MMBFJ310LT1

Description
JFET 25V 10mA
CategoryDiscrete semiconductor    The transistor
File Size109KB,5 Pages
ManufacturerON Semiconductor
Websitehttp://www.onsemi.cn
Download Datasheet Parametric View All

MMBFJ310LT1 Online Shopping

Suppliers Part Number Price MOQ In stock
MMBFJ310LT1 - - View Buy Now

MMBFJ310LT1 Overview

JFET 25V 10mA

MMBFJ310LT1 Parametric

Parameter NameAttribute value
Brand NameON Semiconductor
Is it lead-free?Contains lead
MakerON Semiconductor
Parts packaging codeSOT-23
package instructionCASE 318-08, 3 PIN
Contacts3
Manufacturer packaging code318-08
Reach Compliance Codenot_compliant
ECCN codeEAR99
Factory Lead Time1 week
Is SamacsysN
ConfigurationSINGLE
Minimum drain-source breakdown voltage25 V
FET technologyJUNCTION
Maximum feedback capacitance (Crss)2.5 pF
highest frequency bandULTRA HIGH FREQUENCY BAND
JEDEC-95 codeTO-236AB
JESD-30 codeR-PDSO-G3
JESD-609 codee0
Humidity sensitivity level1
Number of components1
Number of terminals3
Operating modeDEPLETION MODE
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)240
Polarity/channel typeN-CHANNEL
Maximum power dissipation(Abs)0.225 W
Certification statusNot Qualified
surface mountYES
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperature30
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
Base Number Matches1
MMBFJ309L, MMBFJ310L,
SMMBFJ309L, SMMBFJ310L
JFET - VHF/UHF Amplifier
Transistor
N−Channel
Features
http://onsemi.com
2 SOURCE
Drain and Source are Interchangeable
S Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC−Q101 Qualified and
PPAP Capable
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
MAXIMUM RATINGS
Rating
Drain−Source Voltage
Gate−Source Voltage
Gate Current
Symbol
V
DS
V
GS
I
G
Value
25
25
10
Unit
Vdc
Vdc
mAdc
1
3
GATE
1 DRAIN
3
2
SOT−23 (TO−236)
CASE 318
STYLE 10
THERMAL CHARACTERISTICS
Characteristic
Total Device Dissipation FR−5 Board,
(Note 1) T
A
= 25°C
Derate above 25°C
Thermal Resistance, Junction−to−Ambient
Junction and Storage Temperature
Symbol
P
D
Max
225
1.8
556
−55
to +150
Unit
mW
mW/°C
°C/W
°C
6x
MARKING DIAGRAM
6x M
G
G
1
= Device Code
x = U for MMBFJ309L, SMMBFJ309L
x = T for MMBFJ310L, SMMBFJ310L
= Date Code*
= Pb−Free Package
R
qJA
T
J
, T
stg
Stresses exceeding Maximum Ratings may damage the device. Maximum
Ratings are stress ratings only. Functional operation above the Recommended
Operating Conditions is not implied. Extended exposure to stresses above the
Recommended Operating Conditions may affect device reliability.
1. FR−5 = 1.0 x 0.75 x 0.062 in.
M
G
(Note: Microdot may be in either location)
*Date Code orientation and/or overbar may
vary depending upon manufacturing location.
ORDERING INFORMATION
Device
MMBFJ309LT1G,
SMMBFJ309LT1G
MMBFJ310LT1G,
SMMBFJ310LT1G
SMMBFJ310LT3G
Package
SOT−23
(Pb−Free)
SOT−23
(Pb−Free)
SOT−23
(Pb−Free)
Shipping
3,000 / Tape &
Reel
3,000 / Tape &
Reel
10,000 / Tape &
Reel
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
©
Semiconductor Components Industries, LLC, 2013
October, 2013
Rev. 7
1
Publication Order Number:
MMBFJ309LT1/D
