800-40-064-61-001000 datasheet, PDF

Datasheet> All Categories > The connector> The connector> 800-40-064-61-001000

800-40-064-61-001000: DescriptionHeaders u0026 Wire Housings 64P COMPLIANT TAIL PIN HDR SINGLE ROW; CategoryThe connector The connector; File Size448KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com; Environmental Compliance

Download Datasheet Parametric View All

800-40-064-61-001000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	800-40-064-61-001000	-	-	View	Buy Now

800-40-064-61-001000 Overview

Headers u0026 Wire Housings 64P COMPLIANT TAIL PIN HDR SINGLE ROW

800-40-064-61-001000 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mill-Max
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Connector type	BOARD CONNECTOR
Contact to complete cooperation	MATTE TIN (200) OVER NICKEL (150)
Contact completed and terminated	Matte Tin (Sn) - with Nickel (Ni) barrier
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	800
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	PRESS FIT
Total number of contacts	64

Preview

Download Datasheet

View All

INTERCONNECTS

SERIES 800 & 801 • .100” GRID (.030” DIA. PINS),

SOLDERLESS PRESS-FIT • SINGLE ROW STRIPS

Number of Pins

X .100"

.100

•

The unique compliant tail pins conform to

.040”+ .003” nished hole without stressing

inner layers. Patent No. 4,799,904

thicknesses of .060” - .100” and .090” - .130”.

See ordering information for details

#5602 compliant tail pins featuring a .030”

dia. mating lead. See page 220 for details

Hi-Rel, 6- nger BeCu #47 contact rated at

4.5 amps. Receptacles accept .030” diameter

pins & .025” square pins. See pg. 256 for details

.030 DIA.

.191

.110

•

Headers and sockets are available for board

.104

.045 DIA.

•

Series 800 pin headers use MM #5601 and

.100

.035 DIA.

.018

SLOT

•

Series 801 sockets MM #4614 or #4615 use

FIG. 1

.100

Number of Pins

X .100"

•

Insulators are high temperature thermoplastic

.030 DIA.

.191

ORDERING INFORMATION

Compliant Tail Pin Header for .060” - .100” Thick Boards

.143

.110

.045 DIA.

FIG. 1

.100

800 XX 0_ _ 61 001000

Specify number of pins

01-64

.035 DIA.

.018

SLOT

Compliant Tail Pin Header for .090” - .130” Thick Boards

FIG. 2

.025-.037

.025 * .025

.100

Number of Pins

X .100"

FIG. 2

RoHS - 2

800 XX 0_ _ 62 001000

Specify number of pins

XX=Plating Code

See Below

µ”

01-64

For

Electrical, Mechanical

& Enviromental Data,

See page 264

2011/65/EU

.088

.240

.276

SPECIFY PLATING CODE XX=

.104

200

µ”

Sn/Pb

200

µ”

.045 DIA.

Pin Plating

.100

.040 DIA.

.018

SLOT

Compliant Tail Socket for .060” - .100” Thick Boards

FIG. 3

.025-.037

.025 * .025

FIG. 3

Number of Pins

X .100"

801 XX 0_ _ 61 001000

Specify number of pins

01-50

Compliant Tail Socket for .090” - .130” Thick Boards

PAGE 56 | INTERCONNECTS

.100

FIG. 4

RoHS - 2

801 XX 0_ _ 62 001000

Specify number of pins

01-50

For

Electrical, Mechanical

& Enviromental Data,

See page 264

.088

.240

.276

.045 DIA.

.143

2011/65/EU

XX=Plating Code

See Below

µ”

.040 DIA.

.018

SLOT

.100

SPECIFY PLATING CODE XX=

Sleeve (Pin)

Contact (Clip)

200

µ”

200

µ”

Sn/Pb 200

µ”

Sn/Pb 200

µ”

Sn/Pb

200

µ”

FIG. 4

µ”

100

µ”

Sn/Pb

µ”

Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
