1N3518A

Description
Zener Diodes Voltage Regulator
CategoryDiscrete semiconductor    diode
File Size113KB,2 Pages
ManufacturerMicrosemi
Websitehttps://www.microsemi.com
Download Datasheet Parametric View All

1N3518A Online Shopping

Suppliers Part Number Price MOQ In stock
1N3518A - - View Buy Now

1N3518A Overview

Zener Diodes Voltage Regulator

1N3518A Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerMicrosemi
Parts packaging codeDO-35
package instructionO-LALF-W2
Contacts2
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeZENER DIODE
Maximum dynamic impedance7 Ω
JEDEC-95 codeDO-35
JESD-30 codeO-LALF-W2
JESD-609 codee0
Number of components1
Number of terminals2
Maximum operating temperature175 °C
Minimum operating temperature-65 °C
Package body materialGLASS
Package shapeROUND
Package formLONG FORM
Peak Reflow Temperature (Celsius)NOT SPECIFIED
polarityUNIDIRECTIONAL
Maximum power dissipation0.5 W
Certification statusNot Qualified
Nominal reference voltage1 V
surface mountNO
technologyZENER
Terminal surfaceTIN LEAD
Terminal formWIRE
Terminal locationAXIAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Maximum voltage tolerance5%
Working test current10 mA
Base Number Matches1
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01844
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
400mW
ZENER VOLTAGE REGULATOR DIODE
DEVICES
1N3506A through 1N3534A
MAXIMUM RATING AT 25
o
C
Junction and Storage Temperature: -65°C to +175°C
DC Power Dissipation: 500mW @ T
EC
= +125°C
Forward Voltage @ 200mA: 1.1 volts maximum
ELECTRICAL CHARACTERISTICS
(TA = 25°C, unless otherwise specified)
Zener Type
#
1N3506A
1N3507A
1N3508A
1N3509A
1N3510A
1N3511A
1N3512A
1N3513A
1N3514A
1N3515A
1N3516A
1N3517A
1N3518A
1N3519A
1N3520A
1N3521A
1N3522A
1N3523A
1N3524A
1N3525A
1N3526A
1N3527A
1N3528A
1N3529A
1N3530A
1N3531A
Zener Voltage @ Izt
Volts
@ mA
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
1.0
11.0
12.0
13.0
15.0
16.0
18.0
20.0
22.0
24.0
27.0
30.0
33.0
36.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
10.0
10.0
10.0
10.0
10.0
10.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
4.0
4.0
3.0
3.0
Zener Voltage
Tolerance
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
Max Zener Impedance
@ Izt Ohms
24.0
22.0
20.0
18.0
16.0
14.0
8.0
3.0
3.0
4.0
5.0
6.0
7.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
35.0
38.0
40.0
48.0
50.0
75.0
Power Rating
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
400mW
DO-35
LDS-0063 Rev. 2 (091964)
Page 1 of 2
