Self-Locking or Non-Self-Locking
AS85049/49-2 and MS27506
Straight Strain Relief
B
AS85049
CONNECTOR DESIGNATOR:
F
MIL-DTL-27599,
MIL-DTL-38999 Series I & II
Basic
Part Number
Dash No.
FOR NEW DESIGN
USE AS85049/121
M85049/49-2
S
10
W
Material and Finish Designator
A
= Aluminum, Black Anodize
N
= Aluminum, Electroless Nickel
S
= 300 Series Steel, Passivated
W
= Aluminum, 1000 Hour Cadmium
Olive Drab over Electroless Nickel
S
= Self-Locking
Use Dash for Non-Self-Locking
N
= Non-Detented
A Thread
F
Self-Locking
Only
Cable
Entry
Note: Screw
orientation shown is
for non-self-locking
configuration. Screws
on self-locking
configurations are on
the same side/face of
the clamp.
E
Self-Locking Only
H
TABLE I: Shell Size, Cable Entry and Backshell Dimensions
Shell
Size
8
10
12
14
16
18
20
22
24
Shell Size
Ref.
8/9
10/11
12/13
14/15
16/17
18/19
20/21
22/23
24/25
A Thread
Ø E Max
F Max
Class 2B
Self-Locking Only Self-Locking Only
.438 - 28 UNEF
.86
(21.8)
.91
(23.1)
.562 - 24 UNEF
.98
(24.9)
.91
(23.1)
.688 - 24 UNEF
1.16
(29.5)
1.01
(25.7)
.813 - 20 UNEF
1.28
(32.5)
1.06
(26.9)
.938 - 20 UNEF
1.41
(35.8)
1.16
(29.5)
1.063 - 18 UNEF
1.52
(38.6)
1.41
(35.8)
1.188 - 18 UNEF
1.64
(41.7)
1.51
(38.4)
1.313 - 18 UNEF
1.77
(45.0)
1.66
(42.2)
1.438 - 18 UNEF
1.89
(48.0)
1.76
(44.7)
H
Max
.85
(21.6)
.90
(22.9)
1.10
(27.9)
1.15
(29.2)
1.30
(33.0)
1.50
(38.1)
1.60
(40.6)
1.70
(43.2)
1.80
(45.7)
.098
.153
.190
.260
.283
.325
.343
.381
.418
Min
Cable Entry
.234
.234
.328
.457
.614
.634
.698
.823
.853
(2.5)
(3.9)
(4.8)
(6.6)
(7.2)
(8.3)
(8.7)
(9.7)
(10.6)
Max
(5.9)
(5.9)
(8.3)
(11.6)
(15.6)
(16.1)
(17.7)
(20.9)
(21.7)
APPLICATION NOTES
1.
2.
3.
4.
Assembly to be identified with manufacturer’s name and part number, space permitting.
Cable Entry is defined as the accommodation entry for the wire bundle or cable.
Dimensions are not intended for inspection criteria.
For complete dimensions, see the applicable Military Specification.
Metric dimensions (mm) are in parentheses.
© 2013 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
B-74
