Shielded Power Inductors – LPS5030
• Very low DCR; excellent current handling
• 4.9 × 4.9 mm footprint; less than 3 mm tall
Designer’s Kit C420
contains 3 each of all values
Core material
Ferrite
Environmental
RoHS compliant, halogen free
Terminations
RoHS compliant matte tin over nickel over silver.
Other terminations available at additional cost.
Weight
226 – 244 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
750/7″ reel; 2500/13″ reel Plastic tape: 12 mm wide,
0.32 mm thick, 8 mm pocket spacing, 3.1 mm pocket depth
Recommended pick and place nozzle
OD: 5 mm; ID:
≤
2.5 mm
PCB washing
Tested with pure water or alcohol only. For other solvents,
see
Doc787_PCB_Washing.pdf.
Part number
1
Isat
(A)
DCR SRF
2
max
3
4
Inductance
typ
10% 20% 30%
±20% (µH) (Ohms) (MHz) drop drop drop
5
Irms
(A)
6
20°C 40°C
rise rise
2.10
2.00
1.90
1.60
1.40
1.30
1.25
1.20
1.10
1.00
0.95
0.92
0.90
0.88
0.85
0.75
0.65
0.60
0.55
0.45
0.42
0.36
0.32
0.28
0.23
0.20
0.18
0.15
0.13
0.10
0.090
0.080
2.80
2.65
2.50
2.15
1.80
1.75
1.65
1.60
1.55
1.50
1.40
1.40
1.30
1.25
1.20
1.00
0.900
0.830
0.750
0.660
0.570
0.500
0.420
0.370
0.320
0.290
0.250
0.210
0.170
0.150
0.125
0.110
1. Please specify
termination
and
packaging
codes:
LPS5030-105MRC
Termination: R
= RoHS compliant matte tin over
nickel over silver.
Special order, added cost:
Q
= RoHS tin-silver-copper (95.5/4/0.5)
or
P
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481
embossed plastic tape (750 parts
per full reel).
B
= Less than full reel. In tape, but not
machine ready.
To have a leader and trailer added
($25 charge), use code letter C
instead.
D
= 13″ machine-ready reel. EIA-481
embossed plastic tape. Factory
order only, not stocked (2500 parts
per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc using an
Agilent/HP 4192A impedance analyzer or equivalent.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 8753ES or equivalent.
5. DC current at which the inductance drops the specified
amount from its value without current.
6. Current that causes the specified temperature rise from
25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
LPS5030-901MR_
LPS5030-122MR_
LPS5030-172MR_
LPS5030-222MR_
LPS5030-332MR_
LPS5030-472MR_
LPS5030-562MR_
LPS5030-682MR_
LPS5030-822MR_
LPS5030-103MR_
LPS5030-123MR_
LPS5030-153MR_
LPS5030-183MR_
LPS5030-223MR_
LPS5030-333MR_
LPS5030-473MR_
LPS5030-683MR_
LPS5030-823MR_
LPS5030-104MR_
LPS5030-124MR_
LPS5030-154MR_
LPS5030-224MR_
LPS5030-334MR_
LPS5030-474MR_
LPS5030-564MR_
LPS5030-684MR_
LPS5030-105MR_
LPS5030-155MR_
LPS5030-185MR_
LPS5030-225MR_
LPS5030-335MR_
LPS5030-475MR_
0.90
1.2
1.7
2.2
3.3
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
33.0
47.0
68.0
82.0
100
120
150
220
330
470
560
680
1000
1500
1800
2200
3300
4700
0.040
0.043
0.051
0.057
0.066
0.083
0.089
0.099
0.125
0.127
0.155
0.160
0.170
0.190
0.260
0.330
0.440
0.470
0.600
0.800
0.860
1.35
1.80
2.80
3.20
3.80
5.10
7.60
10.0
11.0
19.5
26.0
250
210
190
168
125
84
70
56
45
30
24
32
27
24
19
16
12
11
10
9
7.5
6.0
5.0
4.0
3.6
3.0
2.5
2.0
1.8
1.6
1.3
1.1
3.8
3.5
3.0
2.9
2.3
1.9
1.8
1.6
1.6
1.4
1.3
0.80
0.80
0.70
0.60
0.50
0.40
0.38
0.27
0.26
0.22
0.21
0.155
0.117
0.110
0.100
0.100
0.068
0.069
0.063
0.056
0.049
4.0
3.6
3.2
3.1
2.5
2.0
1.8
1.7
1.7
1.4
1.4
0.90
0.82
0.75
0.63
0.53
0.43
0.40
0.31
0.29
0.25
0.235
0.155
0.134
0.130
0.120
0.110
0.080
0.081
0.074
0.063
0.056
4.1
3.7
3.3
3.2
2.6
2.0
1.9
1.7
1.7
1.4
1.4
0.90
0.87
0.78
0.64
0.55
0.44
0.40
0.32
0.30
0.263
0.245
0.200
0.146
0.140
0.126
0.110
0.089
0.086
0.080
0.067
0.059
