SUM09N20-270-E3

Description
MOSFET 200V 9.0A 60W 270mohm @ 10V
CategoryDiscrete semiconductor    The transistor
File Size104KB,6 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

SUM09N20-270-E3 Online Shopping

Suppliers Part Number Price MOQ In stock
SUM09N20-270-E3 - - View Buy Now

SUM09N20-270-E3 Overview

MOSFET 200V 9.0A 60W 270mohm @ 10V

SUM09N20-270-E3 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
MakerVishay
Parts packaging codeD2PAK
package instructionSMALL OUTLINE, R-PSSO-G2
Contacts4
Reach Compliance Codeunknown
ECCN codeEAR99
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage200 V
Maximum drain current (Abs) (ID)9 A
Maximum drain current (ID)9 A
Maximum drain-source on-resistance0.3 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JEDEC-95 codeTO-263AB
JESD-30 codeR-PSSO-G2
JESD-609 codee3
Humidity sensitivity level1
Number of components1
Number of terminals2
Operating modeENHANCEMENT MODE
Maximum operating temperature175 °C
Minimum operating temperature-55 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeN-CHANNEL
Maximum power dissipation(Abs)60 W
Maximum pulsed drain current (IDM)10 A
Certification statusNot Qualified
surface mountYES
Terminal surfaceMatte Tin (Sn) - with Nickel (Ni) barrier
Terminal formGULL WING
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Transistor component materialsSILICON
SUM09N20-270
Vishay Siliconix
N-Channel 200 V (D-S) 175 °C MOSFET
FEATURES
PRODUCT SUMMARY
V
DS
(V)
200
R
DS(on)
(Ω)
0.270 at V
GS
= 10 V
0.300 at V
GS
= 6 V
I
D
(A)
9
8.5
• TrenchFET
®
Power MOSFETS
• 175 °C Junction Temperature
• Low Thermal Resistance Package
Compliant to RoHS Directive 2002/95/EC
D
TO-263
G
G
D S
S
N-Channel MOSFET
Top View
Ordering Information:
SUM09N20-270-E3 (Lead (Pb) free)
ABSOLUTE MAXIMUM RATINGS
(T
C
= 25 °C, unless otherwise noted)
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (T
J
= 175 °C)
Pulsed Drain Current
Avalanche Current
Repetitive Avalanche Energy
Maximum Power
a
Symbol
V
DS
V
GS
T
C
= 25 °C
T
C
= 125 °C
I
D
I
DM
I
AR
L = 0.1 mH
T
C
= 25 °C
T
A
= 25 °C
c
E
AR
P
D
T
J
, T
stg
Limit
200
± 20
9
5.2
10
7
2.45
60
b
3.75
- 55 to 175
Unit
V
A
mJ
W
°C
Dissipation
a
Operating Junction and Storage Temperature Range
THERMAL RESISTANCE RATINGS
Parameter
Junction-to-Ambient (PCB Mount)
c
Junction-to-Case (Drain)
Notes:
a. Duty cycle
1 %.
b. See SOA curve for voltage derating.
c. When mounted on 1" square PCB (FR-4 material).
Symbol
R
thJA
R
thJC
Limit
40
2.5
Unit
°C/W
Document Number: 72158
S11-2308-Rev. B, 21-Nov-11
www.vishay.com
1
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
