This document was generated on 03/19/2013
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
85013-2282
Active
DIN 41612
2.54mm Pitch DIN 41612 Header, Through Hole, Vertical, C-Pin Press-Fit Style R
Reverse, 1µm Selective Gold (Au), 64 Circuits, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-85013-0002 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
LR19980
E29179
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Low-Halogen
China RoHS
Agency Certification
CSA
UL
General
Product Family
Series
Application
Component Type
Overview
Product Name
Style
UPC
Backplane Connectors
85013
Daughtercard
PCB Header
DIN 41612
IEC 603-2/DIN 41612
R
800753874510
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Plating Mating
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
64
96
Rows A & C
500
No
94V-0
No
Yes
Gold
14.209/g
32
Open Pin Field
3
Vertical
13.25mm
No
Yes
Tray
2.54mm
2.54mm
1.016µm
No
No
No
-55°C to +125°C
Search Parts in this Series
85013Series
Mates With
85042 DIN 41612 Receptacle. 85052 DIN
41612 Header
Use With
85089-1079 Press-in Tool
Electrical
Current - Maximum per Contact
Data Rate
Real Signals (per 25mm)
Shielded
2.5A
622.0 Mbps
30
No
Voltage - Maximum
1000V (RMS)
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-85013-0002
610-6043-201, SD-85013-2282
