CI100505-1N2D datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> CI100505-1N2D

CI100505-1N2D: DescriptionPhase Locked Loops - PLL WB Synthesizer w/ Intg VCO; CategoryPassive components inductor; File Size163KB，2 Pages; ManufacturerBourns; Websitehttp://www.bourns.com; Environmental Compliance

Download Datasheet Parametric Compare View All

CI100505-1N2D Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CI100505-1N2D	-	-	View	Buy Now

CI100505-1N2D Overview

Phase Locked Loops - PLL WB Synthesizer w/ Intg VCO

CI100505-1N2D Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Bourns
package instruction	0402
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	12 weeks
uppercase and lowercase codes	0402
structure	Rectangular
core material	CERAMIC
DC Resistance	0.09 Ω
Nominal inductance(L)	0.0012 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	0.5 mm
Package length	1 mm
Package form	SMT
Package width	0.5 mm
method of packing	TR, 7 Inch
Maximum rated current	0.3 A
self resonant frequency	6000 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
special characteristics	0.3NH IS THE TOLERANCE
surface mount	YES
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	100 MHz
Tolerance	25%

Preview

Download Datasheet

View All

Features

■

0402 size

■

Available in E12 Series

■

High frequency

■

Nickel barrier

■

RoHS compliant*

Applications

Mobile phones

■

Cellular phones

■

CTV, VCR, HIC, FDD

■

Automotive electronics

■

CI100505 Series - Multi-Layer Chip Inductors

Electrical Specifications

Bourns Part No.

Inductance

@100 MHz

Q Typ.

@100 MHz @500 MHz @1000 MHz

SRF MHz

DCR

I rms

CI100505-1N0D

CI100505-1N2D

CI100505-1N5D

CI100505-1N8D

CI100505-2N2D

CI100505-2N7D

CI100505-3N3D

CI100505-3N9D

CI100505-4N7D

CI100505-5N6D

CI100505-6N8J

CI100505-8N2J

CI100505-10NJ

CI100505-12NJ

CI100505-15NJ

CI100505-18NJ

CI100505-22NJ

CI100505-27NJ

CI100505-33NJ

CI100505-39NJ

CI100505-47NJ

CI100505-56NJ

CI100505-68NJ

CI100505-82NJ

CI100505-R10J

1.0

1.2

1.5

1.8

2.2

2.7

3.3

3.9

4.7

5.6

6.8

8.2

100

±0.3 nH

±5

Tol. %

—

6000

4000

3900

3600

3200

2700

2300

2100

1900

1600

1300

1200

1000

750

700

600

550

min.

13000

10000

9500

9000

8000

6500

5000

4400

4000

3500

3000

2600

2200

1900

1700

1600

1300

900

800

700

650

typ.

ohm max. mA max.

0.08

0.09

0.10

0.12

0.13

0.16

0.21

0.23

0.25

0.28

0.31

0.40

0.46

0.55

0.60

0.70

0.80

0.90

1.00

1.20

1.30

1.50

300

250

200

100

General Specifications

Temperature Rise

...................20 °C max. at rated current

Operating Temperature..-40 °C to +105 °C

Storage Temperature..-40 °C to +105 °C

Reflow Soldering ...230 °C, 50 sec. max.

Resistance to Soldering Heat

...............................260 °C, 10 seconds

Materials

Base Material .............................Ceramic

Terminal.....................................Ag/Ni/Sn

Packaging................10,000 pcs. per reel

Product Dimensions

0.5

0.05

(.020

.002)

0.4

MAX.

(.016)

1.0

0.05

(.039

.002)

0.5

0.05

(.020

.002)

Recommended Layout

0.5

(.020)

REF.

0.5

(.020)

REF.

Packaging Specifications

178.0

(7.00)

DIA.

2.0

0.8

(.079

.031)

12.0

(.472)

1.0

(.040)

REF.

0.4

REF.

(.016)

DIMENSIONS:

(INCHES)

21.0

0.8

(.827

.031)

13.0

0.5

(.512

.020)

DIA.

50.0

(1.969)

13.0

0.5

DIA.

(.512

.020)

9.0

(.354)

*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.

Specifications are subject to change without notice.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.

Users should verify actual device performance in their specific applications.

CI100505-1N2D Related Products

	CI100505-1N2D	BLU1206ER-4024-FB101W	CI100505-15NJ	CI100505-56NJ	CI100505-4N7D	CI100505-47NJ	CI100505-27NJ	CI100505-1N8D	GP56SER-2083-CTQ
Description	Phase Locked Loops - PLL WB Synthesizer w/ Intg VCO	Fixed Resistor, Thin Film, 0.25W, 4020000ohm, 150V, 1% +/-Tol, 100ppm/Cel, 1206,	RF Transceiver 2 receive by 2 transmit intgrtd frq	Fixed Inductors 56nH 5% MultiLayer High Frequency	LDO Voltage Regulators 150Ma Low Noise CMOS LDO	Fixed Inductors 47nH 5% MultiLayer High Frequency	Multilayer Ceramic Capacitors MLCC - SMD/SMT 0402 2.2uF 10volts *Derate Voltage/Temp	USB Connectors USB Mini-B Recept On-The-Go Rt.Angle	Fixed Resistor, Metal Film, 0.6W, 208000ohm, 250V, 0.25% +/-Tol, 100ppm/Cel,
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to	incompatible
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
structure	Rectangular	Chip	Rectangular	Rectangular	Rectangular	Rectangular	Rectangular	Rectangular	Cylindrical
JESD-609 code	e3	e3	e3	e3	e3	e3	e3	e3	e0
Number of terminals	2	2	2	2	2	2	2	2	2
Maximum operating temperature	125 °C	155 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	160 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Package length	1 mm	3.2 mm	1 mm	1 mm	1 mm	1 mm	1 mm	1 mm	6.3 mm
Package form	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT	Axial
method of packing	TR, 7 Inch	Bulk	TR, 7 Inch	TR, 7 Inch	TR, 7 Inch	TR, 7 Inch	TR, 7 Inch	TR, 7 Inch	TR
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier	Matte Tin (Sn) - with Nickel (Ni) barrier	Tin (Sn) - with Nickel (Ni) barrier	Matte Tin (Sn) - with Nickel (Ni) barrier	Matte Tin (Sn) - with Nickel (Ni) barrier	Matte Tin (Sn) - with Nickel (Ni) barrier	Matte Tin (Sn) - with Nickel (Ni) barrier	Matte Tin (Sn) - with Nickel (Ni) barrier	Tin/Lead (Sn/Pb)
Tolerance	25%	1%	5%	5%	6.383%	5%	5%	16.6667%	0.25%
Is it lead-free?	Lead free	-	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	-
Maker	Bourns	-	Bourns	Bourns	Bourns	-	Bourns	Bourns	-
package instruction	0402	-	0402	0402	0402	0402	0402	0402	-
Factory Lead Time	12 weeks	-	12 weeks	24 weeks	12 weeks	12 weeks	12 weeks	12 weeks	-
uppercase and lowercase codes	0402	-	0402	0402	0402	0402	0402	0402	-
core material	CERAMIC	-	CERAMIC	CERAMIC	CERAMIC	CERAMIC	CERAMIC	CERAMIC	-
DC Resistance	0.09 Ω	-	0.46 Ω	1 Ω	0.21 Ω	1 Ω	0.7 Ω	0.12 Ω	-
Nominal inductance(L)	0.0012 µH	-	0.015 µH	0.056 µH	0.0047 µH	0.047 µH	0.027 µH	0.0018 µH	-
Inductor Applications	RF INDUCTOR	-	RF INDUCTOR	RF INDUCTOR	RF INDUCTOR	RF INDUCTOR	RF INDUCTOR	RF INDUCTOR	-
Inductor type	GENERAL PURPOSE INDUCTOR	-	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	-
Number of functions	1	-	1	1	1	1	1	1	-
Package height	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	-
Package width	0.5 mm	1.6 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm	-
Maximum rated current	0.3 A	-	0.2 A	0.1 A	0.3 A	0.1 A	0.2 A	0.3 A	-
self resonant frequency	6000 MHz	-	2300 MHz	750 MHz	4000 MHz	1000 MHz	1600 MHz	6000 MHz	-
Shape/Size Description	RECTANGULAR PACKAGE	-	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	-
shield	NO	-	NO	NO	NO	NO	NO	NO	-
surface mount	YES	-	YES	YES	YES	YES	YES	YES	-
Terminal location	DUAL ENDED	-	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	-
Terminal shape	WRAPAROUND	-	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	-
Test frequency	100 MHz	-	100 MHz	100 MHz	100 MHz	100 MHz	100 MHz	100 MHz	-
