RB33X06Y08Y
2.76
70
1.38
35.1
.32
8.2
TYP
2.28
58
1.71
43.5
2
R.06
1.5
2.76
70
.16
3.9
4X
3.15
80.1
.5°
TYP
.79
20.1
2.68
68.1
2.28
58
.06
1.5
.67
17
A
A
1.45
36.9
1
2.90
73.7
1
1.97
50
END VIEW
.31
8
R.26 1
6.5
4X
R.11 1
2.9
8X
2.24
56.9
2.98
75.7
1
TOP VIEW
BOTTOM VIEW
1
.12 WALL
3
TYP
PN-RB33-X06Y
PN-8033 O-Ring
.20
5
TYP
PN-6023
PN-6102
1.14
29.1
1
1.38
35.1
3.23
82
PN-6022
PN-RB33X08Y
RB33X06G28G 2
(Part shown, no material (X) specified)
1
2
=INTERIOR DIMENSIONS (@ BOTTOM)
SIDE VIEW
SECTION A-A
SCALE 1 : 1.5
ALL DIMENSIONS ARE ± .010"
7/31/2015
2009 Wright Ave., La Verne,Ca. 91750
Ph. (626) 331-0517 Fx. (626) 331-8584 serpac.com
PN
RB33-X06Y
RB33X08Y
8033
6023
6022
6102
Description
(1) RB33-X06Y, Top
(1) RB33X08Y, Bottom
(1) RB33 O-Ring
(4) #4-40 Torx 10 Hd Screw
(4) #10 High/Low Pan Hd x 1/4"
(4) #4-40 Threaded Insert
=STANDARD COLORS (Y) ARE: BLACK (B), CLEAR (C) AND GRAY (G)
TOPS AND BOTTOMS ALL POSIBLE COMBINATIONS AVAILABLE
STANDARD MATERIALS (X) ARE: POLYCARBONATE (P) AND ABS (A)
DIMENSIONS in Inch
[mm]
-Watertight enclosure meets or
exceed Nema 4 and or IP67.
