3.3V 1 Megabit (128K x 8-Bit)
EEPROM
V
CC
V
SS
RES
OE
CE
WE
RES
A0
A6
Address
Buffer and
Latch
Y Decoder
Y Gating
I/O Buffer and
Input Latch
Control Logic Timing
High Voltage
Generator
I/O0
I/O7
RDY/Busy
28LV010
A7
A16
X Decoder
Memory Array
Data Latch
Logic Diagram
Memory
F
EATURES
:
• 3.3V low voltage operation 128K x 8 Bit EEPROM
• R
AD
-P
AK
® radiation-hardened against natural space
radiation
• Total dose hardness:
- > 100 krad (Si), depending upon space mission
• Excellent Single Event Effects:
- SEL
TH
> 84 MeV/mg/cm
2
- SEU
TH
> 37 Mev/mg/cm
2
(read mode)
-SEU saturated cross section = 3E-6 cm
2
(read mode)
- SEU
TH
= 11.4 Mev/mg/cm
2
(write mode)
-SEU saturated cross section = 5E-3 cm
2
(write mode) with
hard errors
• Package:
- 32 Pin R
AD
-P
AK
® flat pack
- 32 Pin R
AD
-P
AK
® DIP
- JEDEC-approved byte-wide pinout
• Address Access Time:
- 200, 250 ns maximum access times available
• High endurance:
- 10,000 erase/write (in Page Mode), 10-year data
retention
• Page write mode:
- 1 to 128 bytes
• Automatic programming
- 10 ms automatic page/byte write
• Low power dissipation
- 20 mW/MHz active current (typ.)
- 72 µW standby (maximum)
D
ESCRIPTION
:
Maxwell Technologies’ 28LV010 high density, 3.3V, 1 Megabit
EEPROM microcircuit features a greater than 100 krad (Si)
total dose tolerance, depending upon space mission. The
28LV010 is capable of in-system electrical Byte and Page pro-
grammability. It has a 128-Byte Page Programming function to
make its erase and write operations faster. It also features
Data Polling and a Ready/Busy signal to indicate the comple-
tion of erase and programming operations. In the 28LV010,
hardware data protection is provided with the RES pin, in addi-
tion to noise protection on the WE signal and write inhibit on
power on and off. Meanwhile, software data protection is
implemented using the JEDEC-optional Standard algorithm.
The 28LV010 is designed for high reliability in the most
demanding space applications.
Maxwell Technologies' patented R
AD
-P
AK
® packaging technol-
ogy incorporates radiation shielding in the microcircuit pack-
age. It eliminates the need for box shielding while providing
the required radiation shielding for a lifetime in orbit or space
mission. In a GEO orbit, R
AD
-P
AK
provides greater than 100
krad (Si) radiation dose tolerance. This product is available
with screening up to Class S.
Note:The recommended form of data protection during power
on/off is to hold the RES pin to V
SS
during power up and power
down. This may be accompanied by connecting the RES pin
to the CPU reset line. Failure to provide adequate protection
during power on/off may result in lost or modified data.
1000579
12.19.01 Rev 3
All data sheets are subject to change without notice
1
(858) 503-3300 - Fax: (858) 503-3301- www.maxwell.com
©2001 Maxwell Technologies
All rights reserved.
