PCB
Wire
ACCESSORIES
Wire & Wiring Tools
P160-2B
Manual Wrap Tool
This tool makes
standard or modified
wrap wire joints with
#26 thru #30 gage
wire. The tool will
make wrapped wire
connections manually
with either left or right
hand rotation. Tool
will also strap short
lengths of bare wire
manually. Provides
gas tight permanent
connections with a
long life bit and sleeve.
P180-1
Manual Slit-N-
Wrap
®
tool with #28
ga. Polyurethane
wire
Unwraps #26 thru #30
gage wire manually.
Outer spring loaded
sleeveretainswireafter
unwrapping and ejects
wire. The unwrapping bit
is recessed into the
sleeve to permit
unwrapping beyond the
maximum amount of
turns needed on .025"
square wrap posts.
Bitincluded.
Replacement bit, 01/1
An excellent selection of wire products, many choices
of gage size, color, and insulating materials.
Wire For Slit-N-Wrap
®
Wire Wrapping Tools
Tefzel Insulated Silver Plated Wire for use with No. 02 Bit
Part No
A W G
Color Spool
Dia.
Feet per
Spool
Spools
Per Pkg.
W28-6A
W28-6B
W28-6D
W28-6E
W28-6F
W28-6H
W28-6AU
W28-6BU
W28-6DU
W28-6EU
W28-6FU
W28-6HU
28
28
28
28
28
28
28
28
28
28
28
28
green
red
blue
white
yellow
black
green
red
blue
white
yellow
black
1"
1"
1"
1"
1"
1"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
50
50
50
50
50
50
150
150
150
150
150
150
2
2
2
2
2
2
1
1
1
1
1
1
P184-1
Manual Slit-N-Wrap
®
tool with #28 ga.
Tefzel wire
Provides two 50'
spools of #28 gage
Tefzel,silverplated
wire (.023" D. total) on
small bracket. Wrap
bit
No.02
isinstalled
Replacement bit 02/1
P184-6
Manual Slit-N-
Wrap
®
tool with
#30 ga. Tefzel wire
Mounts 200' spool of
#30 gage silver plated
Tefzel wire on P160-
6A tension regulator.
Wrap bit
No. 04
is
installed.
Replacement bit, 04/1
Tefzel Insulated Silver Plated Wire for use with No. 04 Bit
Part No
A W G
Color Spool
Dia.
Feet per
Spool
Spools
Per Pkg.
W30-6D
W30-6E
W30-6F
W30-6J
30
30
30
30
blue
white
yellow
orange
1-1/2"
1-1/2"
1-1/2"
1-1/2"
200
200
200
200
1
1
1
1
P160-1B
Wire For Conventional Wire Wrapping, Kynar Insulated Wire,
Silver Plated, Solid Conductor, Easy Stripping, for use with
No. 03 Bit
Part No
A W G
Color Spool
Dia.
Feet per
Spool
Spools
Per Pkg.
W30-5A
W30-5B
W30-5E
W30-5F
W30-5AS
W30-5BS
W30-5ES
W30-5FS
30
30
30
30
30
30
30
30
®
green
red
white
yellow
green
red
white
yellow
1"
1"
1"
1"
2"
2"
2"
2"
75
75
75
75
300
300
300
300
1
1
1
1
1
1
1
1
Unwraps #26 thru #30 gage wire manu-
ally. Outer spring loaded sleeve retains
wire after unwrapping and ejects wire.
The unwrapping bit is recessed far enough
into the sleeve to permit unwrapping more
than the maximum amount of turns
needed on .025" square wrap posts.
Bit included.
Products
P184-1
P184-6
Slit-N-Wrap Wire-Wrapping Tools
No Stripping / No Pre-cutting / No Pre-measuring
•
•
•
•
•
•
•
•
No Loading
Daisy Chain Wraps
Quick Change Bits
Reliable Wraps meet MIL-STD-1130B, par. 5.6
US & Foreign Patents
4X Faster Than Conventional Wrap
Replaceable Bits, Set-Screw Mounted, Simplify Maintenance And
Insure Reliability, Reduce Costs and Downtime.
Use Lower Profile Sockets And Pins
Shows stripping action
of Slit-N-Wrap process.
Insulation
Copper
How the Systems Work:
Insulated wire is pulled past a sharp cutter adjacent to the wrap
point where a narrow slit is cut in the wire longitudinally. As the wire is
pulled along the wrap post, it is caused to twist along the path from the
cuter to the post. Further opening the slit and exposing the bared
conductor to the post corner, indenting both it and the post to produce
gas tight joints at each corner.
Figure above shows wire which has been unwrapped after going
through this action. Note the narrow channel where the insulation has
been pushed aside to bare the conductor against the post corner and to
indent both. No insulation is removed but is spread out to fit in the
space between the coils.
P/N 184-6
Uses 200' spool of silver plated Tefzel wire on tension regulator. Supplied with 1 200'
spool of Tefzel wire, and accessories.
P/N 184-1
Uses 50' spools of Tefzel 28 ga. wire. Tension regulator spring reduces wire breakage.
Supplied with 2 50' spools of Tefzel wire and accessories.
