BUT30V

Description
General Purpose Relays High-Capacity SPDT Vented 12VDC
CategoryDiscrete semiconductor    The transistor
File Size339KB,7 Pages
ManufacturerSTMicroelectronics
Websitehttp://www.st.com/
Download Datasheet Parametric View All

BUT30V Online Shopping

Suppliers Part Number Price MOQ In stock
BUT30V - - View Buy Now

BUT30V Overview

General Purpose Relays High-Capacity SPDT Vented 12VDC

BUT30V Parametric

Parameter NameAttribute value
Brand NameSTMicroelectronics
MakerSTMicroelectronics
package instructionISOTOP-3
Contacts3
Reach Compliance Codenot_compliant
ECCN codeEAR99
Factory Lead Time8 weeks
Shell connectionISOLATED
Maximum collector current (IC)100 A
Collector-emitter maximum voltage125 V
ConfigurationSINGLE
Maximum landing time (tf)200 ns
JESD-30 codeR-XUFM-X3
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialUNSPECIFIED
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeNPN
Maximum power consumption environment250 W
Maximum power dissipation(Abs)250 W
Certification statusNot Qualified
surface mountNO
Terminal surfaceNickel (Ni)
Terminal formUNSPECIFIED
Terminal locationUPPER
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Maximum off time (toff)2200 ns
VCEsat-Max0.9 V
®
BUT30V
NPN TRANSISTOR POWER MODULE
s
s
s
s
s
s
NPN TRANSISTOR
HIGH CURRENT POWER BIPOLAR MODULE
VERY LOW R
th
JUNCTION CASE
SPECIFIED ACCIDENTAL OVERLOAD
AREAS
FULLY INSULATED PACKAGE (U.L.
COMPLIANT) FOR EASY MOUNTING
LOW INTERNAL PARASITIC INDUCTANCE
Pin 4 not connected
APPLICATIONS:
s
MOTOR CONTROL
s
SMPS & UPS
s
WELDING EQUIPMENT
ISOTOP
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS
Symbol
V
CEV
V
CEO(sus)
V
EBO
I
C
I
CM
I
B
I
BM
P
tot
V
isol
T
stg
T
j
Parameter
Collector-Emitter Voltage (V
BE
= -5 V)
Collector-Emitter Voltage (I
B
= 0)
Emitter-Base Voltage (I
C
= 0)
Collector Current
Collector Peak Current (t
p
= 10 ms)
Base Current
Base Peak Current (t
p
= 10 ms)
Total Dissipation at T
c
= 25
o
C
Insulation Withstand Voltage (RMS) from All
Four Terminals to External Heatsink
Storage Temperature
Max. Operating Junction Temperature
Value
200
125
7
100
150
20
30
250
2500
-55 to 150
150
Unit
V
V
V
A
A
A
A
W
o
o
C
C
February 2003
1/7
