MALE PCB
PINS
PRINTED CIRCUIT PINS
8600/8954/8955
8XXX-X-05-XX-00-00-03-0
Square press-fit in .043 plated through-hole
3159
3159-X-00-XX-00-00-08-0
Basic Part
Number
Pin
Length
A
Swage mount in .064 hole
Basic Part
Number
Board
Thickness
Length
V
8600-0
8600-1
8600-2
8954-0
8955-0
.400
.850
1.200
.136
.655
3159-1
3159-2
3159-3
3159-4
.031
.062
.094
.125
.062
.094
.125
.156
8952
8952-0-05-XX-00-00-03-0
Square press-fit in .087 plated through-hole
8953
8953-0-05-XX-00-00-03-0
Square press-fit in .047 plated through-hole
3230
3230-X-00-XX-00-00-08-0
Swage mount in .094 hole
Basic
Part
Number
.064 SQ.
.125
DIA.
.060
.120
Board
Thick-
ness
Length
A
Length
V
.035 SQ.
.072 DIA.
.036
.120
.080 DIA.
.440
3230-1
3230-2
3230-3
3230-4
.031
.062
.094
.125
.202
.228
.258
.288
.065
.095
.125
.155
.440
.040 DIA.
3146
3146-2-00-XX-00-00-08-0
Swage mount in .076 hole
For a .062 thick board
3142
3142-2-00-XX-00-00-08-0
Swage mount in .062 hole
For a .062 thick board
3232
3232-3-00-XX-00-00-08-0
Swage mount in .062 hole
For a .094 thick board
3145
3145-2-00-XX-00-00-08-0
Swage mount in .076 hole
For a .062 thick board
PAGE 222 | MALE PCB PINS
SPECIFICATIONS:
Pin Material:
Brass Alloy 360, 1/2 Hard
( Except swage pins which are annealed )
Dimensions: Inches
Tolerances On:
Lengths: ± .005
Diameters: ± .002
Angles:
±2°
RoHS - 2
2011/65/EU
ORDER CODE: XXXX - X - 0X -
XX
- 00 - 00 - XX - 0
BASIC PART #
SPECIFY PIN FINISH:
01
200
”
TIN/LEAD OVER NICKEL
80
200
”
TIN OVER NICKEL (RoHS)
15
10
”
GOLD OVER NICKEL (RoHS)
21
20
”
GOLD OVER NICKEL (RoHS)
34
50
”
GOLD OVER NICKEL (RoHS)
