74LCX240 — Low Voltage Octal Buffer/Line Driver with 5V Tolerant Inputs and Outputs
January 2008
74LCX240
Low Voltage Octal Buffer/Line Driver with 5V Tolerant
Inputs and Outputs
Features
■
5V tolerant inputs and outputs
■
2.3V–3.6V V
CC
specifications provided
■
6.5ns t
PD
max. (V
CC
=
3.3V), 10µA I
CC
max.
■
Power-down high impedance inputs and outputs
■
Supports live insertion/withdrawal
(1)
■
±24mA output drive (V
CC
=
3.0V)
■
Implements p
roprietary
noise/EMI reduction circuitry
■
Latch-up performance exceeds 500mA
■
ESD performance:
General Description
The LCX240 is an inverting octal buffer and line driver
designed to be employed as a memory address driver,
clock driver and bus oriented transmitter or receiver. The
device is designed for low voltage (2.5V or 3.3V) V
CC
applications with capability of interfacing to a 5V signal
environment.
The LCX240 is fabricated with an advanced CMOS tech-
nology to achieve high speed operation while maintain-
ing CMOS low power dissipation.
– Human body model
>
2000V
– Machine model
>
200V
Note:
1. To ensure the high-impedance state during power up
or down, OE should be tied to V
CC
through a pull-up
resistor: the minimum value or the resistor is
determined by the current-sourcing capability of the
driver.
Ordering Information
Order
Number
74LCX240WM
74LCX240SJ
74LCX240MSA
74LCX240MTC
Package
Number
M20B
M20D
MSA20
MTC20
Package Description
20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
20-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
20-Lead Shrink Small Outline Package (SSOP), JEDEC MO-150, 5.3mm Wide
20-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 4.4mm
Wide
Device also available in Tape and Reel. Specify by appending suffix letter “X” to the ordering number.
All packages are lead free per JEDEC: J-STD-020B standard.
