08055C822J4T2A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> 08055C822J4T2A

08055C822J4T2A: DescriptionMultilayer Ceramic Capacitors MLCC - SMD/SMT 50V 8200pF X7R 0805 5% Tol; CategoryPassive components; File Size90KB，5 Pages; ManufacturerAVX

Download Datasheet Parametric View All

08055C822J4T2A Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	08055C822J4T2A	-	-	View	Buy Now

08055C822J4T2A Overview

Multilayer Ceramic Capacitors MLCC - SMD/SMT 50V 8200pF X7R 0805 5% Tol

08055C822J4T2A Parametric

Parameter Name	Attribute value
Product Category	Multilayer Ceramic Capacitors MLCC - SMD/SMT
Manufacturer	AVX
RoHS	Details
Capacitance	8200 pF
Voltage Rating DC	50 VDC
Dielectric	X7R
Tolerance	5 %
Case Code - in	0805
Case Code - mm	2012
Height	0.94 mm
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 55 C
Termination	-
Product	Automotive MLCCs
Qualification	AEC-Q200
Packaging	MouseReel
Packaging	Reel
Packaging	Cut Tape
Capacitance - nF	8.2 nF
Capacitance - uF	0.0082 uF
Length	2 mm
Package / Case	0805 (2012 metric)
Factory Pack Quantity	4000
Termination Style	SMD/SMT
Type	Automotive MLCCs X7R Dielectric
Width	1.25 mm
Unit Weight	0.000194 oz

Preview

Download Datasheet

View All

Automotive MLCC

Automotive

GENERAL DESCRIPTION

AVX Corporation has supported the Automotive Industry requirements for Multilayer

Ceramic Capacitors consistently for more than 10 years. Products have been de- veloped

and tested specifically for automotive applications and all manufacturing facilities are

QS9000 and VDA 6.4approved.

As part of our sustained investment in capacity and state of the art technology, we are now

transitioning from the established Pd/Ag electrode system to a Base Metal Electrode

system (BME).

AVX is using AECQ200 as the qualification vehicle for this transition. A detailed qualification

package is available on request and contains results on a range of part numbers including:

•

X7R dielectric components containing BME electrode and copper

terminations with a Ni/Sn plated overcoat.

•

X7R dielectric components, BME electrode with epoxy finish for conductive glue mounting.

•

X7R dielectric components BME electrode and soft terminations with a Ni/Sn plated over-

coat.

•

NP0 dielectric components containing Pd/Ag electrode and silver termination with a Ni/Sn

plated overcoat.

HOW TO ORDER

0805

Size

0402

0603

0805

1206

1210

1812

Voltage

10V =Z

16V =Y

25V =3

50V =5

100V =1

200V =2

250V = V

500V =7

Dielectric

NP0 = A

X7R = C

X8R =F

104

Capacitance

Code (In pF)

2Significant

Digits + Numberof

Zeros

e.g. 10µF =106

Capacitance

Tolerance

F =±1%

(≥10pF)*

G =±2%

(≥10pF)*

J =±5%

(≤1µF)

K =±10%

M =±20%

*NPOonly

Failure Rate

4 = Automotive

Terminations

T = Plated Ni and Sn

Z =FLEXITERM

U =Conductive Epoxy**

**X7R & X8Ronly

Packaging

2 = 7" Reel

4 =13" Reel

Special Code

A = Std. Product

Contact factory for availability of Tolerance Options for Specific PartNumbers.

NOTE: Contact factory for non-specified capacitancevalues.

0402 case size available in T termination only.

COMMERCIAL VS AUTOMOTIVE MLCC PROCESS COMPARISON

Administrative

Design

Dicing

Lot Qualification

(Destructive Physical

Analysis - DPA)

Visual/Cosmetic Quality

Application Robustness

Commercial

Standard Part Numbers.

No restriction on who purchases these parts.

Minimum ceramic thickness of 0.020"

Side & End Margins = 0.003" min

As per EIA RS469

Automotive

Specific Automotive Part Number. Used to control

supply of product to Automotive customers.

Minimum Ceramic thickness of 0.029" (0.74mm)

on all X7R product.

Side & End Margins = 0.004" min

Cover Layers = 0.003" min

Increased sample plan –

stricter criteria.

100% inspection

Increased sampling for accelerated wave solder on

X7R and NP0 followed by lot by lot reliability testing.

Standard process and inspection

Standard sampling for accelerated

wave solder on X7R dielectrics

All Tests have Accept/Reject Criteria 0/1

112817
