1N6113A
†1N6114A
†1N6115A
†1N6116A
†1N6117A
†1N6118A
1N6119A
1N6120A
1N6121A
1N6122A
1N6123A
1N6124A
1N6125A
1N6126A
1N6127A
1N6128A
1N6129A
1N6130A
1N6131A
1N6132A
1N6133A
1N6134A
1N6135A
1N6136A
1N6137A
† Also available in JANS qualification per MIL-PRF-19500/516.
Notes:
1. Part number without the A suffix has 5% higher V
C
, 5% lower minimum V
(BR)
, and 5% lower I
PP
.
T4-LDS-0277, Rev. 1 (121354)
©2013 Microsemi Corporation
Page 3 of 6
