Part Number

Search

M80-7172405

Description
Power to the Board 24S+2P VERT FM CONN
CategoryThe connector    The connector
File Size48KB,1 Pages
ManufacturerHarwin
Websitehttp://www.harwin.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

M80-7172405 Online Shopping

Suppliers Part Number Price MOQ In stock
M80-7172405 - - View Buy Now

M80-7172405 Overview

Power to the Board 24S+2P VERT FM CONN

M80-7172405 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerHarwin
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresPOLARIZED, SHROUDED
body width0.333 inch
subject depth0.247 inch
body length1.146 inch
Body/casing typePLUG
Connector typeBOARD CONNECTOR
Contact arrangementS24P2
Contact to complete cooperationGOLD
Contact completed and terminatedGold (Au)
Contact point genderFEMALE
Contact materialNOT SPECIFIED
Contact resistance25 mΩ
Contact styleHYBRID
DIN complianceNO
Durability500 Cycles
empty shellNO
Filter functionNO
IEC complianceNO
maximum insertion force2.78 N
Insulation resistance100000000 Ω
insulator materialPOLYAMIDE
JESD-609 codee4
MIL complianceNO
Plug informationMULTIPLE MATING PARTS AVAILABLE
Mixed contactsYES
Installation option 1LOCKING
Installation methodSTRAIGHT
Installation typeBOARD
Number of connectorsONE
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
OptionsGENERAL PURPOSE
Plating thickness12u inch
Rated current (signal)3 A
GuidelineUL
reliabilityCOMMERCIAL
Shell materialPLASTIC
Termination typeSOLDER
Total number of contacts26
UL Flammability Code94V-0

M80-7172405 Related Products

M80-7172405 M80-7104422 M80-7131522
Description Power to the Board 24S+2P VERT FM CONN Power to the Board 15S+2P MALE 90 DEG CONN
Is it lead-free? Lead free - Contains lead
Is it Rohs certified? conform to - incompatible
Maker Harwin - Harwin
Reach Compliance Code compliant - compliant
ECCN code EAR99 - EAR99
Other features POLARIZED, SHROUDED - TERMINAL PITCH FOR POWER CONTACTS: 4 MM
body width 0.333 inch - 0.358 inch
body length 1.146 inch - 1.46 inch
Body/casing type PLUG - RECEPTACLE
Connector type BOARD CONNECTOR - BOARD CONNECTOR
Contact arrangement S24P2 - S15P2
Contact to complete cooperation GOLD - GOLD (30)
Contact completed and terminated Gold (Au) - Tin/Lead (Sn/Pb)
Contact point gender FEMALE - MALE
Contact material NOT SPECIFIED - PHOSPHOR BRONZE
Contact resistance 25 mΩ - 25 mΩ
Contact style HYBRID - HYBRID
DIN compliance NO - NO
Durability 500 Cycles - 500 Cycles
Filter function NO - NO
IEC compliance NO - NO
Insulation resistance 100000000 Ω - 100000000 Ω
insulator material POLYAMIDE - POLYAMIDE
JESD-609 code e4 - e0
MIL compliance NO - NO
Mixed contacts YES - YES
Installation option 1 LOCKING - LOCKING
Installation method STRAIGHT - RIGHT ANGLE
Installation type BOARD - BOARD
Number of connectors ONE - ONE
Maximum operating temperature 125 °C - 125 °C
Minimum operating temperature -55 °C - -55 °C
Options GENERAL PURPOSE - GENERAL PURPOSE
Plating thickness 12u inch - 30u inch
Rated current (signal) 3 A - 3 A
Guideline UL - UL
reliability COMMERCIAL - COMMERCIAL
Termination type SOLDER - SOLDER
Total number of contacts 26 - 17
UL Flammability Code 94V-0 - 94V-0
