FEED-THROUGH FLAT BASE
EUROSTRIPS
Panel Mount
For wire-to-wire connections in
HVAC, appliance, equipment,
power distribution and other
industrial applications with strict
budget and space requirements.
Easy to use double row terminal
strips are a cost-effective alternative
to barrier strips or other types of
terminal blocks. Simply strip the
wire, insert and tighten the screw.
Eurostrips feature tubular screw
clamps, with wire protectors, and
recessed metal parts for finger
protection. The stainless steel wire
protectors exhibit excellent memory
and the wire stop insures the most
effective connection.
Eurostrips described on this and the
following page are available with a
flat base for minimum clearance
applications. They can be panel
mounted or left to free float.
Offered in easy to cut standard 12
pole strips, they can also be
ordered precut with the required
number of poles.
•
•
•
•
•
Tubular screw clamp
Panel mount or free float
Housing material: polyamide 6.6
Color: opaque white
Marking plates or factory
imprinted application
HE1
HE4
Flat base with wire protector
Flat base with wire protector
Pole Spacing
Mounting Hole Diameter
Stripping Length
Approvals
Wire Range
Voltage Rating
Current Rating
Torque
No. of Poles
2
3
4
5
6
7
8
9
10
11
12
1-2.5 mm
2
400 V
6A
0.5 Nm
Cat. No.
8 mm
3 mm
5 mm
10 mm
3.6 mm
6 mm
24-12 AWG
300 V
20 A
4.4 lb-in
Std. Pk.
100
100
100
100
50
50
50
50
50
50
50
2.5-4 mm
2
400V
10 A
0.8 Nm
Cat. No.
HE4WPR/02
HE4WPR/03
HE4WPR/04
HE4WPR/05
HE4WPR/06
HE4WPR/07
HE4WPR/08
HE4WPR/09
HE4WPR/10
HE4WPR/11
HE4WPR/12
24-10 AW
300
30 A
7.0 lb
Std. P
100
100
100
100
50
50
50
50
50
50
50
HE1WPR/02
HE1WPR/03
HE1WPR/04
HE1WPR/05
HE1WPR/06
HE1WPR/07
HE1WPR/08
HE1WPR/09
HE1WPR/10
HE1WPR/11
HE1WPR/12
A
B
A
B
C
D
E
F
J
C
D
E
F
J
M
K
G
L
H
I
N
G
L
H
I
N
Dimensions mm
A
B
C
D
E
F
G
= 8.0
= M2.6
= 5.2
= 2.8
= Ø3
= Ø5
= 8.0
H = Ø2.8
I = 2.8
J = 6.5
K = 6.5
L = 94 (12 pole)
M = 12.2
N = 16.2
A
B
C
D
E
F
G
= 10.0
= M3
= 6.4
= 3.5
= Ø3.6
= Ø5.7
= 10.0
Dimensions mm
H =
I =
J =
K =
L =
M=
N=
Ø3.6
3.2
8.5
7.9
117 (12 pole)
14.9
20.0
70
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
