Part Number:
Status:
Overview:
Description:
0460100621
Active
Mini-Fit Plus Connector System
Mini-Fit Plus PCB Receptacle, 4.20mm Pitch, Dual Row, Vertical, Blind Mating, 6
Circuits, with Snap-in Plastic Peg PCB Lock, PA Polyamide Nylon 6/6, UL 94V-0, Tin
(Sn) Over Nickel (Ni) Plating
Documents:
3D Model
Drawing (PDF)
Product Specification PS-45750-001-001 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Comments
Packaging Specification PK-42385-999 (PDF)
Test Summary 423850000-TS-000 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
E29179
PCB Receptacles
46010
Board-to-Board, Power
Current = 13A max. per circuit when header is mated to
a receptacle loaded with 45750 Mini-Fit Plus HCS Crimp
Terminal Crimped to 16 AWG wire. . See Molex product
specification for additional current de-rating information.
Mini-Fit Plus Connector System
Mini-Fit Plus
883906726485
6
6
Natural
30
94V-0
No
Yes
None
None
Copper Alloy
Tin
Tin
Nylon
1.329/g
2
Vertical
1.80mm
Yes
Yes
Tray
4.20mm
2.540µm
1.270µm
Yes
Yes
No
No
-40°C to +105°C
Through Hole
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Search Parts in this Series
46010 Series
Mates With
42404 Mini-Fit BMI Right Angle Header,
46011 Mini-Fit Plus Vertical Header, 42475
Mini-Fit BMI Plug Housing
Electrical
Current - Maximum per Contact
Grounding to PCB
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
Test Summary
13.0A
Yes
600V
005
WAVE
001
240
PK-42385-999
PS-45750-001-001
SD-46010-001-000
423850000-TS-000
