Radial Leads/SkyCap
®
/SR Series
GENERAL INFORMATION
AVX SR Series
Conformally Coated Radial Leaded MLC
Temperature Coefficients:
C0G (NP0), X7R, Z5U
200, 100, 50 Volts (300V, 400V & 500V also available)
Case Material:
Epoxy
Lead Material:
RoHS Compliant, 100% Tin
LD
Nom.
L.S.
Styles SR15, SR20,
SR30, SR40, SR50
H Max.
LD
Nom.
W
Max.
Styles SR22, SR27
L.S.
1.0" Min.
H Max.
Dimensions: Millimeters (Inches)
W
Max.
H Max.
W
Max.
T
Max.
1.52 (0.060)
Max.
1.0" Min.
LD
Nom.
T
Max.
See Note
T
Max.
See Note
1.0" Min.
L.S.
Note: Coating clean .784 (0.031) min.
above seating plane
Style SR21
HOW TO ORDER
SR21
AVX Style
SR15
SR20
SR21
SR22
SR27
SR30
SR40
SR50
Drawings are for illustrative purposes only.
Actual lead form shape could vary within stated tolerances based on body size.
5
Voltage
5 = 50V
1 = 100V
2 = 200V
9 = 300V
8 = 400V
7 = 500V
E
Temperature
Coefficient
A = C0G (NP0)
C = X7R
E = Z5U
104
Capacitance
M
Capacitance
A
Failure Rate
A = Not Applicable
R
Leads
R = RoHS
Long Lead
1.0" minimum
TR1
Packaging
Blank = Bulk Packaging
T = Trimmed Leads
.230"± .030"
Bulk packaging
TR1 = Tape and Reel
Packaging
AP1 = Ammopack
Packaging
See packaging specification
page 33-34.
First two digits are the
Tolerance
significant figures of
C0G (NP0):
X7R:
capacitance. Third digit
C = ±.25pF
J = ±5%
indicates the additional
D = ±.5pF
K = ±10%
number of zeros. For
F = ±1%
M = ±20%
example, order 100,000
(>50pF only)
pF as 104. (For values
G = ±2%
Z5U:
below 10pF use “R” in
(>25pF only) M = ±20%
place of decimal point,
J = ±5%
Z = +80%
e.g., 1R4 = 1.4pF.)
K = ±10%
-20%
MARKING
FRONT
XXX
X X X
Capacitance Code
Tolerance Code
Voltage Code
Temp. Char. Code
PACKAGING REQUIREMENTS
BACK
XXX
A XX
3 Digit Date Code
Lot Code
AVX Logo
SR15, 20, 21, 22, 27, 30
SR40, 50
Quantity per Bag
1000 Pieces
500 Pieces
Note: SR15, SR20, SR21, SR30, and SR40 available on tape and reel per EIA
specifications RS-468. See Pages 33 and 34.
14
Radial Leads/SkyCap
®
/SR Series
C0G (NP0) Dielectric
SIZE AND CAPACITANCE SPECIFICATIONS
EIA Characteristic
Dimensions: Millimeters (Inches)
AVX Style
AVX “Insertable”
Width
(W)
Height
(H)
Thickness
(T)
Lead Spacing
(L.S.)
Lead Diameter
(L.D.)
SR15
SR07
3.81
(.150)
3.81
(.150)
2.54
(.100)
2.54
(.100)
.508
(.020)
SR20
SR29
5.08
(.200)
5.08
(.200)
3.175
(.125)
2.54
(.100)
.508
(.020)
SR21
SR59
5.08
(.200)
5.08
(.200)
3.175
(.125)
5.08
(.200)
.508
(.020)
SR22
N/A
5.08
(.200)
5.08
(.200)
3.175
(.125)
6.35
(.250)
.508
(.020)
SR27
N/A
6.604
(.260)
6.35
(.250)
4.06
(.160)
7.62
(.300)
.508
(.020)
SR30
SR65
7.62
(.300)
7.62
(.300)
3.81
(.150)
5.08
(.200)
.508
(.020)
WVDC
100
50
SR40
SR75
10.16
(.400)
10.16
(.400)
3.81
(.150)
5.08
(.200)
.508
(.020)
WVDC
100 50
SR50
N/A
12.70
(.500)
12.70
(.500)
5.08
(.200)
10.16
(.400)
.635
(.025)
WVDC
100 50
Cap. in.* Industry Preferred
WVDC
WVDC
WVDC
pF
Values in Blue 200 100 50 200 100 50 200 100 50
1.0-9.9 SR151A1R0DAR
10 SR151A100KAR
15 SR-----A150KAR
22 SR-----A220KAR
33 SR-----A330KAR
39 SR-----A390KAR
47 SR-----A470KAR
68 SR-----A680KAR
100 SR151A101KAR
150 SR-----A151KAR
220 SR-----A221KAR
330 SR-----A331KAR
390 SR-----A391KAR
470 SR-----A471KAR
680 SR-----A681KAR
1000 SR211A102KAR
1500 SR-----A152KAR
2200 SR-----A222KAR
3900 SR-----A392KAR
4700 SR-----A472KAR
6800 SR-----A682KAR
8200 SR-----A822KAR
10,000 SR305A103KAR
15,000 SR-----A153KAR
22,000
33,000
39,000
47,000
68,000
100,000
SR-----A223KAR
SR-----A333KAR
SR-----A393KAR
SR-----A473KAR
SR-----A683KAR
SR-----A104KAR
WVDC
WVDC
200 100 50 200 100 50
For other styles, voltages, tolerances and lead lengths see Part No. Codes or contact factory.
*Other capacitance values available upon special request.
= Industry preferred values
= SR20 only
Capacitance ranges available for SR12
SR62
SR64
SR75
SR13
and SR07 same as SR15
and SR59 same as SR21
and SR65 same as SR30
same as SR40
same as SR21
NOTE:
For others voltages, tolerances, electrical specifications and NPO typical characteristics,
see the AVX Multilayer Ceramic Leaded Capacitors Catalog.
15
Radial Leads/SkyCap
®
/SR Series
X7R Dielectric
SIZE AND CAPACITANCE SPECIFICATIONS
EIA Characteristic
Dimensions: Millimeters (Inches)
AVX Style
AVX “Insertable”
Width
(W)
Height
(H)
Thickness
(T)
Lead Spacing
(L.S.)
Lead Diameter
(L.D.)
SR15
SR07
3.81
(.150)
3.81
(.150)
2.54
(.100)
2.54
(.100)
.508
(.020)
SR20
SR29
5.08
(.200)
5.08
(.200)
3.175
(.125)
2.54
(.100)
.508
(.020)
WVDC
200 100 50
SR21
SR59
5.08
(.200)
5.08
(.200)
3.175
(.125)
5.08
(.200)
.508
(.020)
SR22
N/A
5.08
(.200)
5.08
(.200)
3.175
(.125)
6.35
(.250)
.508
(.020)
SR27
N/A
6.604
(.260)
6.35
(.250)
4.06
(.160)
7.62
(.300)
.508
(.020)
SR30
SR65
7.62
(.300)
7.62
(.300)
3.81
(.150)
5.08
(.200)
.508
(.020)
SR40
SR75
10.16
(.400)
10.16
(.400)
3.81
(.150)
5.08
(.200)
.508
(.020)
SR50
N/A
12.70
(.500)
12.70
(.500)
5.08
(.200)
10.16
(.400)
.635
(.025)
Cap. in.* Industry Preferred
WVDC
pF
Values in Blue 200 100 50
470
1000
1500
2200
3300
4700
6800
10,000
15,000
22,000
33,000
47,000
68,000
100,000
150,000
220,000
330,000
390,000
470,000
1.0 uF
2.2 uF
2.7 uF
4.7 uF
10.0 uF
SR-----C471KAR
SR155C102KAR
SR-----C152KAR
SR-----C222KAR
SR-----C332KAR
SR-----C472KAR
SR-----C682KAR
SR215C103KAR
SR-----C153KAR
SR-----C223KAR
SR-----C333KAR
SR-----C473KAR
SR-----C683KAR
SR215C104KAR
SR-----C154KAR
SR215C224KAR
SR-----C334KAR
SR-----C394KAR
SR305C474KAR
SR305C105KAR
SR405C225KAR
SR505C275KAR
SR505C475KAR
SR655C106KAR
WVDC
WVDC
WVDC
WVDC
200 100 50 100 50 100 50 200 100 50
WVDC
WVDC
200 100 50 200 100 50
For other styles, voltages, tolerances and lead lengths see Part No. Codes or contact factory.
= Industry preferred values
= Extended range
= Extended range with 0.150" thickness maximum
16
Radial Leads/SkyCap
®
/SR Series
Z5U Dielectric
SIZE AND CAPACITANCE SPECIFICATIONS
EIA Characteristic
Dimensions: Millimeters (Inches)
AVX Style
AVX “Insertable”
Width
(W)
Height
(H)
Thickness
(T)
Lead Spacing
(L.S.)
Lead Diameter
(L.D.)
Cap. in.* Industry Preferred
pF
Values in Blue
10,000 SR155E103ZAR
47,000 SR-----E473ZAR
100,000 SR215E104ZAR
150,000 SR-----E154ZAR
220,000 SR215E224ZAR
330,000 SR215E334ZAR
470,000 SR215E474ZAR
680,000 SR-----E684ZAR
1.0 μF SR
-----
105ZAR
1.5 μF SR30E155ZAR
2.2 μF SR30E225ZAR
3.3 μF SR30E335ZAR
4.7 μF SR30E475ZAR
SR15
SR07
3.81
(.150)
3.81
(.150)
2.54
(.100)
2.54
(.100)
.508
(.020)
WVDC
100
50
SR20
SR29
5.08
(.200)
5.08
(.200)
3.175
(.125)
2.54
(.100)
.508
(.020)
WVDC
100
50
SR21
SR59
5.08
(.200)
5.08
(.200)
3.175
(.125)
5.08
(.200)
.508
(.020)
WVDC
100
50
SR22
N/A
5.08
(.200)
5.08
(.200)
3.175
(.125)
6.35
(.250)
.508
(.020)
WVDC
100
50
SR27
N/A
6.604
(.260)
6.35
(.250)
4.06
(.160)
7.62
(.300)
.508
(.020)
WVDC
100
50
SR30
SR65
7.62
(.300)
7.62
(.300)
3.81
(.150)
5.08
(.200)
.508
(.020)
WVDC
100 50
SR40
SR75
10.16
(.400)
10.16
(.400)
3.81
(.150)
5.08
(.200)
.508
(.020)
WVDC
100 50
SR50
N/A
12.70
(.500)
12.70
(.500)
5.08
(.200)
10.16
(.400)
.635
(.025)
WVDC
100
50
For other styles, voltages, tolerances and lead lengths see Part No. Codes or contact factory.
*Other capacitance values available upon special request.
= Industry preferred values
= SR20 only
Capacitance ranges available for SR12
SR62
SR64
SR75
SR13
and SR07 same as SR15
and SR59 same as SR21
and SR65 same as SR30
same as SR40
same as SR21
AVX 500 VOLT SKYCAPS**
STYLE*
SR29
SR20
SR28
SR59
SR13
SR21
SR30
SR61
SR65
SR40
SR75
SR22
SR27
SR76
SR50
MAXIMUM CAPACITANCE VALUE
C0G (NP0)
X7R
900 pF
.015 μF
1800 pF
.033 μF
900 pF
1800 pF
7200 pF
.015 μF
1800 pF
1800 pF
.015 μF
.036 μF
.015 μF
.033 μF
.12 μF
.27 μF
.033 μF
.033 μF
.27 μF
.59 μF
NOTE:
For others voltages, tolerances, electrical specifications and
NPO typical characteristics, see the AVX Multilayer Ceramic
Leaded Capacitors Catalog.
*Consult pages 27 and 28 for style sizes.
**Voltage rating based on DWV of 150% of rated voltage.
