BA05FP-E2 Overview

CAN Interface IC W/ SPI Interface

BA05FP-E2 Parametric

Parameter Name	Attribute value
Product Category	LDO Voltage Regulators
Manufacturer	ROHM Semiconductor
RoHS	Details
Mounting Style	SMD/SMT
Package / Case	TO-252-3
Output Voltage	5 V
Output Current	1 A
Number of Outputs	1 Output
Polarity	Positive
Input Voltage MAX	25 V
Input Voltage MIN	+ 6 V
Output Type	Fixed
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Load Regulation	150 mV
Dropout Voltage	0.3 V at 500 mA
Packaging	Reel
Packaging	MouseReel
Packaging	Cut Tape
Dropout Voltage - Max	0.5 V at 500 mA
Line Regulation	100 mV
Pd - Power Dissipation	1 W
Factory Pack Quantity	2000
Unit Weight	0.139332 oz

Preview

Download Datasheet

View All

Standard ICs

Low saturation voltage type 3-pin

regulator

BAffT / FP series

The BAffT / FP series are fixed positive output low drop-out type, 3-pin voltage regulators with positive output. These

regulators are used to provide a stabilized output voltage from a fluctuating DC input voltage.

There are 10 fixed output voltages, as follows:3V, 3.3V, 5V, 6V*, 7V, 8V, 9V, 10V, 12V and 15V. The maximum current

capacity is 1A for each of the above voltages. (Items marked with an asterisk are under development.)

FApplications

Constant voltage power supply

FFeatures

1) Built-in overvoltage protection circuit, overcurrent

protection circuit and thermal shutdown circuit.

2) TO220FP and TO252-3 packages are available to

cover a wide range of applications.

FProduct

codes

3) Compatible with the BA178ff series.

4) Richly diverse lineup.

5) Low minimum I / O voltage differential.

FBlock

diagram

www.DataSheet4U.com
