7000 Push Button Switches
16A 250Vac
Round and rectangular
push button switches
Ratings up to 16A,
250V ac
Latching and
momentary
Illuminated & non-
illuminated
Matching indicators
Low profile version
Panel cut outs:
25.0 dia
27.2 x 22.3
NON-LIT
B
BLACK
R
RED
W
WHITE
LIT
AMBER
CLEAR
GREEN
RED
3mm contact gap.
Technical data on pages 4 & 5 (switches), 6 (indicators).
16(4)A 250Vac T125
8(8)A 250Vac T85
UL CSA 16A Non Ind, 250Vac 1hp, 125Vac 1/2hp
UL 65°C, file no. E45221, CSA file no. LR10990
RoHS
RoHS compliant
B
BLACK
R
RED
W
WHITE
push
switches
A
C
G
R
2
125V NEON
3
250V NEON
7
12V INCANDESCENT
C 7053 A F W R 2 ---------
ORDER FORMAT
TERMINAL
C
7000
9.1
TERMINAL
CODE
FUNCTION
CODE
ACTUATOR
CODE
BODY BODY ACTUATOR
CODE COLOR
COLOR
LAMP VOLTAGE
IF REQUIRED
ACTUATOR
A
Round actuator
LEGEND &
OPTIONS
FUNCTION
Single pole ON - OFF
shown in F body
21.0
9.7
2
6.3 x 0.8
1
7001
Single pole ON - OFF
(momentary ON)
A
Round actuator
shown in G body
7003
4
2
1
Single pole ON - OFF
with light
B
Round actuator - medium
shown in F body
ø21.1
ø11.5
18.6
9.7
16.9
20.0
29.5
7004
Single pole ON - OFF
(momentary ON) with light
7050
H
4
2
9.1
Double pole ON - OFF
C
Round actuator - long
shown in F body
ø21.1
ø11.2
3
1
Double pole ON - OFF
(momentary ON)
7051
4.8 x 0.8
D
Round actuator - sub panel mount
7053
4
2
7054
3
1
Double pole ON - OFF
with light
ø21.1
Double pole ON - OFF
(momentary ON) with light
S
Rectangular actuator
Shown in “A” body
N/A for 7030
19.5
8.8
4
7030
2
Indicator
44
Phone: 760-343-3650 •
Arcolectric
• Email: americas@elektron-technology.com
9.1
C7000AF ---
C7003AF ---
C7053CF ---
C7053BF ---
push
switches
C7050SA ---
C7053AG ---
C7053DF ---
C7030AH ---
BODY
Panel cut-outs
OPTIONS
Finish
Matt finish is standard on bodies
Gloss finish is standard on actuators
DIMENSIONS
(mm)
Panel thickness:
A
0.8 - 2.5mm
F, G, H
0.8 - 5.0mm
F H G
Body types fit either cut-out
Color
Call factory for custom colors
A full range is available for large orders
Legend printing
25.0/25.2
A wide range is available or call the
factory for custom legends
A
2.0
36.2
Lamp voltage
O 23.5/23.7
/
1.7
1.9
21.0
O 25.0/25.2
/
30.0
Call factory for details of other
available voltages
Weatherproof housing (E)
Additional housing which fits round body
switches with an oversize housing with a clear
silicone cover designed to IP65. Mounting hole
dia: 38.0mm
24.0
8.8
3.5
34.7
F
Ø28.0
‘OFF’
‘ON’
A
4.0
G
switch only
27.2
27.3
Ø28.0
2.0
43.2
22.3/22.4
H
7030 Indicator only
Accepts A lens only
Ø28.0
Cut-outs must be punched in the direction of insertion
3.5
16.0
9.8
