High-Performance DAQ
PXI/DAQ/DAQe-2000 Series
4-CH 14/16-Bit Up to 2 MS/s Simultaneous-Sampling DAQ Cards
Ordering Information / Quick Selection Guide
Model Name
No. of
channels
PXI/DAQ/DAQe-2010
4-CH DI
4-CH DI
4-CH DI
Analog Input
Resolution
14 Bit
16 Bit
16 Bit
Sampling
rate
2 MS/s
500 kS/s
250 kS/s
Input range
±1.25 V to ±10 V
±1.25 V to ±10 V
±1.25 V to ±10 V
No. of
channels
2
2
2
Analog Output
Resolution
12 Bit
12 Bit
12 Bit
Update rate
1 MS/s
1 MS/s
1 MS/s
DIO
No. of channels
24-CH 8255 PIO
24-CH 8255 PIO
24-CH 8255 PIO
Timer/Counter
No. of channels
2-CH, 16-Bit
2-CH, 16-Bit
2-CH, 16-Bit
PXI-2010
PXI/DAQ/DAQe-2005
PXI/DAQ/DAQe-2006
Specifications
Model Name
Analog Input
Resolution
Number of channels
Maximum sampling rate
Programmable gain
Bipolar input ranges
Unipolar input ranges
Offset error
Gain error
Input Coupling
Overvoltage protection
Input Impedance
Trigger sources
Trigger modes
FIFO buffer size
Data transfers
Analog Output
Number of channels
Resolution
Output ranges
Maximum update rate
Slew rate
Settling time
Offset error
Gain error
Driving capacity
Stabililty
Trigger sources
Trigger modes
FIFO buffer size
Data transfers
Digital I/O
Number of channels
Compatibility
Data transfers
Timer/Counter
Number of channels
Resolution
Compatibility
Base clock available
General Specifications
Auto Calibration
Dimensions
PXI/DAQ/DAQe-2010
14 Bit
PXI/DAQ/DAQe-2005
PXI/DAQ/DAQe-2006
DAQ-2010
DAQe-2010
16 Bit, no missing codes
16 Bit, no missing codes
4 simultaneous-sampling channels with differential input
2 MS/s
500 kS/s
250 kS/s
1, 2, 4, 8
±10 V, ±5 V, ±2.5 V, ±1.25 V
0-10 V, 0-5 V, 0-2.5 V, 0-1.25 V
±3 mV
2 mV
±1 mV
±0.1% of FSR
±0.04% of FSR
±0.03% of FSR
DC
Power on: Continuous ±35 V, Power off: Continuous ±15 V
1 GΩ/100 pF
Software, external digital/analog trigger, SSI bus
Pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger
8 k samples
512 samples
512 samples
Polling, scatter-gather DMA
2 voltage outputs
12 Bit
0-10 V, ±10 V, 0-AOEXTREF, ±AOEXTREF
1 μs
20 V/μs
3 μs to ±0.5 LSB accuracy
±3mV
±1mV
±1mV
±0.05% of max. output
±0.04% of max. output
±0.04% of max. output
5 mA
Any passive load, up to 1500 pF
Software, external digital/analog trigger, SSI bus
Post-trigger, delay-trigger, and repeated trigger
2 k samples
Programmed I/O, scatter-gather DMA
8255 24-Bit programmable input/output
5 V/TTL
Programmed I/O
2
16 Bit
5 V/TTL
40 MHz , external clock up to 10 MHz
Yes (+5 V,
±2 ppm/˚C)
160 mm x 100 mm (not including connectors) (PXI-2000 series)
175 mm x 107 mm (not including connectors) (DAQ-2000 series)
168 mm x 107 mm (not including connectors) (DAQe-2000 series)
68-pin VHDCI-type female
0˚C to 55˚C (32˚F to 131˚F )
-20˚C to 70˚C (-4˚F to 158˚F)
5 to 95%, non-condensing
+5 V 1.82 A typical (PXI/DAQ-2010) +5 V 2.04 A typical (PXI/DAQ-2005) +5 V 1.82 A typical (DAQ-2006)
+3.3 V 1.02 A, +12 V 0.67 A
+3.3 V 1.03 A, +12 V 0.75 A
+3.3 V 1.246 A, +12 V 0.448 A
typical (DAQe-2006)
typical (DAQe-2005)
typical (DAQe-2010)
Features
■
■
■
■
■
■
■
■
■
■
■
■
■
Supports a 32-Bit 3.3 V or 5 V PCI bus (DAQ-2000 series)
x1 lane PCI Express
®
Interface (DAQe-2000 series)
PXI specification Rev. 2.2 compliant (PXI-2000 series)
4-CH differential analog inputs
Bipolar or unipolar analog input ranges
Programmable gains of x1, x2, x4, x8
Scatter-gather DMA for both analog inputs and outputs
2-CH 12-Bit multiplying analog outputs with waveform
generation
24-CH TTL digital input/output
2-CH 16-Bit general-purpose timer/counter
Analog and digital triggering
Fully auto calibration
Multiple cards synchronization through SSI (System
Synchronization Interface) bus or PXI trigger bus
■ Supported
Operating System
• Windows
7/8 x64/x86, Linux
• LabVIEW,
MATLAB, C/C++, Visual Basic,
Visual Studio.NET
■ Software
Utility
• AD-Logger
■ Driver
and SDK
Connector
Operating temperature
Storage temperature
Humidity
Power requirements
Terminal Boards & Cables
■ DIN-68S-01
■ ACL-10568-1
■ ACL-SSI-2/3/4
* For more information on mating terminal board and cables, please
refer to P3-48/49.
Updated September 23, 2014. ©2014 ADLINK Technology, Inc. All Rights Reserved. All specifications are subject to change without further notice.
www.adlinktech.com 3-20
