Radial Lead Fuses
TE5
®
> Fast-Acting Fuse > 395 Series
395 Series, TE5
®
Fast-Acting Fuse
Description
Pb
RoHS
PS
E
The 395 Series TE5
®
Fuses are fast-acting type, 125V and
are designed in accordance to UL 248-14.
Features
• RoHS compliant and
Lead-free
• Reduced PCB space
requirements
• Direct solderable or
plug-in versions
Agency Approvals
Agency
Agency File Number
Ampere Range
• Low internal resistance
• Shock safe casing
• Vibration resistant
• Halogen Free
• Available from 0.05A
to 6.3A
• Internationally approved
Applications
• Battery chargers
• Consumer Electronics
E67006
E67006
PS
E
0.05A-6.3A
0.05A-6.3A
1A - 5A
• Power supplies
• Industrial controllers
JET1896-31007-1005
Additional Information
Electrical Characteristics
% of Ampere
Rating
200%
Opening Time
60 Seconds,
Max.
Datasheet
Resources
Samples
Electrical Characteristics
Rated
Current
50mA
63mA
80mA
100mA
125mA
160mA
200mA
250mA
315mA
400mA
500mA
630mA
800mA
1.00A
1.25A
1.60A
2.00A
2.50A
3.15A
4.00A
5.00A
6.30A
Voltage
Rating
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
Breaking
Capacity
Nominal
Cold
Resistance
(Ohms)
8.1290
4.6900
3.6500
7
.4910
6.1970
4.2850
2.9780
2.3100
1.7220
0.2200
0.1570
0.1180
0.0970
0.0710
0.0635
0.0492
0.0412
0.0305
0.0247
0.0193
0.0139
0.0116
Voltage
Drop
1.0×I
N
max. (mV)
1600
1300
1200
1100
1350
1000
950
900
800
230
220
210
200
190
180
170
160
150
140
130
120
115
Power
Dissipation
1.0×I
N
max. (mW)
85
85
100
110
160
150
210
225
255
95
110
135
160
190
225
275
450
375
445
520
600
850
Melting
Integral
10×I
N
max. (A
2
s)
0.0001
0.0001
0.0002
0.0013
0.0019
0.0037
0.0075
0.0130
0.0260
0.0150
0.0250
0.0450
0.0680
0.1300
0.2000
0.3900
0.5300
1.1000
1.9000
3.2000
6.1000
9.7000
Agency Approvals
PS
E
Amp Code
0050
0063
0080
0100
0125
0160
0200
0250
0315
0400
0500
0630
0800
1100
1125
1160
1200
1250
1315
1400
1500
1630
100A
@125 VAC
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
Notes:
1. 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
2. Resistance is measured at 10% of rated current, 25°C.
© 2015 Littelfuse, Inc.
Specifications are subject to change without notice. Application testing is strongly recommended.
Revised: 11/11/15
Radial Lead Fuses
TE5
®
> Fast-Acting Fuse > 395 Series
Temperature Re-rating Curve
Average Time Current Curves
0.100A
0.125A
0.160A
0.200A
0.250A
0.315A
140
120
100000
PERCENT OF RATING
100
80
60
40
20
10000
23°C
1000
-40
-20
0
20
40
60
80
AMBIENT TEMPERATURE (°C)
TIME IN SECONDS
0
100
10
Note:
1. Rerating depicted in this curve is in addition to the standard derating of 25% for
continuous operation.
1
0.100
0.010
0.001
0.02
0.100
1
10
100
CURRENT IN AMPERES
Soldering Parameters - Wave Soldering
300
Temperature (°C) - Measured on bottom side of board
280
260
240
220
200
180
160
140
120
100
80
60
40
20
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
10
20
30
40
50
60
70
80
90
0
0
Recommended Process Parameters:
Wave Parameter
Preheat:
(Depends on Flux Activation Temperature)
(Typical Industry Recommendation)
Temperature Minimum:
Temperature Maximum:
Preheat Time:
Solder Pot Temperature:
Solder Dwell Time:
Recommended Hand-Solder Parameters:
Solder Iron Temperature: 350°C +/- 5°C
Heating Time: 5 seconds max.
Note: These devices are not recommended for IR or
Convection Reflow process.
Time (Seconds)
Preheat Time
Dwell Time
Cooling Time
0.400A
0.500A
0.630A
0.800A
1.00A
1.25A
1.60A
2.00A
2.50A
3.15A
4.00A
5.00A
6.30A
0.050A
0.063A
0.080A
Lead-Free Recommendation
100
°
C
150
°
C
60-180 seconds
260
°
C Maximum
2-5 seconds
© 2015 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 11/11/15
Radial Lead Fuses
TE5
®
> Fast-Acting Fuse > 395 Series
Product Characteristics
Materials
Lead Pull Strength
Solderability
Soldering Heat
Resistance
Base/Cap: Brown Thermoplastic
Polyamide PA 6.6, UL 94 V-0
Round Pins: Copper, Tin-plated
10 N (IEC 60068-2-21)
260ºC, ≤ 3s. (Wave)
350ºC, ≤ 1s. (Soldering Iron)
260ºC, 10s. (IEC 60068-2-20)
350ºC, 3s. (Soldering Iron)
Stock Conditions
Operating Temperature
Climatic Category
-40ºC to +85ºC (Consider re-rating)
-40ºC to +85ºC/21 days
(IEC 60068-1,-2-1,-2-2,-2-78)
+10ºC to +60ºC
RH ≤ 75% yearly average, without
dew, maximum value for 30 days-
95%
24 cycles at 15 min. each
(IEC 60068-2-6)
10 - 60Hz at 0.75mm amplitude
60 - 2000Hz at 10g acceleration
Vibration Resistance
Dimensions
8,5
max. 8
max.4
Part Numbering System
395 xxxx 0000
Series
Amp Code
0,5 min
L
Æ 0,6
1,5
Refer to Amp Code column of
Electrical Characteristics Table
Packaging Code
0000 Tape/Ammopack (1,400 pcs.)
0440 Short Leads - Bulk (1,400 pcs.)
5,08
Holes in the printed circuit board
Long Leads (L=18.8mm)
Short Leads (L=4.3mm)
Packaging
Packaging Option
395 Series
Tape and Ammopack
Short Leads
Packaging Specification
N/A
N/A
Quantity
1,400
1,400
Quantity &
Packaging Code
0000
0440
Taping Width
N/A
N/A
Holes in PCB
© 2015 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 11/11/15
1 +0,1
