Output voltage detection pin / ADJ for BD9106½07FVM
GmAmp output pin/connected to phase compensation capacitor
Enable pin(active high)
Ground pin
Power switch ground pin
Power switch node
Power switch supply pin
Power supply input pin
Function
Output voltage detection pin
Power supply input pin
GmAmp output pin/connected to phase compensation capacitor
Ground pin
Power switch ground pin
Power switch node
Power switch supply pin
Enable pin(active high)
Function
Output voltage detection pin
GmAmp output pin/connected to phase compensation capacitor
Enable pin(active high)
Ground pin
Power switch ground pin
Power switch node
Power switch supply pin
Power supply input pin
2/46
TSZ02201-0J3J0AJ00090-1-2
02.Oct.2014 Rev.003
BD9106FVM
Lineup
Operating
Temperature
Range
BD9107FVM
Input
Voltage
Range
4.0V to 5.5V
BD9109FVM
Output
Voltage
Range
Adjustable
(1.0V to 2.5V)
Adjustable
(1.0V to 1.8V)
3.30±2%
Adjustable
(1.0V to 1.5V)
Adjustable
(1.0V to 2.5V)
BD9110NV
UVLO
Threshold
Voltage
（Typ）
3.4V
2.7V
3.8V
2.5V
3.7V
BD9120HFN
Datasheet
Output
Current
（Max）
0.8A
1.2A
0.8A
0.8A
2.0A
Package
MSOP8
MSOP8
MSOP8
HSON8
SON00
8V5060
Reel of 3000
Reel of 3000
Reel of 3000
Reel of 3000
Reel of 2000
Available
Part Number
BD9106FVM-TR
BD9107FVM-TR
BD9109FVM-TR
BD9120HFN-TR
BD9110NV-E2
-25°C to +85°C
4.5V to 5.5V
2.7V to 4.5V
-25°C to +105°C
4.5V to 5.5V
Absolute Maximum Ratings
(Ta=25°C)
Parameter
VCC Voltage
PVCC Voltage
EN Voltage
SW , ITH Voltage
Power Dissipation 1
Power Dissipation 2
Operating Temperature Range
Storage Temperature Range
Maximum Junction Temperature
Symbol
V
CC
PV
CC
V
EN
V
SW
,V
ITH
Pd1
Pd2
Topr
Tstg
Tjmax
BD910xFVM
-0.3 to +7
(Note 1)
-0.3 to +7
(Note 1)
-0.3 to +7
-0.3 to +7
0.38
(Note 2)
0.58
(Note 3)
-25 to +85
-55 to +150
+150
Limit
BD9110NV
-0.3 to +7
(Note 1)
-0.3 to +7
(Note 1)
-0.3 to +7
-0.3 to +7
0.64
(Note 4)
5.29
(Note 5)
-25 to +105
-55 to +150
+150
BD9120HFN
-0.3 to +7
(Note 1)
-0.3 to +7
(Note 1)
-0.3 to +7
-0.3 to +7
0.63
(Note 6)
1.75
(Note 7)
-25 to +85
-55 to +150
+150
Unit
V
V
V
V
W
W
°C
°C
°C
(Note 1) Pd should not be exceeded.
(Note 2) IC only
(Note 3) 1-layer. mounted on a 70mm x 70mm x 1.6mm glass-epoxy board
(Note 4) IC only
(Note 5) 4-layer. mounted on a 74.2mm x 74.2mm x 1.6mm glass-epoxy board, area of copper foil in 1st layer : 5505mm
2
(Note 6) 1-layer. mounted on a 74.2mm x 74.2mm x 1.6mm glass-epoxy board, area of copper foil : 0.2%
(Note 7) 1-layer. mounted on a 74.2mm x 74.2mm x 1.6mm glass-epoxy board, area of copper foil : 65%
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
