Product Guide
H__1105W Series, Dome Lens Type SMT LED
s
Features
• Dome lens provides intensified narrow, bright beam
• Available for both standard and reverse mounting
• Wider operating temperature: -40° ~ +100°C
•
(HBG: -40° ~ +85°C)
s
Applications
• High-beam indicator for automotive use
• Backlighting for automotive dashboards
• Indoor / outdoor full-color signboards
s
Outline Dimensions
s
Recommended Solder Pad
on a Surface Mount
1.55
0.6
1.6
0.3
Anode
s
Recommended Solder Pad
on a reverse mount
(1.6)
1.6
1.5
HOLE
Polarity Mark
Cathode
PCB
0.5
0.5
R0.8
Cathode Mark
0.6
2.3+0.05
Unit: mm
Tolerance + 0.1
s
Electro-Optical Characteristics
Part No.
Material Emitted Lens
Color Color
GaAlAs
GaAlAs
GaAsP
GaAsP
GaP
GaP
GaP
Red
Red
Orange
Yellow
Yellow-Green
Green
Pure Green
(Ta=25°C)
Wavelength
Peak
λ
p
TYP.
Spectral Line
Dominant Half Width
∆λ
λ
d
TYP.
TYP.
I
F
Luminous
Intensity
IV
MIN.
TYP.
I
F
Forward
Voltage
V
TYP.
MAX.
F
Reverse Viewing
Current
IR
Angle
I
F
MAX.
V
R
(2
θ
1/2)
HKR1105W
HBR1105W
HAA1105W
HAY1105W
HPY1105W
HPG1105W
HBG1105W
70 150 20
25
10
Water 10
Clear 20
15
6
50
20
20
50
30
12
mcd
20
20
20
20
20
20
mA
660
660
605
580
570
560
555
647
647
606
590
572
567
558
nm
25
30
30
30
30
30
30
20
20
20
20
20
20
20
mA
1.8
1.7
2.2
2.2
2.1
2.1
2.1
V
2.5
2.0
2.5
2.5
2.5
2.5
2.5
20
20
20
20
20
20
20
mA
100
100
100
100
100
100
100
µA
4
4
4
4
4
4
4
V
30°
50°
40°
Units
Deg.
1.5
2.1 + 0.05
(4.6)
3.2
1.6
(2)
s
Absolute Maximum Ratings
Item
Power Dissipation
Forward Current
Peak Forward Current
Reverse Voltage
Operating Temperature
Storage Temperature
Derating*
Red
Orange
Yellow
Yellow-Green
Green
Pure Green
(Ta=25°C)
HAA
75
30
70
4
HAY
75
30
70
4
-40 to +100
-40 to +120
1.0 (DC) 2.33 (Pulse)
HPY
75
30
70
4
HPG
75
30
70
4
HBG
75
30
70
4
-40 to +85
-40 to +100
0.42 (DC) 0.93 (Pulse)
Symbol
HBR, HKR
Pd
60
(HBR)
,75
(HKR)
I
F
I
FM
V
R
Topr
Tstg
∆I
F
30
70
4
Units
mW
mA
mA
V
°C
°C
mA/°C
* Ta=25°C,
I
FM
applies for the pulse width
≤
1msec. and duty cycle
≤1/20.
The current derating for operation applies when the temperature is above 25°C for HBG and 75°C for HVR, HBR, HKR, HAA, HAY, HPY & HPG
s
Taping Specifications
1.75 + 0.1
4+0.1
φ
1.5
+0.1
0
(1.8)
(0.25)
for Reverse
Mount Type
s
Taping Specifications
φ
1.5
+0.1
0
(1.85)
1.75+0.1
4+0.1
(0.25)
Center
Hole
for Standard
Mount Type
(
φ
1.1)
2+0.05
4+0.1
3.5+0.05
(0.5)
(2.2)
(
φ
1.1)
2+ 0.05
4+0.1
3.5 +0.05
(3.45)
(3.5)
Quantity on tape:
2000 pieces
per reel
8+0.2
Quantity on tape:
2000 pieces
per reel
(2.1)
2+0.5
φ
21+0.8
Center
Hole
Cathode
Center
Hole
8+0.2
φ
13+0.2
+1
φ
60 -0
φ
13+0.2
Direction to pull
RR
Cathode
9+0.3
11.4+1
+0
φ
180 3
s
Operation Current Derating Chart (DC)
Direction to pull
TR
HAA, HAY, HPG,
HPY, HBR, HKR
HBG
s
Precautions
Please follow these handling precautions to prevent damage to the chip and
ensure its reliability.
1. Soldering conditions:
• Soldering iron: Temperature at tip of iron: 280°C max. (30W max.)
Soldering time: 3 sec. max.
• Dip soldering: Preheating: 120 ~ 150°C max. (resin surface temp.)
60 ~ 120 sec. max. Bath temperature: 260°C max. Dipping Time: 5 sec. max.
• Reflow Soldering:
LED Surface Temperature
°C
Operation Heating
240
Temperature
rise: 5°C/sec.
Cooling:
—5°C/sec.
s
Spatial Distribution
(X & Y)
(X & Y)
150
120
Pre-heating
2. Cleaning:
• If cleaning is required, use the following solutions for less than 1 minute,
at less than 40°C.
• Appropriate chemicals: Ethyl alcohol and isopropyl alcohol.
• Effect of ultrasonic cleaning on the LED resin body differs depending on such
factors as the oscillator output, size of PCB and LED mounting method. The
use of ultrasonic cleaning should be enforced at proper output after confirming
there is no problem.
HKR, HAA, HAY, HPY, HPG, HBG
HBR
Product specifications subject to change without notice. PGH__1105W-0301
~
0
60 to 120 sec.
5 sec. max
Stanley Electric Sales of America, Inc.
2660 Barranca Parkway, Irvine, CA 92606 • Tel: 800-LED-LCD1 (533-5231) • Fax: 949-222-0555
Website: www.stanley-electric.com
