SERIES:
SJ-352X-SMT
│
DESCRIPTION:
3.5 MM AUDIO JACKS
FEATURES
• low profile design
• switch options include:
– no switch
– tip switch
RoHS
PART NUMBER KEY
SJ-352
X-SMT-X-X
Base Number
Switch Options
3 = no switch
4 = tip switch
Package Options
"blank" = standard
TR = Tape & Reel
Color Options
"blank" = black
BE = blue*
GR = green*
PI = pink*
*tip switch model only
SPECIFICATIONS
parameter
rated input voltage
rated input current
contact resistance
insulation resistance
voltage withstand
insertion/withdrawl force
terminal strength
operating temperature
life
Notes:
1. When measured at a current of less than 100 mA / 1 kHz
conditions/description
min
typ
12
max
1
units
Vdc
A
mΩ
mΩ
MΩ
Vac
kg
g
°C
cycles
between terminal and mating plug
between terminal in a closed circuit
1
at 500 Vdc
at 50/60Hz for 1 minute
0.3
any direction for 10 seconds
-25
5,000
100
50
30
500
3
500
85
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
SJ-352X-SMT
│
DESCRIPTION:
3.5 MM AUDIO JACKS
date
11/09/2012
│
page
3 of 3
SOLDERABILITY
parameter
reflow soldering
conditions/description
see reflow profile
min
255
typ
260
max
265
units
°C
270
260
250
240
217
180
150
120
60
50
°C
60
Time (second)
70
120
140
180
240
250
300
340
360
380
420
430
480
REVISION HISTORY
rev.
1.0
1.01
1.02
description
initial release
new template applied
added TR package and color options
date
02/07/2006
01/25/2012
11/01/2012
The revision history provided is for informational purposes only and is believed to be accurate.
