Bussmann
®
Supplementary Fuseblocks
Type M, For ⁄‹Ω£™∑ ≈ 1⁄Ω™∑ Fuses
600 Volt AC, ⁄Ω¡º to 30 Amps
BM Series
Dimensional Data
All dimensions (±0.015)
1 POLE
Catalog Symbol:
BM Series
Type M Supplementary Fuseblocks
Ampere Rating:
⁄Ω¡º to 30 Amperes
Voltage Rating:
600 Volts AC
Withstand Rating:
10,000 A RMS Sym. or interrupting rating of
the fuse used, whichever is lower.
Agency Information:
U.L. Recognized, U.L. 512, Guide IZLT2, File E14853
CSA Certified, C22.2 No. 39, Class 6225-01, File 47235
For use with any ⁄‹Ω£™∑ ≈ 1⁄Ω™∑ Fuses
(Bussmann KTK, FNQ, FNM, BAF, BAN and AGU)
U.L. Flammability:
94 V0
Material:
Thermoplastic
Catalog Data (600V)
Amps
⁄Ω¡º
to
30
Wire
Range
CU Only
* QUICK CONNECT RATED FOR 20A MAXIMUM.
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin
is intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information con-
tained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
1-16-02
th o
e m O
Se BM me B
n d SO
e M
da m e L
d E
ta od r T
ep E
sh ul
ee ar lac
t n fus em
o. e e
bl nt
10 o
is
24 ck
1 .
(76.20mm + 0.38mm)
3.000" + 0.015"
(21.03mm + 0.38mm)
0.828" + 0.015"
(9.14mm)
0.360"
(5.08mm + 0.08mm)
0.200" + 0.003"
2 POLE
(10.80mm)
0.425"
(41.28mm + 0.38mm)
1.625" + 0.015"
(19.43mm)
0.765"
Poles
1
2
3
Terminal Type
Screw with
Quick
Connect*
BM6031SQ
BM6032SQ
BM6033SQ
Pressure Plate w/
Quick Connect*
BM6031PQ
BM6032PQ
BM6033PQ
Box
Lug
BM6031B
BM6032B
BM6033B
Fig.
No.
1
2
3
3 POLE
.169"
≈
.210"
4.29mm ≈ 5.33mm
Typ. 2
(5.08mm + 0.08mm)
0.200" + 0.003"
(10.80mm)
0.425"
(60.33mm + 0.38mm)
2.375" + 0.015"
(19.05mm)
.750"
(38.86mm)
1.530"
ec
#10-#18
#10-#18
#6-#14
(4.37mm)
Typ. 2
.172"
(5.08mm + 0.08mm)
0.200" + 0.003"
R
FUSEBLOCK LABEL
(EXAMPLE SHOWN)
FUSEBLOCK LABEL
(EXAMPLE SHOWN)
1.210" + 0.015"
1.210" + 0.015"
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000 Vac, 75-1500 Vdc). Refer to BIF document #8002 or contact
Bussmann Application Engineering at 636-527-1270 for more information.
BM6032SQ
BM6032SQ
REPLACES M60030-2SQ
REPLACES M60030-2SQ
(30.73mm + 0.38mm)
(30.73mm + 0.38mm)
CU ONLY
CU ONLY
10 -14
20 LB IN.
10 -14
20 LB IN.
QUIK CON. 20A
QUIK CON. 20A
30A
30A
600V
600V
Buss
®
Buss
®
BUSSMANN
BUSSMANN
COOPER INDUSTRIES
COOPER INDUSTRIES
ST. LOUIS, MO 63178
ST. LOUIS, MO 63178
MADE IN U.S.A.
MADE IN U.S.A.
10,000A RMS SYM
10,000A RMS SYM
WITHSTAND RATING
WITHSTAND RATING
R
R
XXXXX
XXXXX
SB02003
Form No. BM Series
Page 1 of 1
BIF Doc #1104
