M SERIES OUTPUT MODULES
•
AC Modules have High Current Thyristors with 100 Amp
Surge Capability
•
Plug into mounting boards for 0.6" modules
•
Zero or Random Turn-On Available in AC Modules
•
4kV Optical isolation (1500 VAC Isolation for
FET DC Output Modules)
•
UL Recognized, CSA Certified, CE Compliant
•
Industry standard packaging and Color Coding
Black (AC Output) Red (DC Output)
I/O Modules
SPECIFICATIONS
Input
Nominal Voltage [VDC]
Minimum Voltage [VDC]
(2)
Maximum Voltage [VDC]
Drop-out Voltage [VDC]
Maximum Current [mA]
(3)
Resistance [Ohms]
(4)
(1)
Part Number
M-OAC5
5.0
2.75
8.0
1.0
20
220
M-OAC5A
5.0
2.75
8.0
1.0
20
220
M-OAC5AH
5.0
2.75
8.0
1.0
20
220
M-OAC5AR
5.0
2.75
8.0
1.0
20
220
M-OAC5R
5.0
2.75
8.0
1.0
20
220
Output
Nominal Line Voltage
Minimum Line Voltage
Maximum Line Voltage
Max Off-State Voltage
(5)
Max Off-State Leakage
(6)
Static Off-State dv/dt
(7)
Maximum Rated On-State Current
(8)
Minimum On-State Current
Max Surge Current
(9)
On-State Voltage Drop or Resistance
(10)
Maximum Turn-On Time [msec]
(13)
Maximum Turn-Off Time [msec]
(13)
Input/Output Isolation Voltage
(14)
Input/Output Capacitance
Operating Temperature Range
Storage Temperature Range
Line Frequency Range
Weight
120 VAC
12 VAC
140 VAC
400 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
47 to 63 Hz
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
47 to 63 Hz
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
5.0 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
47 to 63 Hz
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
0.1
8.33
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
47 to 63 Hz
1.1 oz. (31.2g)
120 VAC
12 VAC
140 VAC
400 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
0.1
8.33
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
47 to 63 Hz
1.1 oz. (31.2g)
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
Datasheet
Input
I/O Modules
SPECIFICATIONS
(1)
Nominal Voltage [VDC]
Minimum Voltage [VDC]
(2)
Maximum Voltage [VDC]
Drop-out Voltage [VDC]
Maximum Current [mA]
(3)
Resistance [Ohms]
(4)
Part Number
M-OAC24
24
18
32
1.0
13
2000
M-OAC24A
24
18
32
1.0
13
2000
M-ODC5
5.0
2.75
8.0
1.0
18
250
M-ODC5A
5.0
2.75
8.0
1.0
18
250
M-ODC5F
5.0
2.75
8.0
1.0
18
250
Output
Nominal Line Voltage
Minimum Line Voltage
Maximum Line Voltage
Max Off-State Voltage
(5)
Max Off-State Leakage
(6)
Static Off-State dv/dt
(7)
Maximum Rated On-State Current
(8)
Minimum On-State Current
Max Surge Current
(9)
On-State Voltage Drop or Resistance
(10)
Maximum Turn-On Time [msec]
(13)
Maximum Turn-Off Time [msec]
(13)
Input/Output Isolation Voltage
(14)
Input/Output Capacitance
Operating Temperature Range
Storage Temperature Range
Line Frequency Range
Weight
120 VAC
12 VAC
140 VAC
400 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
47 to 63 Hz
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
47 to 63 Hz
1.1 oz. (31.2g)
5-48 VDC
3.0 VDC
60 VDC
60 VDC
10 uA
N/A
3.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-150 VDC
3.0 VDC
250 VDC
250 VDC
10 uA
N/A
1.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-48 VDC
3.0 VDC
60 VDC
60 VDC
10 uA
N/A
3.0 A
10 mA
5.0 A
1.5 V
0.025
0.05
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
Input
SPECIFICATIONS
(1)
Nominal Voltage [VDC]
Minimum Voltage [VDC]
(2)
Maximum Voltage [VDC]
Drop-out Voltage [VDC]
Maximum Current [mA]
(3)
Resistance [Ohms]
(4)
Part Number
M-ODC5MA
5.0
2.75
8.0
1.0
18
250
M-ODC5MC
5.0
2.75
8.0
1.0
18
250
M-ODC5ML
5.0
2.75
8.0
1.0
18
250
M-ODC24
24
18
32
1.0
13
2000
M-ODC24A
24
18
32
1.0
13
2000
Output
Nominal Line Voltage
Minimum Line Voltage
Maximum Line Voltage
Max Off-State Voltage
(5)
Max Off-State Leakage
(6)
Static Off-State dv/dt
(7)
Maximum Rated On-State Current
(8)
Minimum On-State Current
Max Surge Current
(9)
On-State Voltage Drop or Resistance
(10)
Maximum Turn-On Time [msec]
(13)
Maximum Turn-Off Time [msec]
(13)
Input/Output Isolation Voltage
(14)
Input/Output Capacitance
Operating Temperature Range
Storage Temperature Range
Line Frequency Range
Weight
5-150 VDC
1.0 VDC
200 VDC
200 VDC
10 uA
N/A
3.0 A
1.0 mA
10 A
0.25 Ohms
1.0
0.05
1500 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-90 VDC
1.0 VDC
100 VDC
100 VDC
10 uA
N/A
5.0 A
1.0 mA
10 A
0.10 Ohms
1.0
0.05
1500 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-48 VDC
50 VDC
50 VDC
50 VDC
10 uA
N/A
1.0 A
10 mA
10 A
0.05 Ohms
1.0
0.05
1500 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-48 VDC
60 VDC
60 VDC
60 VDC
10 uA
N/A
3.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-150 VDC
250 VDC
250 VDC
250 VDC
10 uA
N/A
1.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000 Vrms
8 pF
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
Datasheet
General Notes:
(1)
Specifications apply to an ambient temperature of -30 to 80°C unless otherwise noted.
(2)
Whitout external LED status indicator Add 1.7 volts for external LED if utilized.
(3)
At nominal input voltage, without external LED status indicator.
(4)
+ / - 10% at 25°C.
(5)
Maximum 1 minute duration for OAC modules when applied as a DC voltage rather than a peek AC voltage.
(6)
At maximum line voltage, 25°C for OAC modules, and 80°C for ODC modules.
(7)
Minimum DV/DT per EIA/NARM RS433, method RS397, DV/DT raitings do not apply to DC output models.
(8)
At 40°C derate OAC modules 58 mA/°C to 80°C derate ODC, ODCxMC and ODCxML modules 50mA/°C
(9)
At 25°C for 1 second maximum duration: 1 AC cycle for AC modules, 1 second for DC modules.
(10)
At maximum rated on-state current and 25°C.
(11)
At maximum line voltage, maximum rated output current, nominal input voltage and 25°C switching speed
(12)
At 25°C for 1 second maximum duration.
(13)
1/3 HP at 240 VAC 1/8 HP at 120 VAC.
(14)
At 25°C for 1 second maximum duration.
of OAC modules is based upon 60 Hz line frequency
to 80°C CSA rating of OAC modules is 3.0 Arms at 40°C.
I/O Modules
EQUIVALENT CIRCUIT DIAGRAMS / MECHANICAL SPECIFICATIONS
CASE COLORS:
AC-BLACK
DC-RED
4
3
2
1
0.035 (.89)
0.24 (6.1)
0.042 (1.1) DIA
1.7 (43.2)
0.15 (3.81)
0.4 (10.2)
UNLESS OTHERWISE SPECIFIED
DIMENSIONS: INCHES (MILLIMETERS)
TOLERANCE:
±
0.020 (
±
0.50)
AGENCY APPROVALS
E46203
38595
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
1.0 (25.4)
0.3 (7.6)
0.7 (17.8)
1.2 (30.5)
1.4 (35.6)
Rev. 042017
