(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
T13E.pdf
Sep.1,2017
EU RoHS Compliant
For
r o ur
-
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
T13E.pdf
Sep.1,2017
Contents
Product specifications are as of
September 2017
.
Bluetoothr is a registered trademark
or trademark of Bluetooth SIG, Inc.
in the United States and other countries.
Part Numbering
Selection Guide of Ceramic Trimmer Capacitors
1
TZR1 Series
p2
p3
p4
2
TZY2 Series
p8
3
TZC3 Series
p13
4
TZW4 Series
p18
5
TZB4 Series
p21
Packaging
Recommended Adjustment Tools
Qualified Standards
p26
p28
p29
Please check the MURATA website (http://www.murata.com/)
if you cannot find a part number in this catalog.
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
T13E.pdf
Sep.1,2017
o
Part Numbering
Ceramic Trimmer Capacitors
(Part Number)
1Product
ID
Product ID
TZ
2Series/Terminal
Code
B4
W4
C3
Y2
R1
3Temperature
Characteristics
Code
Z
R
K
P
Temperature Characteristics
NP0ppm/°C
N750ppm/°C
N1000ppm/°C
N1200ppm/°C
7Packaging
Code
B00
R00
R01*
* TZB4 only.
TZ
1
Y2
2
R 200 A C01 R00
3
4
5
6
7
5Terminal
Shape
Code
Terminal Shape
Top Adjustment:
TZR1, TZY2, TZC3, TZW4, TZB4
Top Adjustment:
TZB4
Trimmer Capacitors
A
B
Please refer to dimensions for terminal details.
Series/Terminal
4mm Size SMD Type
4mm Size SMD Type
3mm Size SMD Type
2mm Size SMD Type
1mm Size SMD Type
6Individual
Specifications
Code
001
C01
A01
A10
B10
Individual Specifications
TZR1, TZW4
Standard Type
TZY2
Standard Type
TZC3
Standard Type
TZB4
No-cover Film Standard Type
TZB4
with Cover Film Standard Type
Packaging
Bulk
Reel (Taping ø180mm)
Reel (Taping ø330mm)
Please refer to ratings for tolerance of temperature characteristics.
4Maximum
Capacitance
Expressed by three-digit alphanumerics. The unit is pico-farad
(pF). The first and second figures are significant digits, and the
third figure expresses the number of zeros that follow the two
numbers. If there is a decimal point, it is expressed by the capital
letter "R". In this case, all figures are significant digits.
2
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
T13E.pdf
Sep.1,2017
Selection Guide
Mounting Method?
Surface Mount
Reflow
Flow
Height 0.90mm max.
Height 1.7mm max.
High Frequency
Power
Height 2.6mm max.
Height 3.2mm max.
TZR1
1.5(W) x 1.7(L)
TZC3
3.2(W) x 4.5(L)
TZB4_AB
4.0(W) x 4.5(L)
(with cover film)
Height 1.25mm max.
Height 3.2mm max.
TZW4
4.2(W) x 5.2(L)
TZB4_BB
4.0(W) x 4.5(L)
(with cover film)
TZY2
2.5(W) x 3.2(L)
TZB4_AA
4.0(W) x 4.5(L)
TZB4_BA
4.0(W) x 4.5(L)
All Ceramic Trimmer Capacitor products comply with RoHS and ELV.
