TLR
-2BW, 2BP, 2HW, 3AP, 3APS
metal plate current sense resistor
NEW
NEW
resistors
L
W
t
d
EU
features
•
Ultra-low TCR (+50ppm/°C) available
•
Metal alloy: superior corrosion and heat resistance
•
Applications include current sensing, voltage division
and pulse applications
•
Ultra low resistance (0.5mΩ - 20mΩ)
•
Suitable for reflow soldering (Not suitable for flow soldering)
•
Products with lead-free terminations meet EU RoHS
and China RoHS requirements
•
AEC-Q200 Qualified
dimensions and construction
Protective Top Coating
TLR2BW (1mΩ, 1.5mΩ)
TLR2BP (1mΩ, 1.5mΩ)
TLR3AP (0.5m-1.5mΩ)
TLR3APS (2mΩ)
Resistive Element
Termination
Solder
Size
Code
Resistance
L
Dimensions
inches
(mm)
W
d
t
d
Protective
Bottom Coating
TLR2BW (1m-5mΩ)
TLR2BP (1m-5mΩ)
TLR2HW (1m-3mΩ)
TLR3AP (0.5m-1.5mΩ)
TLR3APS
(2mΩ, 3mΩ)
1mΩ
.043±.008
New
1.5mΩ .126±.008 .063±.008
(1.10±0.20)
TLR2BW
(3.20±0.20) (1.60±0.20)
.020±.008
2mΩ - 20mΩ
(0.50±0.20)
1mΩ,
.043±.008
1.5mΩ
.126±.008 .063±.008
(1.10±0.20)
TLR2BP
(3.20±0.20) (1.60±0.20)
.020±.008
2mΩ - 20mΩ
(0.50±0.20)
.071±.008
1mΩ
(1.80±0.20)
.024±.008
(0.60±0.20)
.024±.008
(0.60±0.20)
.026±.008
(0.65±0.20)
.200±.008 .100±.008 .060±.008
TLR2HW
2mΩ - 6mΩ
(5.00±0.20) (2.50±0.20) (1.50±0.20)
.024±.008
(0.60±0.20)
.020±.008
7mΩ - 10mΩ
(0.50±0.20)
.107±.01
0.5mΩ
(2.725±0.25)
0.68mΩ,
0.75mΩ,
0.82mΩ
.105±.01
(2.675±0.25)
.087±.01
.25±.01
.125±.01
(2.20±0.25)
.024±.01
TLR3AP
(6.35±0.25) (3.18±0.25)
(0.62±0.25)
.098±.01
2mΩ
(2.50±0.25)
5mΩ, 6mΩ,
.047±.01
7mΩ, 8mΩ
(1.20±0.25)
9mΩ, 10mΩ
TLR3APS
2mΩ, 3mΩ
.030±.01
(0.77±0.25)
.25±.01
.125±.01 .047±.01 .024±.01
(6.35±0.25) (3.18±0.25) (1.20±0.25) (0.60±0.25)
1mΩ, 1.5mΩ,
3mΩ, 4mΩ
ordering information
New Part #
TLR
Type
2BW
Power
Rating
2BW: 1W
New
2BP: 1.5W
2HW: 2W
3AP: 3W
New
3APS: 3W
D
Termination
Material
D: SnAgCu
TD
Packaging
TD: 7" 4mm pitch
punched paper
TE: 7" 4mm
embossed plastic
10L0
Nominal
Resistance
±1%: 4 digits
All values less than
0.1Ω (100m) are
expressed in mW
with “L” as decimal
Ex: 2mΩ = 2L00
F
Tolerance
F: ±1%
75
T.C.R.
50: 50ppm/°C
75: 75ppm/°C
For further information on packaging, please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
12/15/16
96
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
metal plate current sense resistor
applications and ratings
Part
Designation
Power
Rating
T.C.R.
(ppm/°C)
Max.**
±50
TLR2BW
1W
±75
±50
NEW
TLR2BP
1.5W
±75
±50
±75
±50
TLR3AP
3W
±75
NEW
TLR3APS
3W
±50, ±75
Standard
Resistance
(Ω)
2m,3m,4m,5m,6m,7m,8m,
9m,10m,11m,12m,13m,
15m,16m,18m,20m
1m,1.5m,2m,3m,4m,5m,6m,
7m,8m,9m,10m,11m,12m,
13m,15m,16m,18m,20m
2m,3m,4m,5m,6m,7m,8m,9m,10m
11m,12m,13m,15m,16m,18m,20m
1m,1.5m,2m,3m,4m,5m,6m,
7m,8m,9m,10m
11m,12m,13m,15m,16m,18m,20m
Resistance
Tolerance
Rated
Terminal Part
Temperature
Operating
Temperature
Range
F: ±1%
+120°C and less
-65°C to +170°C
+110°C and less
+100°C and less
F: ±1%
+110°C and less
+100°C and less
F: ±1%
+120°C and less
0.5m ~ 8m:
+110°C and less
9m, 10m: +90°C
and less
+110°C and less
-65°C to +170°C
-65°C to +170°C
TLR2HW
2W
1m,2m,2.5m,3m,4m,5m,
6m,7m,8m,9m,10m
2m,3m,4m,5m
6m,7m,8m,9m,10m
0.5m,0.68m,0.75m,
0.82m,1m,1.5m,2m,3m,4m,
5m,6m,7m,8m,9m,10m
F: ±1%
-65°C to +170°C
2m,3m
F: ±1%
-65°C to +170°C
environmental applications
Derating Curve
TLR2BW, TLR2BP, TLR2HW
100
2BP (11m – 20mΩ)
2BW, 2HW
Temperature Rise
TLR3AP, TLR3APS
100
80
TLR2BP/2HW 6mΩ
200
175
Temperature Rise
(°C)
TLR3AP 4mΩ
200
175
3AP (1)
% Rated Power
2BP (1m –
10mΩ)
% Rated Power
150
2HW (1)
2BP (1)
60
40
20
0
-80
60
40
20
0
-80
125
100
75
50
25
2BP (2)
2HW (2)
Temperature Rise
(°C)
80
150
125
75
50
25
0
100
3AP (2)
-60 -40 -20
-65
20 40 60 80 100 120 140 160 180
110
170
Terminal Part Temperature
(°C)
0
-60 -40 -20
-65
0 20 40 60 80 100 120 140 160 180
90 110
170
Terminal Part Temperature
(°C)
0
0
25
50
75
100
0
25
50
75
100
% Rated Power
% Rated Power
1 Hot
Spot
2 Solder
Joint
For resistors operated at a terminal part temperature of described for each size or above,
a power rating shall be derated in accordance with the derating curve.
Please refer to “Introduction of the derating curve based in the terminal part temperature”
in the beginning of our catalog before use.
Regarding the temperature rise, the
value of the temperature varies per
conditions and board for use since
the temperature is measured under
our measuring conditions.
Performance Characteristics
Parameter
Resistance
T.C.R.
Resistance to Solder Heat
Rapid Change of Temperature
Moisture Resistance
Biased Humidity
Endurance of Rated Terminal
Part Temperature
Requirement
∆
R ±%
Limit
Typical
Within regulated
—
tolerance
Within specified
—
T.C.R.
±0.5%
±0.3%
±0.5%
±0.3%
±0.5%
±0.1%
±0.5%
±0.1%
±1.0%
±1.0%
±2.0%
2BW: ±1.0%
±0.3%
±0.6%
±0.8%
––
Test Method
25°C
+25°C/+125°C
260°C ± 5°C, 10 ± 2 seconds
-55°C (15 minutes), +150°C (15 minutes), 1000 cycles
MIL-STD-202-106, 0% power, 7a and 7b not required
85°C ± 2°C, 85% RH, 1000 hours, 10% bias
120°C ± 2°C (2BW, 2HW), 110°C ± 2°C (3AP 0.5mΩ~8mΩ)
90°C ± 2°C (3AP 9mΩ~10mΩ), 110°C±2°C (2BP 1mΩ-10mΩ)
100°C±2°C (2BP 11mΩ-20mΩ), 110°C±2°C (3APS 2mΩ, 3mΩ)
1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
±155°C, 1000 hours
±170°C, 1000 hours
±170°C ±3°C, 2000 hours
2/20/17
High Temperature Exposure
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
97
resistors
TLR
-2BW, 2BP, 2HW, 3AP, 3APS
