This document was generated on 10/18/2017
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0347362001
Active
MX64™ Sealed Connectors
2.54mm Pitch MX64 Terminal, Silver Plating, 22 AWG, Right Reel Payoff, Also used
with MX123 Female Receptacle Housing
Documents:
Drawing (PDF)
Product Specification PS-33468-001-001 (PDF)
Application Specification AS-33468-001-001 (PDF)
Packaging Specification PK-30907-759 (PDF)
General
Product Family
Series
Application
Comments
Packaging Specification PK-31300-516 (PDF)
Packaging Specification PK-31302-480 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Compliant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2017 (12
January 2017)
Halogen-Free
Status
Not Relevant
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Relevant
Compliant
Not Contained
Crimp Quality Equipment
Overview
Product Name
UPC
Physical
Gender
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Packaging Type
Plating min - Mating
Plating min - Termination
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
Wire Size mm²
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Crimp Terminals
34736
Power
Right Reel Payoff <br><br>For automatic and semi-
automatic crimping, use Left Reel Payoff terminals. See
Sales Drawing for Left Reel Payoff Part Numbers.
Yes
MX64™ Sealed Connectors
MX123, MX64
884982128804
Female
Copper
Silver
Silver
0.236/g
Reel
2.540µm
1.905µm
Crimp or Compression
1.50-2.06mm
22
N/A
Search Parts in this Series
34736 Series
Use With
MX64 Sealed Single Row Crimp Housing
31403 , MX123 Female Receptacle Housing
34566 , 34576
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Hand Crimp Tool
0638114200
AS-33468-001-001
PK-30907-759, PK-31300-516, PK-31302-480
PS-33468-001-001
SD-33468-001
This document was generated on 10/18/2017
